Disaster Area Designs DMC.micro PRO Manual page 6

s M
etup
HOLD TIME / HOLD: Configures the time needed to trigger the "hold" functions for the
DMC footswitches. Set this to LO to trigger holds faster, or set to HI if you are experiencing
unwanted holds.
USB MODE / USB: Configures USB port function.
MIDI = your computer or mobile device controls DMC.micro
HOST = DMC.micro controls your class-compliant USB MIDI device
INPUT CHANNEL / INCH: MIDI channel the controller will use to receive incoming data.
Default is 16. MIDI input on DMC.micro requires the use of the Disaster Area MIDI-Y cable.
MIDI THRU / THRU: Enable or disable MIDI thru on the DMC interfaces. MIDI data from each
interface is always passed to the others, THRU setting determines whether that same data is
returned on the same interface. In most cases, this should be set to OFF or 5 P.
OFF: No MIDI data will pass from input to output on any interface
5 P: MIDI data coming in from the DIN port will be passed to the DIN port
JACK: MIDI data from the MultiJack will pass back through the MultiJack
ALL: MIDI data from DIN, USB, and Jack will pass back out those interfaces
USB: MIDI data from USB port will be mirrored back to USB port.
NAME DISP (PRO): Enable preset name display
OFF: Show preset number only
NAME & NUM: Show preset name and number on two lines
BIG NAME: Show first 7 letters of preset name in large font
UTIL NAME (PRO): Display 5-character names for each Utility Mode function.
UTIL LOAD / UT.LD: Load the UTIL mode values per preset for either Util X, Y, or both. Please
consult the Utility Mode section on
BRT:
Sets display brightness from 0-9. Default is 4. Only available on
CUST 1, CUST 2 /
Custom Devices section on
neither of the Custom devices is selected in any device slot.
DUMP:
Preset and configuration dump via MIDI SysEx.
FACT:
Factory reset. Tap RIGHT in this menu until a setting is displayed,
then tap the left button to reset those settings to defaults.
ALL = clears configuration, fills presets from 0-99.
PROD = test mode, used at the factory.
C4 = sets up Device A and the USB port for use with the Source Audio C4. Does not
erase preses or change other config items.
MERS = sets up Device A and the MultiJack for use with the Meris pedal lineup.
Will not erase presets or change other config items.
CBA = sets up Device A and the MultiJack for use with a single Chase Bliss pedal.
Does not erase presets or change other config items.
4
(
enu ContInued
page 20
C1, C2: Configure the two Custom MIDI devices here. Please consult the
page 15 for full details. Note: these menu items will be hidden if
)
for further details.
LED4 version.
