5 Connect other devices by cabling each device to the previous
one, as shown in the figure on
6 Terminate the last device in the SCSI chain, as shown in the
figure below. All other devices must have termination set to
disabled. See
information.
USB2Xchange adapter
7 Power on your SCSI devices.

Connecting to Your Computer

To connect your USB2Xchange adapter to your computer:
1 Power on your computer.
2 Plug the USB connector into the USB port on your computer.
3 Make sure the cable ends are firmly connected. Do not force your
connections as this may damage your system or the USB2Xchange.
Note: The USB2Xchange receives its +5V power from either
the terminator power line of the attached SCSI device, or if
no termination power is available, from the USB bus.
Terminating the SCSI Bus on page
Unterminated devices
Installing USB2Xchange
page 5.
25, for more
Terminated device
