ACTiSYS BT5701Si Specifications

Bluetooth RS232 PCB
Bluetooth RS232 PCB
Module w/Antenna
Module w/Antenna
Example of RS232 Cable Replacement application
Hotspot wireless
Internet account
registration printer
Bluetooth RS232 Adapter enables any RS232 devices with Bluetooth capability and eliminates
Features and Benefits
No Driver Required for Non-Windows Based Communication (Client) Devices
Configurable as an RS232 Cable Replacement Set
Supports Class 1 Output Power Up to 100 m Operation Range
Bluetooth SIG 1.2 Compliant
Profile Supported: Serial Port Profile as a Master or as a Slave
Baud Rate Supported: 1200 bps ~ 1843200 bps
Configurable for Baud Rate, Data Bit, Parity Check, Stop Bit, RTS/CTS Flow
Control, BD Address, Device Name, Control Flag, PIN Code, Watchdog Timeout,
Supervision Timeout, and Peer BD Address (only used in Master)
Bluetooth RS232 PCB Module enables any RS232 devices
with Bluetooth capability and eliminates RS232 cable
connections. This unit can be configured as a Bluetooth
Piconet or as a point-to-point RS232 cable replacement set. It
is an ideal wireless link solution for industrial, medical and
commercial applications which require freedom from cable
connections. It supports SPP as a Master or a Slave.
Application Scenario
router
RS232 cable connections.
Class I
Example of RS232 Piconet application
Bluetooth enabled PC or PDA with
RS232 application program
BT5701Si
RS232 devices
