ZEPHYRONLINE.COM
Model:
Voltage: 120V 60Hz
Power consumption
Total: 87W@08.A
Lamp: Max. 6Wx2
Fan: 75W
THERMALLY PROTECTED
Model: AK1124Bx
Voltage: 120V 60Hz
Power consumption
Total: 81W@08.A
Lamp: Max. 6W
Fan: 75W
THERMALLY PROTECTED
Model:
Voltage: 120V 60Hz
Power consumption
Total: 70W @0.8A
Lamp: 5W
Fan: 65W
Breeze I & Breeze II Use, Care, and Installation Guide
AK1100Bx, AK1136Bx
AK1200Bx, AK1236Bx
THERMALLY PROTECTED
Wiring Diagram
CIRCUIT DIAGRAM
B/W
B/W
B/W
MOTOR
YELLOW
WHITE
WHITE
CIRCUIT DIAGRAM
B/W
B/W
B/W
MOTOR
YELLOW
WHITE
WHITE
BODY
BODY
