Boss S Etup G Uide - Disaster Area Designs DMC.micro PRO Manual

Boss s g
etup uIde
The DMC.micro supports the following Boss pedals:
500 Series: DD-500, MD-500, RV-500
200 Series: DD-200, OD-200, GE-200
Slicer SL-20 (MIDI Clock only!)
Boss 500-Series pedals have full-sized DIN connections for MIDI connections. Select the
correct device driver to match your pedal in the DevA-DevD menu, ex. DevB = Boss DD500.
To configure the pedal, enter the MIDI menu by pressing EDIT, press down to select MIDI, and
press EDIT again.
Set Rx Channel to match the device slot you have chosen for the Boss pedal, ex. DevA = CH1,
DevB = CH2.
Set PC OUT = off, Bank Sel Out = OFF, MIDI IN->OUT = MIDI, SYNC = MIDI
To use the DMC.micro to set the tempo on the 500-Series, we recommend enabling the Clock
mode as shown on page 19.
The default settings should be correct but if you have problems controlling the pedal, enter the
MIDI mode again and ensure that the following are set:
DD-500: Effect On / Off CC = 21, EXP CC = 16
MD-500: Effect On / Off CC = 27, EXP CC = 16
RV-500: Effect On / Off CC = 27, EXP CC = 16
Boss 200-Series:
All of the pedals in this series have the same MIDI implementation. Please ensure that your
200-series pedal is updated to the latest firmware from the Boss site to enable full MIDI control.
Configure the device slot you wish to use for your Boss pedal as Boss 200 / BOS2. Ex. DevD =
Boss 200. Configure MULTIJACK = MIDI TIP / MID.T and set JACK CHAN / J CH to match the
device slot you have selected, ex. JACK CHAN = CH D.
Ensure that the DIP switches on the DMC.micro are set to ON-ON-ON.
Connect your Boss pedal's 1/8" MIDI input to the MutliJack using a 1/4" to 1/8" TRS cable
Enter the 200-series settings menu by holding the two buttons above the footswitches, ex. TAP
DIVISION and MEMORY on the DD-200.
Turn the data knob to select a parameter, then press it to select and change that parameter. On
the DD-200 this is the TIME knob.
Configure rCH to match the MIDI channel for your chosen device slot, ex. DevA = CH1, DevB =
CH2.
Configure tCh = OFF, Pin = ON, Pot = OFF, CCi = ON, CCo = OFF, EPC = 16, EFC = 27, SYn =
Aut, Nth = ON
Save and exit by holding both buttons down.
8
