Mounting Instructions
Öhlins shock absorber kit KA 590
for Kawasaki KX 85
© Öhlins Racing AB. All rights reserved. Any reprinting or unauthorized use without the
written permission of Öhlins Racing AB is prohibited. Printed in Sweden.
Kit Contents
Before installing the shock absorber, please
check the contents of the kit. If anything is
missing, please contact your Öhlins dealer.
Description Pcs. Part No.
Shock absorber 1 KA 590
Spring clip 1 00516-01
Screw 1 00439-19
Washer 1 00153-06
C-spanner 1 00710-02
Sticker Öhlins 2 00197-01
Sticker memo notes 1 01180-01
Owner's manual 1
Before Installing
Öhlins Racing AB cannot be held responsible
for any damage to shock absorber or vehicle,
or injury to persons, if the instructions for fi tting
and main tenance are not followed exactly.
Similarly, the warranty will become null and
void if the instructions are not adhered to.
Öhlins products are subject to continuous im-
provement and development. Consequently,
although these instructions include the most
up-to-date information available at the time
of printing, there may be minor differences
between your shock absorber and this manual.
Please consult your Öhlins dealer if you have
any questions regarding the contents of this
manual.
