DreamStation BiPAP S/T and AVAPS
Service and Techincal Reference Manual
1127179, V
. 02
ER
D
S
REAM
TATION
B
PAP S/T
AVAPS S
I
AND
& T
R
ERVICE
ECHNICAL
EFERENCE
P
1
AGE
M
ANUAL

Advertisement

Table of Contents
loading

Related Manuals for PHILIPS Respironics DreamStation BiPAP AVAPS

Summary of Contents for PHILIPS Respironics DreamStation BiPAP AVAPS

  • Page 1 DreamStation BiPAP S/T and AVAPS Service and Techincal Reference Manual 1127179, V . 02 PAP S/T AVAPS S & T REAM TATION ERVICE ECHNICAL EFERENCE ANUAL...

  • Page 2: Table Of Contents

    Chapter 1. Introduction ........................ 7 System Overview ..........................7 Device Description ......................... 8 Therapy Modes ..........................8 Therapy Features ........................... 9 Device Features ..........................11 Humidifier System Overview ....................... 12 Service Notice ............................. 13 Service Training ..........................13 Product Support Statement ......................... 14 Chapter 2.
  • Page 3 5.14 Bluetooth Wireless Technology ....................... 46 Pairing to your Bluetooth enabled Mobile Device ................ 46 5.15 Check Mask Fit ..........................47 5.16 Sleep Progress ..........................47 5.17 Altitude Compensation ........................47 5.18 Performance Check Device Screening Tool ..................48 5.19 Accessories ............................
  • Page 4 Device Error Codes ..........................61 Failure Mode Troubleshooting ......................74 Device Alarms ............................. 80 Device Alerts ............................80 Alarm and Alert LED Indicators ......................80 6.10 Alarm and Alert Audible Indicators ....................81 6.11 Silencing an Alarm ........................... 82 6.12 Alarm Message Screens ........................
  • Page 5 Replacing the Dry Box Assembly ....................120 Replacing the Wire Guard ......................121 Replacing the Back Panel Assembly ..................124 Replacing the Flip Lid Latch ....................... 125 Replacing the Lifting Tray ......................126 Replacing the Bottom Cover ...................... 129 Replacing the Heat Shield ......................130 Replacing the Heater Plate O-Ring ....................
  • Page 6 © 2017 Koninklijke Philips N.V. All rights reserved. 1127179, V . 02 PAP S/T AVAPS S & T REAM TATION ERVICE ECHNICAL EFERENCE ANUAL...

  • Page 7: Chapter 1. Introduction

    (C or W**) DreamStation BiPAP AVAPS 30 AE yyX1131Szz (C or W**) DreamStation BiPAP AVAPS 30 AE w/ Humidifier and Standard Tube yyX1131Hzz (C or W**) yyX1131Tzz (C or W**) DreamStation BiPAP AVAPS 30 AE w/ Humidifier and Heated Tube...

  • Page 8: Device Description

    *yy and zz are variables that represent regional configurations, i.e. DOM or INTL models. X is fixed and represents the DreamStation platform. *A model ending in a C signifies a Cellular modem was installed in the device as part of the finished good. ** A model ending in a W signifies a Wi-Fi modem was installed in the device as part of the finished good.

  • Page 9: Therapy Features

    providing machine (time) triggered breaths. For these breaths, the inspiratory time is also a set value. Timed Pressure Support; A Bi-level therapy mode where (BiPAP AVAPS device only) breaths are machine-triggered and machine-cycled. T mode provides mandatory pressure assist with bi-level pressures.
  • Page 10 Bi-Flex Comfort Feature If enabled, the device provides a comfort feature called Bi-Flex. The Bi-Flex attribute adjusts therapy by in- serting a small amount of pressure relief during the latter stages of inspiration and during active exhalation (the beginning part of exhalation). Bi-Flex levels of 1, 2, or 3 progressively reflect increased pressure relief that will take place at the end of inspiration and at the beginning of expiration.

  • Page 11: Device Features

    Rise Time Comfort Feature If enabled, the device provides a feature called Rise Time in all ventilation modes except CPAP. Rise time is the amount of time it takes the device to change from the expiratory pressure setting to the inspiratory pres- sure setting.

  • Page 12: Humidifier System Overview

    The figure above illustrates some of the device features, described in the following table. 1.3 Humidifier System Overview The DreamStation Heated Humidifier attaches to the therapy device and provides an air outlet port to connect a breathing circuit. The breathing circuit is comprised of patient tubing, a mask, and in some instances a sep- arate exhalation device.

  • Page 13: Service Notice

    By using the most current version of the service manual (found on my.respironics.com) and the latest testing software, all repairs and testing can be per- formed. If service training is desired, contact the Philips Respironics service location in your area to schedule training.

  • Page 14: Product Support Statement

    1.6 Product Support Statement For product support, please contact Philips Respironics Customer Satisfaction. U.S.A. and Canada International Phone:1-800-345-6443 Phone: 1-724-387-4000 Fax: 1-800-886-0245 Fax: 1-724-387-5012 Chapter 2. Warnings, Cautions, & Notes Warnings, cautions, and notes are used throughout this manual to identify possible safety hazards, conditions that may result in equipment or property damage, and important information that must be considered when performing service and testing procedures on the device.

  • Page 15: Chapter 4. Cleaning And Disinfection

    If there are any uncertainties related to the disinfectants you are using, please contact Philips Respironics to see if they are approved for use. Follow all instructions from the manufacturer of the disinfectant product. Any deviation from these instructions, the manufacturer’s instructions, or agents not listed in this guide may impact the...

  • Page 16: Chapter 5. Device Setup

    A Philips Respironics DC power cord can be used to operate this device in a stationary recreational vehicle, boat, or motor home. In addition, a Philips Respironics DC battery adapter cable, when used with a DC power cord, allows the device to be operated from a 12 VDC free-standing battery.

  • Page 17: Supplying Ac Power To The Device

    5.2 Supplying AC Power to the Device Complete the following steps to operate the device using AC power: 1. Plug the socket end of the AC power cord into the power supply. 2. Plug the pronged end of the AC power cord into an electrical outlet that is not controlled by a wall switch.

  • Page 18: Connecting The Tubing To The Pap Device

    5.3 Connecting the Tubing to the PAP Device To connect the Tubing to the device, complete the following steps: 1. Connect the flexible tubing to the air outlet on the back of the therapy device. Line up the connector (1) at the top of the heated tube to the top of the air outlet port on the back of the device. 2.

  • Page 19: Connecting The Humidifier To The Pap Device

    WARNINGS • Do not pull or stretch the tubing. This could result in circuit leaks. • Inspect the tubing for damage or wear. Discard and replace the tubing as necessary. • If the device is used by multiple persons (such as rental devices), a low-resistance, main flow bacteria filter should be installed in-line between the device and the circuit tubing to prevent contamination.

  • Page 20: Connecting The Tubing To The Humidifier

    5.5 Connecting the Tubing to the Humidifier 1. To attach the heated tube to the heated humidifier, line up the connector (1) at the top of the heated tube to the top of the air outlet port (2) on the humidifier. 2.

  • Page 21: Disconnecting The Tubing

    5.6 Disconnecting the Tubing 1. To remove the heated tubing, press in the tabs (1) on the side of the tubing connector and pull the tubing away from the outlet port. 2. If you are using a standard tube (not shown) instead of a heated tube, simply pull the tubing away from the outlet port.

  • Page 22: Checking The Humidifier Lid Seal

    5.8 Checking the Humidifier Lid Seal Under normal use, the humidifier lid seal should not require any maintenance or replacement. The seal may be cleaned as needed by wiping it with a damp cloth. If necessary, the humidifier lid seal may be removed for further cleaning.

  • Page 23: Installing/Replacing The Air Filters

    5.9 Installing/Replacing the Air Filters CAUTION A properly installed, undamaged Philips Respironics blue pollen filter is required for proper operation. The device uses a reusable blue pollen filter that can be rinsed and a disposable light-blue ultra-fine filter. The reusable blue filter screens out pollens, while the light-blue ultra-fine filter provides more complete filtration of very fine particles.
  • Page 24 1. Lift up on the filter access door and swing open. If replacing, pull out the old filter assembly. 2. If applicable, place a clean, reusable blue pollen filter (1) on top of a new, optional disposable light- blue ultra-fine filter (2) and firmly snap them together. 3.

  • Page 25: Starting The Device

    5.10 Starting the Device 1. Ensure power is supplied to the device. The first screen to display will be the Philips Respironics logo, followed by the device model screen, and then the Home screen. The first time the device is powered on, a pop-up will prompt you to set the time on the device. The default setting is Greenwich Mean Time, but you may adjust the time in 30 minute increments to match your local time zone.

  • Page 26: Navigating The Device Screens

    5.11 Navigating the Device Screens NOTE The display is not a touch screen. You must use the control dial to navigate the device menu. The User Interface (UI) on this device allows you to adjust the device settings and view information about your therapy.

  • Page 27: User Menu Navigation (Therapy On) And Optional Humidification Settings

    User Menu Navigation (Therapy On) and Optional Humidification Settings While the device is delivering therapy, you can adjust Tube Temperature or Humidifier Settings. Rotate the control dial to choose either setting. Press and rotate the dial to change the setting. Note: If you are using the Humidifier without the Heated Tube, simply just rotate the control dial to change the Humidifier setting.

  • Page 28: Adjusting The Humidifier And Heated Tube Settings

    Adjusting the Humidifier and Heated Tube Settings If you have a humidifier, you can adjust tube temperature or humidifier settings while the device is delivering therapy by following these steps: 1. Turn the control dial counter-clockwise to activate the humidifier setting and clockwise to activate the heated tube setting.

  • Page 29: User Menu Navigation (Therapy Off)

    User Menu Navigation (Therapy Off) From the Home screen, you can scroll between the following four options: • My Info: This menu provides summary statistics of your therapy use. • Preheat: This function lets you warm up your humidifier for 30 minutes before starting a therapy ses- sion.
  • Page 30 Mask Fit Displays the value “100% minus Large Leak”. Large Leak is the percentage of time that the mask leak was so high that it is no longer possible for the device to identify respiratory events with statistical accuracy. Displays the value for the most recent 1 day, as well as the values over last 7 days and 30 days.
  • Page 31 My Provider: When you select “My Provider”, you will be able to view the following screens. You cannot change settings in the Provider menu. These screens are only for reference. Icon Text Description Therapy This screen displays your therapy settings. Settings cannot be adjusted from this screen.
  • Page 32 Upload Allows user to initiate a modem call when an optional Cellular or Wi-Fi Accessory is installed. Signal strength is indicated at the top right of this screen. After the modem upload has finished, the screen will either display a green checkmark with the text “Completed”...
  • Page 33 My Setup: When you select “My Setup”, you will be able to view the following screens. You can change the settings in the Setup menu. These screens will only display if they are available and enabled on the device. Icon Text Description Ramp...
  • Page 34 This setting allows you to select the correct size diameter tubing that you are using with the device. You can choose either (22) for the Philips Respironics 22 mm tubing, or (15) for the Philips Respironics 15 mm tubing. When using Heated Tubing, the device will automatically change this setting to the appropriate tubing type (15H) and you will not be able to change it.

  • Page 35: Accessing Provider Mode Screens

    Accessing Provider Mode Screens Accessing provider mode unlocks settings that cannot be modified by the user. To access provider mode: 1. Supply power to the device. 2. Once the device is powered, press and hold both the control dial and the Ramp button on the device for at least 5 seconds.

  • Page 36: Provider Settings

    Provider Settings Therapy Settings: Choosing this screen will take you to a sub-menu where you can adjust the device therapy modes and pres- sure settings. These settings are described here. Note: Not all settings shown here will display on the device. The display will vary based on therapy device model and device settings.
  • Page 37 EPAP Max This setting allows you to modify the Maximum EPAP setting. This setting will be the maximum level of pressure applied dur- ing the expiratory breath phase. You may adjust the setting as follows: 25 cm device: From the minimum EPAP setting up to the lesser value of either maximum pressure or 21 cmH 30 cm device: From the minimum EPAP setting up to the lesser value of either maximum pressure or 25 cmH...
  • Page 38 30 cm device; 4 to 30 cmH O in increments of 0.5You cannot set the IPAP setting lower than the EPAP setting. IPAP is lim- ited to 25 cmH O when the Flex feature is enabled. EPAP This setting allows you to increase or decrease the Expiratory EPAP Positive Airway Pressure (EPAP) as follows: 25 cm device: 4 to 21 cmH...
  • Page 39 Low Min Vent You can enable or disable this alarm by choosing 0 (off) to 99 Alarm lpm in 1.0 increments. The alarm will sound when the calcu- lated minute ventilation is less than or equal to the specified setting. The default is 0. Low Tidal Vol- You can enable or disable this alarm by selecting On or Off.
  • Page 40 Comfort Settings: Choosing this screen will take you to a sub-menu where you can adjust the humidification and pressure com- fort settings. These settings are described here. Note: Not all settings shown here will display on the device. The display will vary based on therapy device model and device settings.
  • Page 41 This setting allows you to select the correct size diameter tubing that you are using with the device. You can choose either (22) for the Philips Respironics 22 mm tubing, or (15) for the Philips Respironics 15 mm tubing. When using Heated Tubing, the device will automatically change this setting to the appropriate tubing type (15H).
  • Page 42 Device Settings Choosing this screen will take you to a sub-menu where you can adjust the way the device displays infor- mation. These settings are described here. Note: Not all settings shown here will display on the device. The display will vary based on therapy device model and device settings.
  • Page 43 This setting unlocks provider mode. While unlocked, the pro- Provider Lock vider mode key sequence is not needed to access the therapy, comfort, and device settings. The unlocked icon appears on the screen while in this mode. Info Screens: Choosing this screen will take you to a sub-menu where you can view information on patient usage. The Info screens are described in above sections of this manual.

  • Page 44: Therapy Event Detection

    5.12 Therapy Event Detection Text Description Obstructed airway An apnea is detected when there is an 80% reduction in airflow from apnea/ baseline for at least 10 seconds or if there is no airflow detected for Clear airway apnea 10 seconds. During the apnea, one or more pressure test pulses are detection delivered by the device.

  • Page 45: Connecting To Wi-Fi (If Available)

    5.13 Connecting to Wi-Fi (if available) If your device has a Wi-Fi accessory installed and enabled, follow the steps below to connect your device to Wi-Fi. For additional information, see the instructions included with your Wi-Fi accessory. 1. From the My Setup menu, select Wi-Fi. 2.

  • Page 46: Bluetooth Wireless Technology

    5.14 Bluetooth Wireless Technology The device has Bluetooth wireless technology, which is one method by which you can transfer the therapy device’s data to DreamMapper. DreamMapper is a mobile and web-based system designed to help obstruc- tive Sleep Apnea (OSA) patients enhance their sleep therapy experience. Pairing to your Bluetooth enabled Mobile Device NOTES •...

  • Page 47: Check Mask Fit

    5.15 Check Mask Fit The optional check mask fit feature can be enabled or disabled by the home care provider. This feature allows you to check the fit of your mask prior to starting therapy. This is done by measuring the amount of leak. Put on your mask assembly.

  • Page 48: Performance Check Device Screening Tool

    5.18 Performance Check Device Screening Tool Performance Check troubleshooting tool is a self-diagnostic utility built into the therapy device. It allows you to quickly evaluate a therapy device remotely. If a patient calls indicating that their therapy does not seem to be operating properly, just direct them to click on Performance Check in the patient’s My Provider menu.

  • Page 49: Cellular Modem

    Wi-Fi accessory is designed for use with select Philips Respironics therapy devices. Once installed and con- nected to a local Wi-Fi network it can transfer data between the therapy device and Philips Respironics propri- etary compliance software. If available on your model, the accessory is able to receive oximetry data and transfer it to the therapy device.

  • Page 50: Chapter 6. Troubleshooting And Error Codes

    Chapter 6. Troubleshooting and Error Codes 6.1 Introduction This section provides an overview of device troubleshooting, along with corrective actions to take based on the outcome. You will also find bench checkout procedures, along with tables that include error codes and descriptions.

  • Page 51: System Verification

    Please use the following instructions to ensure that the device is functioning properly. You will need the fol- lowing equipment to verify the pressure: • Philips Respironics Pressure Calibration Kit, which includes: Philips Respironics Whisper Swivel II (REF 332113) Philips Respironics O Enrichment Final Assembly (REF 312710) 0.25 inch orifice (REF 332353)

  • Page 52: Heated Humidifier Performance Confirmation

    10. Enter the Provider menu and set the CPAP pressure value to 20 cmH O. Record the manometer value on the test data sheet, and then stop therapy. 11. Set the device to S mode and set the IPAP pressure to 10 cm H O and EPAP pressure to 5 cm H •...

  • Page 53: Verifying The Alarms

    6. Press the Therapy button to enter therapy and end preheat mode. 7. Press and hold the Therapy button for 2 seconds to end therapy. 8. Record the results on the data sheet. Verifying the Alarms Use the test orifice from the Verifying the Pressure instructions and the patient’s prescription for the follow- ing tests.

  • Page 54: Apnea Alarm Test

    6.3.3.2 Apnea Alarm Test 1. Set the Apnea alarm setting to 10 seconds. Exit to the Home screen. 2. Press the Therapy button to start therapy. 3. Remove the closed end cap. Verify that the device triggers to IPAP. 4. Replace the closed end cap. Verify that the Apnea alarm occurs in approximately 10 seconds. 5.

  • Page 55: System Checkout Data Sheet

    System Checkout Data Sheet Device Information Notification # (if applicable) Model #/Serial # Model name Device firmware version Blower hours Humidifier Verification Test Result (circle one) Humidification test: heater plate operation Pass/Fail System and Alarm Verification Test Result/Tolerance Result (circle one) CPAP @ 4 cmH ] +/- 1 cmH Pass/Fail...

  • Page 56: Service Center Tools Suite

    6.4 Service Center Tools Suite The Service Center Tools Suite will provide you the necessary tools to view the device’s error/event log, along with additional functions necessary to service the device. To download the software you must log onto my.respironics.com. If you do not have an account, click on the “Sign Up” link to register for an account. 1127179, V .

  • Page 57: Service Center Tools Suite Installation And Device Connection Process

    Service Center Tools Suite Installation and Device Connection Process 1. Once you have opened the Service and Software Documentation page, click on the Utility Tools link on the left side or drop down menu of the page. 2. Click on the Download button adjacent to the Service Center Tools Suite (v3.8 or greater). 3.
  • Page 58 Available Functions for DreamStation Devices Read SN & MN This function allows you to read the serial and model numbers of the device. RTC Calibration This function allows you to set and verify the real time clock on the device. Get Session ID This function allows you to retrieve the session ID on the device.

  • Page 59: Clearing The Error And Device Logs

    Clearing the Error and Device Logs • There should be no errors on the device after repairs are made. If there are any errors logged on the device that do not affect device functionality, the error(s) must be cleared. Refer to section 6.3 for a list of error codes, descriptions and corrective actions.

  • Page 60: Resetting First Time Use

    4. The following screen should appear indicating the Session ID has been set. 5. Select the OK button. 6. Select the New Device button if you are setting sessions on multiple devices, otherwise, select the Close button to exit the tool. Resetting First Time Use •...

  • Page 61: Device Error Codes

    6.5 Device Error Codes The following table lists the error level and descriptions for the DreamStation devices. Error Level Description STOP The error information is recorded in NVRAM and the unit is placed into Safe State. The only functionality available to the user is serial communication, turning off the audible alarm via a key press and removing power.
  • Page 62 Failed Code Error Name Error Level Actions Component ERR_NULL_PTR REBOOT 1. If error was NOT Last Stop Error, clear error log and test. 2. If error was Last Stop Error, replace PCA and test. 1. If error was NOT Last ERR_STATE_MACHINE REBOOT Stop Error, clear error log...
  • Page 63 Failed Code Error Name Error Level Actions Component E-19 ERR_WDOG_TIMEOUT ABORT 1. If error was NOT Last Stop Error, clear error log and test. 2. If error was Last Stop Error, replace PCA and test. 1. Motor 1. Reseat motor connector, E-20 ERR_MOTOR_SPINUP_F REBOOT...
  • Page 64 Failed Code Error Name Error Level Actions Component E-27 ERR_MOTOR_RL_NOCO STOP 1. Motor 1. Reseat motor connector, connection clear error log and test. NVERGE 2. Blower Box 2. If error still occurs, replace blower and retest. 3. PCA 3. If 2nd retest fails, replace PCA.
  • Page 65 Failed Code Error Name Error Level Actions Component E-36 ERR_MOTOR_BLOCKED CONTINUE 1. Air Path 1. Clear air path including filter and test. _OUTLET 2. PCA 3. Blower Box 2. If test fails, replace PCA and retest. 3. If retest fails, replace blower box and retest.
  • Page 66 Failed Code Error Name Error Level Actions Component E-71 ERR_PSENS_STATUS_B REBOOT 1. If error was NOT Last Stop Error, clear error log ITS_ERROR and test. 2. If error was Last Stop Error, replace PCA and test. E-72 ERR_PSENS_UNABLE_T REBOOT 1. If error was NOT Last Stop Error, clear error log O_OBTAIN_BUS and test.
  • Page 67 Failed Code Error Name Error Level Actions Component E-87 ERR_FLOW_SENSOR_B CONTINUE 1. Clear error log and test. 2. If the test fails or the error reoccurs, replace the PCA and retest. E-93 ERR_RTC_VALUE CONTINUE 1. Clear error log, set the RTC and test.
  • Page 68 Failed Code Error Name Error Level Actions Component E-131 ERR_WIN_WDOG_TIME ABORT 1. If error was NOT Last Stop Error, clear error log and test. 2. If error was Last Stop Error, replace PCA and test. 1. If error was NOT Last E-132 ERR_WIN_WDOG_TEST REBOOT...
  • Page 69 Failed Code Error Name Error Level Actions Component E-173 ERR_BT_STACK_MASK_ CONTINUE 1. Replace PCA and test. DATA_WR_FAIL 1. Replace PCA and test. E-174 ERR_BT_RADIO_EN_DE CONTINUE N_TX 1. Replace PCA and test. E-175 ERR_BT_RADIO_EN_DE CONTINUE N_RX 1. Replace PCA and test. E-176 ERR_BT_RADIO_BIST_F CONTINUE...
  • Page 70 Failed Code Error Name Error Level Actions Component E-191 ERR_ALS_BIST CONTINUE 1. Clear error log and test. 2. If the retest fails or the error reoccurs, replace the PCA and retest. 1. Remove and reinsert the E-192 ERR_USB_DEVICE_LOS REBOOT Accessory accessory module.
  • Page 71 Failed Code Error Name Error Level Actions Component E-220 ERR_MOTOR_ID_TIMEO REBOOT 1. If error was NOT Last Stop Error, clear error log and test. 2. If error was Last Stop Error, replace PCA and test. 1. If error was NOT Last E-221 ERR_MOTOR_SHUNT_S REBOOT...
  • Page 72 Failed Code Error Name Error Level Actions Component E-225 ERR_CRITICAL_HIGH_P STOP 1. Air Path 1. If applying negative pressure to the unit remove RESSURE 2. PCA that first and retest. 3. Blower Box 2. Load latest software version if not up to date. 3.
  • Page 73 Failed Code Error Name Error Level Actions Component E-241 ERR_INVALID_COMPLIA CONTINUE 1. Clear error log and retest. NCE_SIZE 1. Clear error log and test. E-250 ERR_BAROMETRIC_CO CONTINUE 2. If the test fails or the error reoccurs, replace the PCA and retest. 1.

  • Page 74: Failure Mode Troubleshooting

    6.6 Failure Mode Troubleshooting The following table can be used as a guide to aid in troubleshooting the device based on the potential prob- lem. All issues may not be presented here. Problem/Failure Mode Possible Cause Steps to Take Power Supply Related Error •...
  • Page 75 Problem/Failure Mode Possible Cause Steps to Take General Noise • • Humidifier Seals are Make sure all Seals are damaged or not seated seated. • • Humidifier Back Panel Make sure PCA is aligned on not secure seals. • • Enclosures not secure Make sure enclosures are secure.
  • Page 76 Problem/Failure Mode Possible Cause Steps to Take Airflow is Warm • • The air filters may be Make sure there is no debris dirty in the filters. • • The device may be Make sure the device is operating in direct properly ventilated.
  • Page 77 Problem/Failure Mode Possible Cause Steps to Take Ramp Does Not Work • • Mechanical button failure Check for physical damage or enclosure separation. • Ramp feature not • enabled Ensure ramp feature is enabled. • Ramp pressure set the • same as prescribed Ensure ramp pressure is set pressure...
  • Page 78 Problem/Failure Mode Possible Cause Steps to Take Can’t Change Humidity Settings • • User perception - can Activate therapy and verify the only change setting when settings change. therapy is active. You • Verify the dial functions. cannot change the •...
  • Page 79 Problem/Failure Mode Possible Cause Steps to Take Tank Runs Out of Water • • Settings are at max for Examine Humidifier settings. an unsuitable • Check for damage to the environment Tank. • User has high mask leak • Tank is leaking Humidifier Lid Won’t Latch/Open •...

  • Page 80: Device Alarms

    6.7 Device Alarms There are two types of alarms: • High priority - Require immediate response by the operator. • Medium priority - Require prompt response by the operator. When an alarm condition occurs: • The audio pause icon appears and the control dial LED indicator lights. •...

  • Page 81: Alarm And Alert Audible Indicators

    6.10 Alarm and Alert Audible Indicators An audible indicator sounds when any of the following occurs: • A device inoperative condition occurs • The blower is on and a power failure occurs • An alarm condition occurs • An alert message appears on the screen Alarm/Alert Type Audible Indicator Device Inoperative...

  • Page 82: Silencing An Alarm

    6.11 Silencing an Alarm You can temporarily silence an alarm by pressing the control dial. The alarm is silenced for 60 seconds and then sounds again if the cause of the alarm has not been corrected. If another alarm occurs while the silence period is active, the audible alarm portion of the new alarm will not sound until the silence period expires.

  • Page 83: Alarm Summary Table

    6.14 Alarm Summary Table The following table summarizes the alarms. See Alarm and alert LED indicators and Alarm and alert audi- ble indicators earlier in this chapter for LED and audible indicators for each alarm type. Alarm Priority Device Action User Action High Operates...
  • Page 84 Alarm Priority Device Action User Action High Operates This alarm occurs when the patient circuit is disconnected or has a large leak. Press the control dial to silence the alarm. Press the control dial again to acknowledge and re- move the alarm from the screen.
  • Page 85 Alarm Priority Device Action User Action Loss of power Power failure Shuts down Press the control dial to si- lence the alarm. Remove (blank screen) your mask. Check your power connections. Make sure there is power at the outlet or power source. High Operates This could be caused by an...
  • Page 86 Alarm Priority Device Action User Action Medium Operates Press the control dial again to acknowledge and remove the alarm from the screen. Re- move your mask. Remove power from the device. Con- firm a compatible Philips Respironics power supply is attached.

  • Page 87: Alert Summary Table

    6.15 Alert Summary Table The following table summarizes the alerts. See Alarm and alert LED indicators and Alarm and alert audi- ble indicators for LED and audible indicators for each alert type. The screen below is an example of an alert screen.
  • Page 88 Alert Icon Priority Description User Action Pair? Prompts to accept or Rotate the control dial to Status Yes/No decline pairing to a accept pairing (Yes), or decline (No), then press the Bluetooth compatible control dial to confirm device. selection. Selecting Yes opens the Bluetooth passkey screen.
  • Page 89 Incompatible inlet. Confirm a compatible power supply, or Philips Respironics power power cord is not fully supply is attached. Switch to inserted into device’s compatible power supply if power inlet.
  • Page 90 Confirm power cord is full ble power supply is at- inserted into device’s power tached. inlet. Confirm a compatible Incompatible power Philips Respironics power supply, or power supply is attached. Switch cord is not fully to compatible power supply inserted into device’s if needed.

  • Page 91: Chapter 7. Repair & Replacement

    Chapter 7. Repair & Replacement This Chapter illustrates the names and locations of the replaceable components in the DreamStation devices. Prior to executing the repair and replacement procedures, the troubleshooting procedures must first be exe- cuted. Refer to Chapter 6 for troubleshooting procedures. IMPORTANT NOTE The device must be tested after any repairs are made.

  • Page 92: Replacement Part (Rp) Kits

    7.1 Replacement Part (RP) Kits DESCRIPTION RP KIT NUMBER Accessory Module Flip Door 1115485 SD Cover Flip Door 1115542 Upper Enclosure 1115486 (Includes Keypad) UI Panel Assembly, BiPAP S/T 1130519 UI Panel Assembly, BiPAP AVAPS 1130520 UI Knob 1130437 PCA, BiPAP S/T 25 – IN, DE, CN 1130523 1130734 PCA, BiPAP S/T 30 –...
  • Page 93 DC Jack Color Insert 1121555 Rear Panel 1115543 Rear Panel O-Ring 1121559 Bottom Enclosure 1130435 Warning Label, DOM 1121556 Warning Label, IN/LA 1132247 Warning Label, AU/FR 1132278 Warning Label, CA 1125963 Power Supply, 80W 1118499 Travel Power Supply, DOM, 65W 1120136 Travel Power Supply, EU, 65W 1127194...

  • Page 94: Replacement Instructions

    7.2 Replacement Instructions Prior to executing repair and replacement procedures, device troubleshooting must be performed. Refer to Chapter 6 for troubleshooting procedures. Replacing the Accessory Module and SD Flip Doors Included in Kit Tools Required • • Accessory Module Flip None Accessory Module Flip Door...

  • Page 95: Replacing The Sd Card

    Replacing the SD Card To remove the SD Card: 1. Press the SD Card in to release. 2. Pull the SD Card out of the device. To install the SD Card: 1. Slide the SD Card into the slot until it locks into place. Replacing the Upper Enclosure/Keypad: Included in Kit Tools Required...
  • Page 96 Torque screws to 6 IN-LB when installing Upper Enclosure To install the Upper Enclosure/Keypad: 1. Align and snap the Upper Enclosure into place. 2. Secure the Upper Enclosure to the Bottom Enclosure using the two # 4 x 1/2” (torque to 6 IN-LB). 3.

  • Page 97: Replacing The Ui Panel

    Replacing the UI Panel Included in Kit Tools Required UI Panel Assembly • • UI Panel Torx Screwdriver (T10 is recommended) To remove the UI Panel: 1. Remove all components as instructed in the previous sections. 2. Lift the UI Panel away from the device. Note: the alarm ribbon cable may detach when you pull the UI Panel away from the device.

  • Page 98: Replacing The Pca

    GOOD GOOD Replacing the PCA Included in Kit Tools Required • • Torx Screwdriver (T10 is recommended) • # 4 x 1/2” screws (qty 2) To remove the PCA: 1. Remove all components as instructed in the previous sections. 2. Remove the two # 4 x 1/2” screws that secure the PCA to the Blower Cap using a T-10 Torx driver. 3.
  • Page 99 To install the PCA: 1. Connect the DC and Blower Connectors to the PCA Connectors. 2. Seat the PCA onto the Blower Cap standoff and screw bosses, ensuring to position the Humidifier Connector located on the PCA into the groove of the Rear Panel, and positioning the Flow and Pres- sure Sensors into the Seals (refer to the illustrations below).
  • Page 100 Align humidifier connector into Rear Panel groove Align screw bosses Align standoff Underside of PCA: Position Flow and Pres- sure Sensors into Seals CAUTION The PCA’s Flow and Pressure Sensors must be in proper alignment with the Seals. Otherwise, the device will not operate properly. 1127179, V .

  • Page 101: Replacing The Flow And Pressure Sensor Seals

    Replacing the Flow and Pressure Sensor Seals Included in Kit Tools Required Flower Sensor Seal • • Flower Sensor Seal Torx Screwdriver (T10 is recommended) Pressure Sensor Seal • Pressure Sensor Sea To install the Seals: 1. Remove all components as instructed in the previous sections. 2.

  • Page 102: Replacing The Blower Upper Cap

    Replacing the Blower Upper Cap Included in Kit Tools Required Blower Upper Cap • • Blower Upper Cap Torx Screwdriver (T10 is recommended) • # 4 x 1/2” screws (qty 4) • Flathead Screwdriver To remove the Blower Upper Cap: 1.
  • Page 103 To install the Blower Upper Cap: 1. Align the Blower Cap with the screw holes on the Blower Box Assembly, verifying the Blower Cap is fully seated. 2. Secure the Blower Cap to the Blower Box Assembly using the four # 4 x 1/2” screws (torque to 2.5 IN-LB).

  • Page 104: Replacing The Blower, Blower Box Assembly, And Rear Panel

    Replacing the Blower, Blower Box Assembly, and Rear Panel Included in Kit Tools Required • • Blower Torx Screwdriver (T10 is Blower Assembly, Moog recommended) • Blower Box Assembly Blower Box Assembly • Rear Panel Rear Panel Assembly • Rear Panel O-Ring To remove the Blower, Blower Box Assembly and Rear Panel: 1.
  • Page 105 Remove ferrite to disconnect wire harness O-Ring can be replaced if needed 6. Remove the Blower wire ferrite from the Blower Box Assembly by pushing the ferrite straight down. 7. Unwrap the wire around the Blower Box Assembly. 8. Pull the wire grommet out of the Blower Box Assembly groove. Push ferrite down Grommet 9.
  • Page 106 To install the Blower, Blower Box Assembly and Rear Panel: 1. Position the Blower inside the Blower Box Assembly so that the Blower Outlet Seal and Blower Isolators are aligned in their grooves. CAUTION • The Blower with the Isolators attached should be rested inside the Blower Box. Do not press down on the Blower after installation.
  • Page 107 4. Verify the Blower Outlet Seal is properly seated. Seat in groove GOOD – Seated BAD – Not Seated 5. Route the Blower wires as shown below. 1127179, V . 02 PAP S/T AVAPS S & T REAM TATION ERVICE ECHNICAL EFERENCE ANUAL...
  • Page 108 Slide ferrite up to the top of the groove 6. Snap DC Cable ferrite into groove on Rear Panel. Snap ferrite into groove 1127179, V . 02 PAP S/T AVAPS S & T REAM TATION ERVICE ECHNICAL EFERENCE ANUAL...
  • Page 109 7. Attach Rear Panel onto Blower Box Assembly. Note: Ensure O-Ring is properly seated. GOOD GOOD 1127179, V . 02 PAP S/T AVAPS S & T REAM TATION ERVICE ECHNICAL EFERENCE ANUAL...

  • Page 110: Replacing The Blower Outlet Seal And Blower Isolators

    8. Place the Blower Box Assembly with the Real Panel attached into the Bottom Enclosure. 9. Secure the Blower Box Assembly with the two # 4 x 1/2” screws (torque to 6 IN-LB). 10. Assemble the remainder of the device as instructed in the previous sections. Torque screws to 6 IN-LB when installing the Blower Replacing the Blower Outlet Seal and Blower Isolators...
  • Page 111 Blower Isolators Blower Outlet Seal To install the Blower Outlet Seal and Blower Isolators: 1. Position the Blower Outlet Seal and Blower Isolators on the Blower and verify they are fully seated. 2. Assemble the remainder of the device as instructed in the previous sections. GOOD CAUTION The Isolators are prone to falling off the Blower.

  • Page 112: Replacing The Dc Power Cable And Dc Jack Color Insert

    Replacing the DC Power Cable and DC Jack Color Insert Included in Kit Tools Required DC Power Cable • • DC Power Cable Torx Screwdriver (T10 is recommended). DC Jack Color Insert • DC Jack Color Insert To remove the DC Power Cable and DC Jack Color Insert: 1.

  • Page 113: Replacing The Bottom Enclosure

    Replacing the Bottom Enclosure Included in Kit Tools Required Bottom Enclosure • • Bottom Enclosure Torx Screwdriver (T10 is recommended). Warning Label • Warning Label To remove the Bottom Enclosure: 1. Remove all components as instructed in the previous sections (it is not required to remove the Blower Upper Cap, Blower or Blower Isolators –...

  • Page 114: Creating The Serial/Model Number Label

    7.3 Creating the Serial/Model Number Label In the case that the Bottom Enclosure of the PAP device or Bottom Cover of the Humidifier is replaced during service, or if there is damage to the labels, all information on the serial/model number labels is required to be duplicated in order to maintain proper traceability.

  • Page 115: Software

    Software Recommended Software: Loftware Software and Print Key (Fees Apply) • For a full detailed list of Loftware supported printers and fees, please refer to http://www.loft- ware.com/support/tech_printers.cfm • For software support, visit their website at www.loftware.com Label Printing Options There are three different options available for reprinting the serial number label. One of these three options must be used.

  • Page 116: Chapter 8. Humidifier Repair And Replacement

    Chapter 8. Humidifier Repair and Replacement This Chapter illustrates the names and locations of the replaceable components in the DreamStation Humidi- fiers. Prior to executing these procedures, troubleshooting procedures must first be executed (refer to Chap- ter 6 for troubleshooting procedures. IMPORTANT NOTE The device must be tested after any repairs are made.

  • Page 117: Humidifier Replacement Part (Rp) Kits

    8.1 Humidifier Replacement Part (RP) Kits DESCRIPTION RP KIT NUMBER Dry Box Assembly 1120668 Dry Box Inlet Seal 1120613 Flip Lid/Bottom Assembly 1120873 Flip Lid Seal 1120617 Flip Lid Latch 1121569 Back Panel 1120614 Lifting Tray 1121570 Bottom Cover 1120616 Heat Shield 1122522 Heater Plate O-Ring...

  • Page 118: Replacement Instructions

    8.2 Replacement Instructions Prior to executing repair and replacement procedures, device troubleshooting must be performed. Refer to Chapter 6 for troubleshooting procedures. Replacing the Water Tank Assembly Included in Kit Tools Required • • Tank Assembly None Tank Assembly To remove the Water Chamber Assembly: 1.

  • Page 119: Replacing The Flip Lid And Dry Box Inlet Seals

    Replacing the Flip Lid and Dry Box Inlet Seals Included in Kit Tools Required • • Flip Lid Seal None Flip Lid Seal • Dry Box Seal Dry Box Seal To remove the Seals: 1. Remove the Water Tank as instructed in the previous section (not required for Flip Lid Seal replace- ment only).

  • Page 120: Replacing The Dry Box Assembly

    Dry Box Seal To Install the Seals: 1. Press the Seals into the place as shown above. 2. Press the Tank Top Seal onto the Patient Outlet Swivel Clip. Note: The Seal only aligns one way. Be sure to press the Seal the whole way around to ensure it is seated properly.

  • Page 121: Replacing The Wire Guard

    To Install the Dry Box Assembly: 1. Position the Dry Box into the Bottom Assembly. 2. Snap the Dry Box into place and verify it is fully seated. 3. Assemble the remainder of the device as instructed in the previous sections. Replacing the Wire Guard Included in Kit Tools Required...
  • Page 122 To Install the Wire Guard: 1. Position the top of the Wire Guard into the Flip Lid groove and then position the bottom of the Wire Guard into place, but do not fully seat Wire Guard. 2. Verify wires are properly seated by wiping your finger across Wire Gard in location shown in the illus- tration below.
  • Page 123 1127179, V . 02 PAP S/T AVAPS S & T REAM TATION ERVICE ECHNICAL EFERENCE ANUAL...

  • Page 124: Replacing The Back Panel Assembly

    Replacing the Back Panel Assembly Included in Kit Tools Required • • Back Panel Assembly Torx Screwdriver (T10 is Back Panel Assembly recommended) • # 4 x 1/2” screws (qty 5) To remove the Back Panel Assembly: 1. Remove the Water Chamber Assembly (refer to previous corresponding section). 2.

  • Page 125: Replacing The Flip Lid Latch

    Replacing the Flip Lid Latch Included in Kit Tools Required • • Flip Lid Latch Torx Screwdriver (T10 is Flip Lid Latch recommended) To remove the Flip Lid Latch: 1. Remove the Back Panel Assembly and open the Flip Lid (refer to previous corresponding section). Push up on the 2 Latch tabs and pull the Latch out of the Humidifier Assembly.

  • Page 126: Replacing The Lifting Tray

    Replacing the Lifting Tray Included in Kit Tools Required • • Lifting Tray None Lifting Tray To remove the Lifting Tray: 1. Push out one side of the Lifting Tray out of the groove, and then repeat on the other side. 1127179, V .
  • Page 127 2. Lift up the Lifting Tray and push one side inward out of the groove, and then repeat on the other side. To install the Lifting Tray: 1. Place one end of the Lifting Tray back into the cut-out groove, and then repeat on other side. Note: The Tray will only fit one way into the groove.
  • Page 128 Pull back Tray and align into groove 1127179, V . 02 PAP S/T AVAPS S & T REAM TATION ERVICE ECHNICAL EFERENCE ANUAL...

  • Page 129: Replacing The Bottom Cover

    Replacing the Bottom Cover Included in Kit Tools Required • • Bottom Cover Torx Screwdriver (T15 is Bottom Cover recommended) • # 6 x 1/4” screws (qty 4) To remove the Bottom Cover: 1. Turn the Humidifier over. 2. Remove the four # 6 x 1/4” screws securing the Bottom Cover to the Bottom Assembly. 3.

  • Page 130: Replacing The Heat Shield

    Replacing the Heat Shield Included in Kit Included in Kit Tools Required • • Heat Shield Torx Screwdriver (T15 is Heat Shield recommended) Route wires as shown To remove the Heat Shield: 1. Remove the Bottom Cover as instructed in the previous section. 2.

  • Page 131: Replacing The Heater Plate O-Ring

    Replacing the Heater Plate O-Ring Included in Kit Included in Kit Tools Required • • Heater Plate O-Ring Torx Screwdriver (T15 is Heater Plate O-Ring recommended) Heater Plate O-Ring To remove the Heater Plate O-Ring: 1. Remove the Bottom Cover as instructed in the previous section. 2.

  • Page 132: Replacing The Bottom/Flip Lid Assembly

    Replacing the Bottom/Flip Lid Assembly Included in Kit Included in Kit Tools Required • • Bottom/Flip Lid Assembly Torx Screwdriver (T10 and Bottom/Flip Lid Assembly T15 is recommended) • Dry Box • Heater Plate • Heater Plate O-Ring • Heat Shield •...
  • Page 133 Removing/installing the Bottom/Flip Lid Assembly: 1. Remove the Tank Assembly, Flip Lid Seal, Dry Box Seal, and the Back Panel Assembly (refer to pre- vious corresponding sections). 2. Install Back Panel Assembly, Flip Lid Seal, Dry Box Seal and Tank Assembly onto the new Bot- tom/Flip Lid Assembly as instructed in the previous sections.
  • Page 134 6. Install heated tube wire connector into ISO Port, and verify it is connected the whole way as shown below. 7. Install the ISO Port into the top opening of ISO Port Cover and snap into place. 1127179, V . 02 PAP S/T AVAPS S &...
  • Page 135 8. Verify the ISO Port is installed properly and flush with the ISO Port Cover. 9. Verify correct orientation of ISO Port assembly as shown below (port facing toward front of unit) and fully install ISO Port assembly into Flip Lid. 1127179, V .
  • Page 136 10. Open the Flip Lid and ensure there are no pinched wires. 11. Route the wires flat as shown, and ensure they are in the middle within the grooves. 12. Install the Wire Guard. 1127179, V . 02 PAP S/T AVAPS S &...

  • Page 137: Chapter 9. Testing

    Chapter 9. Testing Final testing of a device is a mandatory requirement after any repairs are made to the device, or if the device enclosure has been opened for any reason. NOTE Testing must occur in a lab equipment environment only. 9.1 Required Equipment Hardware: •...

  • Page 138: Testing Prerequisites

    Software (download and install from my.respironics.com): • NI LabVIEW 2014 Support Package • DreamStation Family Drivers, Version 1.0 or higher • DreamStation Test Executive, Version 1.0 or higher (required if the DreamStation Field Service Applica- tion is not already installed on your PC) •...

  • Page 139: Windows 10 Dreamstation Family Drivers Installation

    Windows 10 DreamStation Family Drivers Installation Follow these steps to disable/enable signed driver enforcement on a Windows 10 system, so that the Dream- Station Family Drivers can be installed. Disabling Driver Signature Enforcement in Windows 10: 1. Locate the Windows Command Prompt by typing in “CMD” in the Windows search engine (aka Cor- tana), then right click on the Command Prompt and select “Run as Administrator”.

  • Page 140: Final Testing Procedure

    9.5 Final Testing Procedure 1. The following icon will be created on your desktop. Launch the Test Executive from your desktop by double-clicking on the icon. 2. A window will popup asking for a user name and password. These are not required. Select OK to pro- ceed.
  • Page 141 4. Select the DreamStation ASV_NIV Service Test.seq file, then select OK to load it into the test execu- tive. 5. You will see the test files loaded into the software. 6. Connect the Serial Communication Cable to COM 1 of your PC. 1127179, V .
  • Page 142 7. Select “Test UUT”. 8. Follow the prompts and enter in the device identification information (serial/model number, etc). 9. Follow the next prompt by connecting all hardware items listed and as shown below, and then select OK. The Serial-USB Cable must be connected to COM 1. The Micro-USB Cable can be connected to any other USB COM port.
  • Page 143 10. Continue to follow all prompts. 11. Once the pressure and flow testing is complete, the following prompt will be displayed. 12. Connect the Humidifier and Heated Tube as shown below, then select OK. 13. Continue to follow all prompts until the test is complete. 14.
  • Page 144 1127179, V . 02 PAP S/T AVAPS S & T REAM TATION ERVICE ECHNICAL EFERENCE ANUAL...

This manual is also suitable for:

Dreamstation bipap s/t

Table of Contents
