Control Buttons

This figure shows the primary control buttons on the device, described in the following table.
f
eature
Display Screen
Humidifier Icon
Humidifier Numbers
Control Wheel/Push
Button
Ramp Button
Alarm Silence/Indicator
Button

available Therapy Features

If prescribed for you, the device provides the following therapy features.
Bi-Flex Comfort Feature
If enabled, the device provides a comfort feature called Bi-Flex. The Bi-Flex attribute adjusts therapy by inserting a
small amount of pressure relief during the latter stages of inspiration and during active exhalation (the beginning part
of exhalation). Bi-Flex levels of 1, 2, or 3 progressively reflect increased pressure relief that will take place at the end
of inspiration and at the beginning of expiration.
Ramp
If enabled, the device is equipped with a linear ramp function. The Ramp feature will reduce the pressure and
then gradually increase (ramp) the pressure to the prescription pressure setting so patients can fall asleep more
comfortably.
Rise Time
If enabled, the device provides a feature called Rise Time. Rise time is the amount of time it takes the device to
change from the expiratory pressure setting to the inspiratory pressure setting. Rise time levels of 0, 1, 2, or 3
progressively reflect slowed response of the pressure increase that will take place at the beginning of inspiration. A
setting of 0 is the fastest rise time while a setting of 3 is the slowest. Providers should adjust the rise time to find the
most comfortable setting for the patient. Rise time cannot be adjusted when Bi-Flex is enabled.
6
Humidifier Icon and
Number Settings
Alarm Silence/Indicator
Button
Shows therapy settings, patient data, and other messages. The startup screen is shown temporarily
when the unit is first powered.
This Icon lights up (different colors) when the optional humidifier and/or heated tube is attached
and heat is being applied. White means classic humidification is selected. Blue means System One
humidification is selected. Orange means the heated tube is attached. Please refer to the humidifier
user manual for more information.
The humidifier number settings are only visible when the humidifier is attached and therapy is active.
You can use the control wheel to change the number settings for the humidifier. When the heated
tube is being used with the humidifier, these numbers will control the heated tube setting.
Turn the wheel to toggle between options on the screen. Press the wheel to choose an option.
Primary function is to turn airflow on/off.
When the airflow is on, this button allows you to activate or restart the ramp function. When
the airflow is off, this button allows you to activate the Mask Fit Check. This button lights up when
therapy is active or during specific alerts.
Silences the audible portion of the alarm for a period of time and indicates an alarm condition.
LCD Display Screen
Control Wheel/Push Button
Ramp Button
D
eScription
