Parameter list

Table 4: Parameter list
Par� no� Function
P01 Counting direction
P02 Display measurement unit
P03 Decimal point
P04 Reserve
P05 Keyboard lock
P06 Edge evaluation
P07 Measuring system selection
P08 Multiplication factor
P09 Reference value
P10 Tool offset
P11 Saw blade
P12 Reserve
P13 Reserve
P14 Reserve
P15 Reserve
P16 Default init
P17 Function ext. input 1
P18 Function ext. input 2
P19 Trigger external input 1
P20 Display mode
P21 Reserve
P22 Reserve
P23 Reserve
P24 Reserve
P25 Reserve
P99 Software version
IMScompact position display | R320103179/2019-12
Default setting Description
0 forwards
0 mm
1 1 decimal place
-
0 deactivated
0 1 edge
0 incremental
01.00000
000000.0
000000.0
0000.0
-
-
-
-
0 not active
0 not active
0 not active
0 level-sensitive
0 standard
-
-
-
-
-
-
Customer settings for
IMSc TTL10 µm
0
2
-
2
0
01.00000
-
-
-
-
0
-
-
-
-
-
-
