Westermo MCW-211 Series User Manual

Industrial ethernet media converter
Hide thumbs Also See for MCW-211 Series:

Advertisement

Quick Links

www.westermo.com
MCW-211 Series
Industrial Ethernet Media Converter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCW-211 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Westermo MCW-211 Series

  • Page 1 MCW-211 Series Industrial Ethernet Media Converter...
  • Page 2 6645-2204...
  • Page 3: General Information

    Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused.
  • Page 4: Safety And Regulations

    Safety and Regulations Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially Possible death or Major damage to the hazardous situation major injury product...
  • Page 5 WARNING - PROTECTIVE FUSE The power supply wiring must be sufficiently fused. It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personell. 6645-2204...
  • Page 6 WARNING - REDUCE THE RISK OF FIRE To reduce the risk of fire, use only telecommunication line cords with a cable diameter of AWG 26 or larger. Regarding power cable dimensions, see Interface Specifications. CAUTION - CLASS 1 LASER PRODUCT Do not look directly info a fibre optical port or any connected fibre, although the product is designed to meed the Class 1 Laser regulations and complies with 21 CFR 1040.10 and 1040.11.
  • Page 7: Care Recommendations

    If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo technical support.
  • Page 8: Simplified Eu Declaration Of Conformity

    10/100Base-T/TX: 1 port 100Base-FX: 1 port Simplified EU declaration of conformity Hereby, Westermo declares that the equipment is in compliance with applicable EU directives. The full EU declaration of conformity and other detailed information are available at the respective product page at www.westermo.com/support/product-support.
  • Page 9: Type Tests And Environmental Conditions

    Type tests and environmental conditions Electromagnetic Compatibility Phenomena Test Description Level EN 61000-4-2 Enclosure contact ± 4 kV Enclosure air ± 8 kV RF field AM modulated IEC 61000-4-3 Enclosure 10 V/m 80% AM (1 kHz), 30 – 2700 MHz Fast transient EN 61000-4-4 Signal ports...
  • Page 10: Interface Specifications

    Interface specifications Power Rated voltage 12 to 48 VDC Operating voltage 10 to 60 VDC Rated current 200 mA @ 12 VDC 100 mA @ 24 VDC 50 mA @ 48 VDC Rated frequency Inrush current I2t 0.03 A²s @ 12 VDC Startup current* 0.75 A peak Polarity...
  • Page 11 Location of interface ports and LEDs LED Indicators DIP switches are accessible under the lid Ethernet TX – RJ-45 Position Direction* Description In/Out In/Out TD– In/Out – – – – In/Out RD– – – – – * Direction relative this product Ethernet FX –...
  • Page 12 Fibre optic power budget Model MCW-211-MM MCW-211-SM MCW-211-SM MCW-211-SM SC15 LC15 LC40 Transmitted 1310 nm 1310 nm 1310 nm 1310 nm wavelength Min. output –19 dBm –15 dBm –15 dBm –5 dBm power, transmitter Max. output –12 dBm –8 dBm –8 dBm 0 dBm power,...
  • Page 13: Led Indicators

    LED indicators LED indicators are available on the front panel and on the RJ-45 TX connector. Status Description Internal power, initialising OK Slow flash Initialisation progressing Fast flash Initialisation error LINK TX No Ethernet link TX Good Ethernet link TX Flash Ethernet data is transmitted or received on TX interface...
  • Page 14: Installation

    Installation Mounting / Removal WARNING - HAZARDOUS VOLTAGE Do not open an energized product. Hazardous voltage may occur when connected to a power supply. CAUTION - ELECTROSTATIC DISCHARGE (ESD) Prevent electrostatic discharge damages to internal electronic parts by discharging your body to a grounding point (e.g. use a wrist strap).
  • Page 15: Dip Switch Settings

    Configuration DIP switches are accessible under the lid on top of the product. DIP switches are used to configure the product. DIP-switch settings WARNING - HAZARDOUS VOLTAGE Do not open an energized product. Hazardous voltage may occur when connected to a power supply. CAUTION - ELECTROSTATIC DISCHARGE (ESD) Prevent electrostatic discharge damages to internal electronic parts by discharging your body to a grounding point (e.g.
  • Page 16 TX Port settings Flow control setting Auto-negotiation and Flow control auto MDI / MDI-X disabled 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 disabled TX port Auto-negotiation and Flow control auto MDI / MDI-X enabled 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...
  • Page 18 Westermo • SE-635 35 Stora Sundby, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com REV. F 6645-2204 2021-01 Westermo Network Technologies AB, Sweden...
