ACTiSYS BT5701S Specifications

Bluetooth RS232 Adapter
Bluetooth RS232 Adapter
Example of RS232 Cable Replacement application
Hotspot wireless
router
Internet account
registration printer
enables any RS232 devices with Bluetooth capability and eliminates RS232 cable connections.
Features and Benefits
No Driver Required for Non-Windows Based Communication (Client) Devices
Configurable as an RS232 Cable Replacement Set
Supports Class 1 Output Power Up to 100 m Operation Range
Bluetooth SIG 1.2 Compliant
Profile Supported: Serial Port Profile as a Master or as a Slave
Baud Rate Supported: 1200 bps ~ 1843200 bps
Configurable for Baud Rate, Data Bit, Parity Check, Stop Bit, RTS/CTS Flow
Control, BD Address, Device Name, Control Flag, PIN Code, Watchdog Timeout,
Supervision Timeout, and Peer BD Address (only used in Master)
Class I
Bluetooth RS232 Adapter enables any RS232 devices with
Bluetooth capability and eliminates RS232 cable connections.
This unit can be configured as a Bluetooth Piconet or as a
point-to-point RS232 cable replacement set. It is an ideal
wireless link solution for industrial, medical and commercial
applications which require freedom from cable connections. It
supports SPP as a Master or a Slave.
Application Scenario
Bluetooth RS232 adapter
BT5701Sv2
Example of RS232 Piconet application
Bluetooth enabled PC or PDA with
RS232 application program
RS232 devices
