Summary of Contents for Schulthess Priate household
- Page 1 Only use appliance after first reading the instructions! Operating instructions Washing machine Priate household...
- Page 2 Symbols Please read the instructions. Warnings are marked with a warning triangle. The text gives information how a dangerous situation can be avoided. Signal words indicate the severity of the danger, if not avoided. Warning means that possible personal inju- ries, and potentially life-threatening injuries may occur.
- Page 3 Please read these instructions carefully to enable you to use all the possibilities and advantages of your new washing machine. Please note in particular the safety informations. We hope you will be very happy with your new Schulthess machine. Your Schulthess Maschinen AG...
-
Page 4: Table Of Contents
Content Safety and safety measures ..........6 Disposal . - Page 5 Rinse + ..............35 Temperature .
-
Page 6: Safety And Safety Measures
Safety and safety measures The enclosed documents contain Do not let children play with the important information on the machine. Do not let children carry installation, use and safety of the out cleaning and user maintenance machine. without supervision. Keep the documents safe for other Safety while handling users or subsequent owners. - Page 7 Always unplug the machine from Components sticking out from the ► the power source before carrying machine (e.g. loading door, cover out maintenance work. plate) may break off and cause inju- If the machine is not needed for ries, when used for lifting. ►...
- Page 8 Safety for children Safety during installation Warning Warning Risk of injury! Risk of injury! Children are in danger of injury or If the machine is to be placed on a life-threatening situations, when plinth, it must be mounted accord- playing with the machine. ing to the installation instructions, ►...
- Page 9 When operating the washing ► machine at 2000 m above sea level, it is absolutely imperative to activate the temperature limiter to prevent the water from boiling (see service instructions or ask the customer service and / or retailer). Check the hose kit at regular ►...
-
Page 10: Disposal
Disposal Packaging from your new machine The advance recycling fee (vRG) All packaging materials used are environ- The advance recycling fee is already con- mentally friendly and reusable. Return the tained within the price of a new machine. packaging to the retailer or supplier. The current disposal of old machines is Dispose of all packaging materials properly. -
Page 11: Washing Tips
Washing tips Detergent For smaller wash loads reduce the dosing quantity by one third (for machines with You can use all powder, compact (con- load measurement: please note the infor- centrated), tablet and liquid detergents mation on the display). commonly available for use in automatic Rule of thumb: If during the washing a foam washing machines. - Page 12 Detergent recommendations according to EU Ecodesign Directive ► Use the right detergent for the type and colour of your fabrics Strong Coloured Gentle Wool Wash programme detergent detergent detergent detergent 30° Sportswear 30° Athletic shoes 60° Terry towels 60° Bed linen 60°...
- Page 13 Wash these fabrics in the standard Use dosing aids such as dosing balls or ► ► programme. bags supplied with the detergent. heavily soiled Soap-based detergents Clearly visible soiling and stains. Because soap does not contain anything Increased dosing as per the dosing to prevent limescale, you should only use it ►...
- Page 14 Fabric softener, fabric conditioner Hot water supply Before adding thick fabric softener add The following points should be noted: water and stir to ensure that it is free of The max. permissible hot water ► lumps so that the siphon does not get temperature is 70 °C.
-
Page 15: Environmentally Compatible Washing
Environmentally compatible Knitwear made wholly or partly from wool washing must also be labelled «non-felting» or «machine washable», otherwise there is a risk of felting during the washing process. Fill the drum with the maximum load quan- tity possible for the respective programme. Important This way you wash with the lowest energy Textiles with metal reinforcements can dam-... -
Page 16: Stain Removal
Stain removal Dyeing textiles in the washing machine Stains that are not pre-treated may Starting and interrupting the become set on the textiles during the wash. Such stains may be permanent programme or can only be removed with very strong Choose the washing programme ►... -
Page 17: Machine Description
Machine description Detergent drawer Control and display area Maintenance hatch Loading door... -
Page 18: Control And Display Area
Control and display area Eco 40 – 60 30° Cotton 30° Cleanjet 40° Cotton Control panel Programme buttons * On / Off Sportswear, outdoor Back in the menu Babycare Scroll backwards Favourites Scroll forwards Homecare Start programme Businesswear Open the door Softcare Antibac Display... -
Page 19: Detergent Drawer
Detergent drawer Liquid detergent Pull the flap down. ► Detergent for the main wash, bleach, modular detergent, For washing powder and tablets, push ► starch, water softene the flap up and back. Fabric softener and other laundry care additives for the Notice final rinse. -
Page 20: First-Time Use
First-time use Turn on machine Install the machine according to the ► On / Off installation instructions. Press button . After ► Do not connect an appliance which starting, the main menu is displayed. ► displays visible damage. Eco 40 – 60 Make certain that transport safety ►... -
Page 21: Washing
Washing Preparing the appliance Selecting the wash programme Screw on pump cover. ► Switch on the power supply. Eco 40 –60 ► Open the water tap. ► 30° Cotton Turn on machine 30° Cleanjet On / Off Press button ► 40°... - Page 22 If necessary, cancel the selection by Closing the door ► tapping the light bar again. Close the door by pushing it until the lock ► Additional options can be accessed audibly engages. ► Scroll by pressing the arrow button Ensure that no items of laundry are ►...
-
Page 23: Starting The Programme
40° Cotton 0:57 h Starting the programme Adding more laundry max. 8.0 kg 1500 rpm Rinse+ Washing Press button ► Child lock active Cancel Forward Settings / Child lock. Skipping to the next programme step Open the door Press button ►... -
Page 24: Interrupting The Programme
Interrupting the programme 40° Cotton 0:01 h max. 8.0 kg 1600 rpm On / Off Press button until the ► Rinse + following window is displayed: Programme stopped Cancel Forward The water will be drained and the pro- ► gramme ends. Stop Continue Ending programme... -
Page 25: Programme End
0:01 h max. 8.0 kg The laundry can be spun after Remove the laundry rinse stop Programme end, crease protection Press button . The water will be ► pumped out and the laundry spun. Child lock active Settings / Child lock. - Page 26 Important Close the water taps. If the water tap is open while the power supply is inter- rupted, the overflow protection does not function. (Only for machines without aquastop: The aquastop valve automatically blocks the water supply when the programme has ended.)
-
Page 27: Wash Programmes
Wash programmes This overview includes the wash programmes of all machine types. The programmes avail- able on your machine are listed in the quick start document which you received with your washing machine, together with detailed information about water and energy consumption, as well as residual moisture. - Page 28 Bed linen, aprons, jeans, towels, shirts, underwear 60° Cleanjet ► Coloured cotton, line ► More efficient use of the detergent Bed linen, aprons, jeans, towels, shirts, underwear 60° Cotton ► Coloured cotton, line, quick wash Powerclean ► Small and medium loads Outerwear, T-shirts, shirts, sportswear 30°...
- Page 29 Diapers, onesies 70° Baby clothes ► White and colourfast cotton compartment ► With pre-rinse. Add the detergent to Onesies, rompers, overalls, pyjamas, shirts, pants 40° Baby clothes ► Easy care cotton or non-iron mixed fibres For rinsing hand-washed textiles Rinse, spin Rinse, spin ►...
- Page 30 40° Blocks for play LEGO, Duplo etc. without electrical components ► Wash building blocks in a laundry net and then dry in a dryer in the basket or let air dry ► Take building blocks that are stuck together apart before drying ►...
- Page 31 ► If you would like to use a detergent, we recommend the use of the Schulthess cleaner R 163. ► Start the Autoclean programme and press Forward. The pro- gramme then jumps to the washing programme step. During the dispensing of water, pour approximately 50 ml of cleaner...
-
Page 32: Programme Groups
Programme groups The programmes described as follows Leave to work for around 5 minutes and ► are not available on every machine. then wash the items in the washing machine. Pressing the symbol button the menu of the respective programme Impregnating group is called up. -
Page 33: Homecare
Homecare Businesswear Because of their high water level and Usually there is no need to iron on-iron low spin speed, homecare programmes shirts and blouses. are particularly well suited for house- Hang the shirts and blouses up and let ► hold textiles made of mixed fabrics and them air dry. - Page 34 Favourites 20° Cotton 40° Easy care Prewash 60° Cotton Express You can also call up your saved favourite programmes directly on the display, Set- when you start the machine (see tings / Start menu selection). Deleting favourites Settings / Deleting favour- ites.
-
Page 35: Programme Options
Programme options Prewash The options described as follows are not available on every machine. For particularly heavily soiled laundry By also selecting one or more options, ► with bad stains (e.g. blood, protein-con- a wash programme can be specifically taining stains etc.) as well as occupa- tailored to the particular characteristics tional laundry. -
Page 36: Rinsing Stop
You can end the programme by draining ► Notice the water without spinning or by spinning Washing / Ending programme The temperature cannot be lowered for (see 70° Autoclean with rinsing stop). programme. Soaking Speed 40° Cotton Select a lower spin speed for a gentler 0:57 h max. -
Page 37: Supersilent
Time preset The selected programme starts auto- ► matically after soaking. Forward Select to start the washing ► programme immediately. Time preset With the option ► start time of the programme can be Child lock active delayed and thus suit your lifestyle (e.g. Settings / Child lock. - Page 38 40° Easy care 0:39 h max. 4.0 kg 800 rpm Time preset Programme start 03.12. 21:00 Cancel Forward The selected programme starts auto- ► matically when the start time is reached. Pressing the start button again cancels ► time preset and the washing programme can be started immediately.
-
Page 39: Settings
Settings Your washing machine has basic settings from the factory. The settings can be Settings adapted to the users individual needs Language either when first used or later using the following functions. Date The settings can only be changed if no Time wash programme is running. -
Page 40: Menu Settings
Menu settings Display programme time Duration * ► * = Default setting The display shows the remaining time of the programme. Language ► English * ► The display shows when the programme ..► will be finished. Additional menu pages can be opened arrow buttons by pressing the Brightness display... - Page 41 Extra rinse Soap wash programme Off * Off * ► ► ► ► Additional rinsing improves the rinse A programme sequence optimised for result in soft water areas or for allergy the use of soap detergents by using sufferers. and extra rinse cycle to more thoroughly The selected setting affects all washing rinse out the soap detergent.
- Page 42 Hold the light bar in the upper Load measurement ► right (is not lit!). pressed down On * ► At the same time press the desired ► ► button. When load measurement is activated, the laundry load is displayed together Deleting favourites with a recommendation for the appro- Select the function.
- Page 43 Switch off the machine Crease protection Settings for switching of the machine ► 30 min * automatically: ► ► ► At the end of the programme a crease The machine always remains switched on. protection phase (loosening up of laundry) for 30 minutes or 6 hours can ►...
- Page 44 Cool down Off * ► ► Damage to older drains can be prevent- ed by adding cold water to the boil wash cycle at the end of the washing process. To prevent creasing, easy-care programmes are always cooled down, regardless of the selected setting here. Reduced mains power No * ►...
-
Page 45: Cleaning And Maintenance
Cleaning and Maintenance Cleaning the machine Descaling the machine Lime scale formation depends largely Caution on the hardness of the water.If the Danger of electric shock! correct amounts of detergent are used, Switch off the power supply to the descaling is no longer necessary in gen- ►... -
Page 46: Frost Protection
Frost protection Cleaning the detergent drawer If your washing machine is in a room susceptible to frost, all residual water Removing the detergent drawer must be removed from the detergent The drawer can be pulled out completely pump and the water supply and drain by pressing lightly on the coloured tab in hoses immediately after use. -
Page 47: Emergency Emptying
Emergency emptying Emergency emptying is necessary if: Check drain The error message ► appears. The pump is blocked by a foreign body ► (e.g. buttons, paper clip, fluff). The water cannot be pumped out. ► Clean the insert and the detergent ►... -
Page 48: Cleaning The Filter In The Water Inlet
Warning Risk of scalding!! When washing at high temperature the suds may be very hot. Let the suds cool down before draining! Schliessen Sie die Wartungsklappe. ► Schalten Sie die Stromzufuhr wieder ein. ► Wählen Sie ein beliebiges Wasch- ► programm und brechen Sie dieses ab, sobald die Wasserzufuhr beendet ist. - Page 49 Machines without aquastop Machines with aquastop Screw off the supply hose at the tap. Switch off the power supply. ► ► Rinse out the filter under running water. Screw off the supply hose at the tap. ► ► Connect the hose again. Pull out the filter using a pair of long ►...
-
Page 50: Problems
Problems Warning Improper repairs can result in severe accidents, damages and operation malfunctions! Do not make any changes, manipulations or attempt repairs using tools such as screw- drivers, etc. ER R O R MES S AG E S ON T H E D I S PL AY (is not lit!) and at the Child lock active... - Page 51 The position of the drain hose is too high. The maximum ► pumping height is 1 m above ground. Insufficiently balanced The laundry could not be spun due to excessive unbalanced weight. Continue Press the light bar next to to restart rinsing. ►...
- Page 52 Acknowledge the error message with OK. «Error F ––» ► is displayed again Interrupt the power supply for one minute (switch the main ► despite programme switch off and on again). As soon as the display lights, restart the appliance is again ready to operate. Press the door until you hear the lock snap shut.
- Page 53 Open the loading door Ensure that the drum stopped turning. ► manually Close the water tap. ► Switch off the power supply. ► Warning Cleaning and Carry out an emergency emptying (see ► Hot wash water! Maintenance). Danger of burns! Drain the machine before manual opening!
- Page 54 WASH IN G A ND WA S HI N G R ES U LT Detergent residue in compartment The blue is in the position the detergent drawer for liquid detergents. Damp or clumpy Push the lid up and back. ► detergent Dry the detergent drawer before adding detergent.
- Page 55 Grey stains on Grey stains may be caused by cosmetics or fabric softener the washing and may have appeared on the laundry outside the machine before washing. Some stains can be washed out after soaking in liquid ► detergent. The laundry is hard Use a conditioner for the next wash, if the laundry is dried ►...
- Page 56 FOAM AN D L EA K AG E Some foam can be Some detergents tend to produce more foam, which does seen at the not affect the rinse results. programme end Too much foam visible Too much detergent was used. during washing Mix approx.
- Page 57 Puddles and / or water Too much detergent was used. stains form on the Reduce detergent dose in the future. ► floor Check whether the supply and drain hose connections are ► watertight and have been effected properly. S P I NNIN G A ND N O IS E Pump noise No error! Intake noise and «Emptying»...
-
Page 58: Customer Service
If repairs have been undertaken by some- one who is not authorised by Schulthess, there is no entitlement to guarantee services or product liability benefits for subsequent damage. This also applies if parts have been attached or installed... - Page 60 Headquarters and Production Schulthess Maschinen AG Landstrasse 37, 8633 Wolfhausen ZH Tel. + 41 (0) 55 253 51 11 www.schulthess.ch Austria Schulthess Maschinen GmbH Hetzendorfer Strasse 191 1130 Wien Tel. + 43 (0) 1 803 98 00 www.schulthess.at Brief instruction Follow the safety instructions in this manual! Turn on the power switch and open the water tap.
