Technical Specifications

Specifications

Technical Specifications
Specific Specifications
Flow
(The maximum flow rate is not only
determined by the type of loading
post but also depends on the size of
the refuelling hose, the model of the
breakaway, the type of refuelling
nozzle, and the vehicle coupling.)
Pressure rating
(350 bar options utilise air actuated
valves and require a compressed air
supply.)
Accuracy
Meter
Internal Pipework
Hose
In-line breakaways
Refuelling valve
Loading meter overall dimensions
L x W x H
Minimum flow cut-off
Maximum flow cut-off
Compac Industries Ltd.
Compac CNG Loading Posts (excluding hose assembly) are designed to
operate within the atmospheric environment. Gas parameters are outlined
below.
They require the following operating conditions:
Air temperature range
Air humidity range
Gas type
Gas temperatures
Maximum Water Dew Point
Maximum Working Pressure
(Inlet)
Power Requirements
Standard Model
1 – 15 kg /min
275 bar
(350 bar option)
+/- 1.0%
Compac KG80 coriolis mass flow
1/2"
3/8"
Various available
NGV1 or NZ 7/16" probe
400 mm x 400 mm x 2440 mm
0.5 -10 kg/min (settable)
10 - 99 kg/min (settable)
Page 50
- 25 °C to + 55 °C
10% to 95%
High pressure natural gas (CNG)
- 40 °C to + 80 °C (continuous)
- 55 °C to + 80 °C (intermittent)
- 32 °C at 250 bar
275 bar (350 bar option)
230V +/-10%, 50Hz, 2A
