Massoth DiMAX Operation page 4

Changing the Loco Selected by Using Its Address:
Pressing and briefly holding M2 enters the "Loco Selection Mode". Enter
the loco address using the keyboard, for example press "25", and press M3
to select the locomotive with the address of "25". (The locomotive is assigned
to the Navigator by an address previously set in the decoder.) The Navigator
will automatically start running loco "25".
Change Loco and/or Configuration
Previously configured locomotives are stored in
the Central Station & the Navigator, and may
be selected using the Loco Selection Mode.
Saved locos may be selected by pressing M1
(up) & M2 (down) to scroll the database.
Confirm your selection by pressing
----------------------------------------------------------------------------------------
Re-selecting running locomotives ("catching"): When changing operation
between running locomotives you will have to catch up with the actual
speed of the re-selected locomotive. After re-selecting a locomotive, the
display will show the actual speed of the locomotive (speed steps) and the
driving direction. The wheel knob will flash in the driving direction. To
catch up with the locomotives speed turn the dial in the flashing direction
until the flashing stops (and the speed step setting changes). The locomotive
is now re-selected and can be operated as usual.
-------------------------------------------------------------------------------------------
Operating an Analog Locomotive
The Navigator supports operating an
analog loco using "0" as its address.
The analog operating feature will show
an analog throttle as loco picture. Loco
configuration programming is not
available for analog locos.
M3.
:
Loco Selection Mode Screen
Analog Loco Screen
Page 4 of 6
