CONNECTIONS DIAGRAMS
COUNTER OR PLC
Power Input
Pulse Output
Direction Output
A055 4-20 mA OUTPUT
EX SERIES
+
Power Input
_
+
Pulse Output
_
Direction
FT520 CONTROLLER
Batching
Relay
Output
Page 6
+
11 - 24 Vdc 250 mA max.
_
11 - 24 Vdc 5 mA max.
+
_
11 - 24 Vdc/Vac
100 mA max.
EX SERIES
Sensor
Unused
FT520
NC
+12V
COM
SEN1
NO
G
SEN2
0 0 0 0 0 0 0 0
+
S
+
_
_
4-20 mA
AO55
_
24 Vdc Power
Frequency Input
25 hz per ft/sec
Direction Input
Com
COUNTER OR PLC
DIGITAL INPUT
+
24 Vdc Power
+
4-20 mA
+
EX SERIES
Power
Input
Pulse
Output
Direction
_
_
+
_
+
_
