Visual Productions B-STATION2 Manual page 39

Button Triggers when pressing a button the the B-Station2.
Playback Events generated by the playbacks
Fixture Events generated by the fixtures
Kiosc Triggers from Kiosc. For each Action various controls can
be chosen such as buttons and sliders, colour picker etc. The
order of the actions will control the arrangement in Kiosc.
OSC OSC network message
UDP UDP network messages
TCP TCP network messages
DMX Input DMX received on the DMX port (switch port to input in
the settings page)
Art-Net Art-Net DMX data
sACN sACN DMX data
System Events such as 'Start up'
Timer There are 4 internal timers in the B-Station2. An event can
be raised when a timer starts or ends. Timers are set and
activated by the Timer tasks.
Variable There are 10 Variables in the B-Station2. The Variable
source can trigger when the value of a variable is changed or
refreshed. Variables are changed or refreshed using the
Variable task.
Randomizer The Randomizer source can trigger on a number randomly
created by the Randomizer task.
Actionlist Triggers whenever an Actionlist is enabled or disabled.
User List 1-4 These action-lists have no trigger value. They can only be
triggered by the Action task. They are useful for advanced
programming.
Action-lists can be temporarily suspended by disabling their checkbox in the
Show Control page. There is also a task available to automate changing the
state of this checkbox.
8.2 Actions
Actions are executed when a certain signal is received. This signal is defined
by the trigger. A trigger is always relative to the action-list the action belongs
to. For example, when the trigger type is set to 'Channel' and the actionlist is
DMX Input it will only respond to the selected DMX channel inserted via the
physical DMX connections on the device. If the trigger-type is set to Channel
and the actionlist is Art-Net it will only respond to the selected channel inserted
via Art-Net.
