System Contents

Your BiPAP autoSV Advanced System One may include the following items:
• Device
• User manual
• Carrying case
• Flexible tubing
• Power cord
• Power supply (60W
note: If any of these items are missing, contact your home care provider.

System overview

The BiPAP autoSV Advanced System One device is intended to augment your breathing by supplying pressurized air
through a circuit. It senses your breathing effort by monitoring airflow in the circuit and adjusts its output to assist in
inhalation and exhalation. This therapy is known as Bi-level ventilation. Bi-level ventilation provides a higher pressure,
known as IPAP (Inspiratory Positive Airway Pressure), when you inhale, and a lower pressure, known as EPAP
(Expiratory Positive Airway Pressure), when you exhale. The higher pressure makes it easier for you to inhale, and
the lower pressure makes it easier for you to exhale.
When prescribed, the device can also provide features to help make your therapy more comfortable. The ramp
function allows you to lower the pressure when trying to fall asleep. The air pressure will gradually increase until the
prescription pressure is reached. Additionally, the Bi-Flex comfort feature provides increased pressure relief during
the expiratory phase of breathing.
Several accessories are also available for use with the device. Contact your home care provider to purchase any
accessories not included with your system.
This figure illustrates some of the device features, described in the following table.
D f
evice eature
Air Outlet Port (conical, 22 mm)
SD Card (Accessory) Slot
SD Card Cover
Power Inlet
Filter Area
Side Cover (optional)
User Manual
1091398, or 80W 1091399)
Air Outlet Port
Tab
Side Cover
Connect the 15 or 22 mm Philips Respironics flexible tubing here.
If applicable, insert the optional accessory SD card here.
If applicable, the optional accessories such as a Link Module or Modem can be installed
here. Refer to the instructions supplied with the accessory. When not using an accessory,
this cover must be in place on the device.
Connect the power cord here.
A reusable, gray foam filter must be placed in the filter area to screen out normal household
dust and pollens. A white ultra-fine filter can also be used for more complete filtration of
very fine particles.
If using a humidifier with the device, this side cover can be easily removed with the release
tab before attaching the humidifier. Refer to the humidifier manual.
• SD card
• Side cover panel (optional)
• Reusable gray foam filter
• Disposable ultra-fine filter (optional)
• Humidifier (optional)
SD Card (Accessory) Slot
Filter Area
D
eScription
SD Card Cover
Power Inlet
