R320103179/2019-12 | IMScompact position display
10�2 Possible errors and their correction
The following table shows possible errors and their correction.
Table 6: Error messages and their correction
Error number Error description
"Err 110" Data storage error
"Err 210/220" Sensor error (occurs only with
absolute measuring systems).
"Err 240" Power supply breaks down
during operation.
"Err 250" Power supply breaks down
during switch-on.
10�3 Recommissioning after fault clearance
After eliminating the fault(s):
1 If necessary, reset the emergency stop device
2 If necessary, reset the error message at the superior system
3 Make sure that there are no persons in the danger zone
4 Follow the instructions in section 5
WARNING!
Risk of injury due to improper fault clearance!
Improper fault clearance can lead to severe personal injuries or damage of property.
Therefore:
• Any work to eliminate faults may only be performed by sufficiently qualified and instructed
personnel.
• Before starting work, ensure that there is sufficient installation space.
• Make sure that the installation site is tidy and clean. Loose components and parts lying
around or on top of each other are sources of accidents.
If components need to be replaced:
• Pay attention to correct installation of the spare parts.
• Reinstall all fixing elements properly.
• Before recommissioning, make sure that all covers and safety equipment are installed
correctly and function properly.
10�4

Maintenance

The device is maintenance-free.
10�5

Cleaning

WARNING!
The device must only be cleaned with a damp cloth. Do not use aggressive detergents!
Error correction
Switch the device off and on again. If the error occurs again, return
the device for repair.
Switch the device off and on again. If the error occurs again, check
the measuring system and its wiring. If unsuccessful, return the
device for repair.
Switch the device off and on again. If the error occurs again, check
the supply source or the power pack. If unsuccessful, return the
device for repair.
Switch the device off and on again. If the error occurs again, check
the supply source or the power pack. If unsuccessful, return the
device for repair.
Bosch Rexroth AG 15/18
