User Manual
RIGOL
Publication number DS5-040501
May 2004
DS-5000 Series Digital Storage Oscilloscope
DS 5000CA, DS 5000C, DS 5000MA, DS 5000M
© Copyright Rigol Electronic Co. Ltd. 2004
All Rights Reserved

Advertisement

Table of Contents
loading

Related Manuals for Rigol DS-5000 Series

Summary of Contents for Rigol DS-5000 Series

  • Page 1 User Manual RIGOL Publication number DS5-040501 May 2004 DS-5000 Series Digital Storage Oscilloscope DS 5000CA, DS 5000C, DS 5000MA, DS 5000M © Copyright Rigol Electronic Co. Ltd. 2004 All Rights Reserved...
  • Page 3 RIGOL Copyright © RIGOL ELECTRONIC Co. Ltd. 2003 All Rights Reserved. Rigol products are covered by P.R. China and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specification and price change privileges reserved.
  • Page 4 Provide Proper Ventilation. Refer to the manual’s installation instructions for details on installing the product so it has proper ventilation. Do not operate in wet/damp conditions Do not operate in an explosive atmosphere Keep product surfaces clean and dry Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 5 CAUTION indicates a hazard to property including the product . Symbols on the Product. These symbol s may appear on the product : DANGER ATTENTION Protective Frame Earth High Voltage Refer to Manual Conductor or Chassis Terminal Terminal Terminal Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 6 RIGOL General-Purpose Oscilloscopes The RIGOL DS5000-Series Digital Storage Oscilloscopes offer exceptional waveform viewing and measurements in a small, lightweight package. The DS5000 series are suited for production, field service, research and design labs, applications involving digital circuit test and troubleshooting, and education applications.
  • Page 7 • Warranty and Registration Form Options available 　 EM5-CM Communications function (RS232 and GPIB) Pass/Fail Output Function • 　 EM5-COM Communications modules(RS232、GPIB) • 　 EM5-P/F Pass/Fail Output Function • 　 Accessories Bag: PA-5000 • Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 8: Table Of Contents

    Example 5: Making Cursor Measurements ............3-6 Example 6: The application of the X-Y operation ...........3-8 Example 7: T iggering on a Video Signal............. 3-10 Example 8: FFT Cursor measurement............3-12 Example 9: Pass/Fail Test ................3-13 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 9 CHAPTER 5: SUPPORT & SERVICE ..............5-1 CHAPTER 6: REFERENCE ................6-1 Appendix A: Specifications ................6-1 Appendix B: DS5000-Series Accessories ............6-6 Appendix C: General Care and Cleaning ............6-7 Index........................ i Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 11: Chapter 1: The Oscilloscope At A Glance

    To inspect the instrument To take a functional check To compensate probes To display a signal automatically To set up the vertical window To set up the horizontal system To trigger the oscilloscope Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 12: The Front Panel And The User Interface

    Horizontal buttons: Associate with horizontal MENU. Trigger buttons: Associate with trigger MENU, instant action to set 50% trigger level and FORCE trigger. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 13 Coupling is a soft button. The word Coupling is on the top of the menu on the screen, directly on the left of an unlabeled soft button (which is also gray). Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 14 Execute status Channel 1 symbol Operation menu Channel 2 symbols Waveform display Timebase CH1 status CH2 status Trigger status position Figure 1-3 User Interface Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 15: To Inspect The Instrument

    If the shipping container is damaged, or the cushioning materials show signs of stress, notify the carrier as well as your RIGOL sales office. Keep the shipping materials for the carrier’s inspection. The RIGOL office will arrange for repair or replacement at RIGOL’s option without waiting for claim settlement.

  • Page 16: To Take A Functional Check

    CH 1 BNC, push to connect, and twist to the right to lock the probe in place. Attach the probe tip and reference lead to the PROBE COMP connector. Figure 1-5 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 17 (approximately 3 V at 1 kHz peak- to- peak). ④ Push the OFF button to turn off channel 1, push the CH 2 button to turn on channel 2, repeat steps 2 and 3. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 18: To Compensate Probes

    WARNNING: To avoid electric shock while using the probe, be sure the perfection of the insulated cable, and do not touch the metallic portions of the probe head while it is connected with a voltage source. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 19: To Display A Signal Automatically

    When you press the AUTO button, the oscilloscope changes the front-panel setup to display the signal. It automatically adjusts the vertical and horizontal scaling, as well as the trigger coupling, type, position, slope, level, and mode settings. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 20: To Set Up The Vertical Window

    If the channel is AC coupled, the DC component of the signal is blocked, allowing you to use greater sensitivity to display the AC component of the signal. 1-10 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 21 Vernier Shortcut key You can set the Coarse/Fine vertical control not only on the Volts/Div item in the CH1 or CH2 menus, but also by pressing the vertical SCALE knob. Copyright 2004 Rigol Electronic 1-11 User Manual for DS5000 Series...

  • Page 22: To Set Up The Horizontal System

    Delayed Scan mode and it is equal to the following menu operations, MENU→Delayed. 2 The horizontal POSITION knob adjust horizontally signal on waveform window 1-12 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 23 Horizontal position control Trig-Offset: In this setting, the trigger’s position will be changed horizontally when you turn the POSITION knob. Holdoff: Adjust Holdoff time when you turn the POSITION knob. Copyright 2004 Rigol Electronic 1-13 User Manual for DS5000 Series...

  • Page 24: To Trigger The Oscilloscope

    Second, a line is displayed showing the location of the trigger level (as long as AC coupling or low frequency reject are not selected). 1-14 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 25 4 Press FORCE Press this button starts an acquisition regardless of an adequate trigger signal. This button has no effect if the acquisition is already stopped. Copyright 2004 Rigol Electronic 1-15 User Manual for DS5000 Series...

  • Page 27: Chapter 2: Operating Your Oscilloscope

    How to set up the display system How to save and recall waveforms or setups How to set up utility How to measure automatically How to measure with cursors How to use instant execute buttons Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 28: Understand The Vertical System

    Restore to original display of the waveform. 1MΩ Set 1MΩ input impedance Input 50Ω Set 50Ω input impedance NOTE: The input impedance select function (1MΩ/50Ω) is only provided in certain models. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 29 Press CH1→Coupling→DC, to set CH1’s coupling as “DC”. In this setting, it passes both AC and DC components of the input signal. The waveform is displayed as Figure 2-2: Set to DC Coupling Figure 2-2 DC status Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 30 RIGOL Press CH1→Coupling→GND, to set CH1’s coupling as “GND”. In this setting, it disconnects the input signal. The screen displays as Figure 2-3: Set to GND Coupling Figure 2-3 GND status Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 31 Press CH1→BW Limit→ON, to set up bandwidth limit to “ON” status. It will reject the frequency component higher than 20MHz. The waveform is displayed as Figure 2-5: Set bandwidth limit to 20M Figure 2-5 Bandwidth limit symbol Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 32 Figure 2-6 gives an example for using a 1000:1 probe and it’s attenuation factor. Probe attenuation factor. Figure 2-6 Status changes with the probe attenuation Table 2-2 Probe attenuation Corresponding factors settings 10:1 100:1 100X 1000:1 1000X Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 33 Figure 2-7 The waveform before filtered Set filter ON Figure 2-8 The waveform after filtered Table2-3 Menu Settings Comments Turn on the digital filter Digital Filter Turn off the digital filter Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 34 It will be helpful when you need to adjust the waveform’s vertical size in smooth steps Set Vernier toFine Symbol for Figure 2-9 “Fine” setting Coarse/Fine Shortcut key: Changing Coarse/Fine function not only by menu but also by pressing vertical SCALE knob Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 35 Figure 2-10 and 2-11 show the changes after inversion. Figure 2-10 Set invert OFF The waveform before inversion Figure 2-11 Set invert ON The waveform after inversion Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 36 Do not use 50Ω with the standard probe. Figure 2-12 1MΩ Impedance Table2-4 50Ω Models Provided DC5202CA, DS5152CA, DS5152C, DS5152MA, DS5152M DS5102CA, DS5102C, DS5062CA, DS5062C, DS5102MA Not provided DS5102M, DS5062MA, DS5062M, DS5042M, DS5022M Copyright 2004 Rigol Electronic 2-10 User Manual for DS5000 Series...
  • Page 37 Define CH1 or CH2 as source A Source B Define CH1 or CH2 as source B Set “ON” to invert the MATH waveform. Invert Restore to original display of the waveform. Copyright 2004 Rigol Electronic 2-11 User Manual for DS5000 Series...
  • Page 38 3 To display FFT waveforms with a large dynamic range, use the dBVrms scale. The dBVrms scale displays component magnitudes using a log scale. 2-12 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 39 It’s normally half of the sample rate. This frequency is called the Nyquist frequency. Frequency above the Nyquist frequency will be under sampled, causing a situation known as aliasing. Copyright 2004 Rigol Electronic 2-13 User Manual for DS5000 Series...
  • Page 40 Select channel for REF Source Save Select reserved waveform as resource of REF Set “ON” to invert the REF waveform. Invert Restore to original display of the waveform. Figure 2-15 2-14 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 41 4. Press save to save the currently displayed waveform as REF. NOTE: 1. The reference function is not available in X-Y mode. 2. You cannot adjust the horizontal position and scale on the reference waveform. Copyright 2004 Rigol Electronic 2-15 User Manual for DS5000 Series...
  • Page 42 No status symbol No status symbol Selected Channel 2 (CH2) No status symbol No status symbol Math Mathematic Selected Math Math operation Math No status symbol (MATH) No status symbol 2-16 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 43 3. Adjust the vertical position and scale only when the waveform is selected. 4. When you change the vertical position, the position message is displayed on the left bottom of the screen. Copyright 2004 Rigol Electronic 2-17 User Manual for DS5000 Series...

  • Page 44: Understand The Horizontal System

    Delayed Scan time base. Horizontal Menu. Press the horizontal MENU button to display the horizontal menu. The settings of this menu are listed in the following table. 2-18 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 45 Adjust Holdoff time Holdoff Trig-offset Reset Adjust to the center Holdoff Reset Reset Hold off time to 100ns ① ② ③ ④ ⑤ Figure 2-15: Status bar and mark for Horizontal control Copyright 2004 Rigol Electronic 2-19 User Manual for DS5000 Series...
  • Page 46 Auto, the instrument enters the rolling acquisition mode. In this mode, the waveform display updates from left to right. There is no trigger or horizontal control of waveforms during rolling mode. 2-20 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 47 Delayed Scan. The symbol in the middle of the screen is the main time base and the symbol on the center bottom is the Delayed Scan time base. 　 Copyright 2004 Rigol Electronic 2-21 User Manual for DS5000 Series...
  • Page 48 Notice the changes in the status bar. Delayed Scan Shortcut Key: Delayed Scan function can be activated not only by menu but also by pressing horizontal SCALE knob. 2-22 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 49 ■ The Automatic Measurements ■ The Cursor Measurements ■ Pass/Fail test ■ REF and MATH Operations ■ The Delayed Scan Mode ■ The Vector Display Mode ■ Horizontal POSITION knob ■ Trigger Controls Copyright 2004 Rigol Electronic 2-23 User Manual for DS5000 Series...
  • Page 50 Holdoff function 3. Adjust horizontal POSITION to change Holdoff time until waveform is stable 4. Push 4 function key can reset the Holdoff time to it’s 100ns minimum value Copyright 2004 Rigol Electronic 2-24 User Manual for DS5000 Series...

  • Page 51: Understand The Trigger System

    FORCE: Starts an acquisition regardless of an adequate trigger signal. This button has no effect if the acquisition is already stopped. MENU: The button that activates the trigger controls menu. Figure 2-19: Trigger controls Copyright 2004 Rigol Electronic 2-25 User Manual for DS5000 Series...
  • Page 52 Acquire waveform when trigger occurred. Single When trigger occurs, acquire one waveform then stop Selects the components of the trigger signal applied Coupling LF Reject to the trigger circuitry HF Reject 2-26 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 53 Inverted Polarity selection. Source-EXT(50Ω): This function is only in models that the bandwidth is higher than 100MHz. And normally used ONLY for a signal source that requires 50Ω termination. Copyright 2004 Rigol Electronic 2-27 User Manual for DS5000 Series...
  • Page 54 RIGOL The figure 2-19 and 2-20 display the waveforms with Line and Field synchronization. Figure 2-19: Line synchronization Figure 2-20: Field synchronization 2-28 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 55 HF Reject Reject DC and Low frequency signals LF Reject Note: the Pulse width adjust range is 20ns ～ 10s. The oscilloscope will be trigged when signal meets the preset condition. Copyright 2004 Rigol Electronic 2-29 User Manual for DS5000 Series...
  • Page 56 AC trigger signal. When AC Line is selected as trigger source, the oscilloscope automatically set coupling to DC, set trigger level to 0v. 2-30 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 57 LF Reject: LF Reject coupling blocks DC component, and attenuates all signal with a frequency lower than 8kHz. HF Reject: HF Reject coupling attenuates all signal with a frequency higher than 150kHz. Copyright 2004 Rigol Electronic 2-31 User Manual for DS5000 Series...
  • Page 58 Everything to the right of the trigger point is called posttrigger information. The amount of delay range (pretrigger and posttrigger information) available is dependent on the sweep speed selected. 2-32 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 59: How To Set Up The Sampling System

    Averages 2 to 256 average times from 2 to 256 Intensity Adjust the analog display intensity < i % > Anti-Aliasing ON Turn on Anti-Aliasing function Turn off Anti-Aliasing function Copyright 2004 Rigol Electronic 2-33 User Manual for DS5000 Series...
  • Page 60 • Select Real-time acquisition to observe the single-shot or pulse signals. Select Equal-Time to observe high frequency repetitive signal. • To reduce the displayed random noise, select the Averages Acquisition. And this 2-34 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 61 The acquisition system does not miss any data during the measurement. The slight shift in the display after the measurement is complete is that of the display catching up to the acquisition system. Copyright 2004 Rigol Electronic 2-35 User Manual for DS5000 Series...
  • Page 62 Anti-Aliasing: Aliasing is the condition that oscilloscope acquire frequency is lower than twice the max frequency of input signal. Anti-Aliasing prevents it. The Anti-Aliasing function could detect the max signal frequency to avoid aliasing. 2-36 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 63: How To Set Up The Display System

    Set the time before hiding menu. The Menu menu will be hidden according to the Display time after last button pressing. Infinite Normal Set to normal mode Screen Invert Set to invert color display mode Copyright 2004 Rigol Electronic 2-37 User Manual for DS5000 Series...
  • Page 64 Refresh rate: It is an important performance of digital oscilloscopes. It means times of oscilloscopes’ refreshing per second and will affect the ability to observe signal. The refresh rate of DS5000 series digital oscilloscope is over 1K per second. 2-38 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 65: How To Store And Recall Waveforms Or Setups

    Select storage location of Waveform No.3 waveform … No10 No.1 No.2 Setup No.3 Select storage location of setup … No10 Set recalling of stored Load documents Save Set storage of waveform data Copyright 2004 Rigol Electronic 2-39 User Manual for DS5000 Series...
  • Page 66 • The user should wait at least five seconds before turning off the instrument if the settings are changed. This ensures the setup be saved properly. The oscilloscope can store 10 settings permanently and can restore at anytime. 2-40 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 67: How To Set Up The Utility

    (More languages may be Language English added in later software Korean versions) Japanese Figure 2-34 Table2-20 Menu Settings Comments Pass/Fail Setup Pass/Fail test Record Setup Waveform Recorder Self-Cal Execute Self-calibration Self-Test Execute Self-test Copyright 2004 Rigol Electronic 2-41 User Manual for DS5000 Series...
  • Page 68 • Before install or uninstall an extension module, it must be confirmed that the oscilloscope powers is off. • More details could be found in the user manual for extension module. 2-42 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 69 2. Push the UTILITY button and select Self-Cal The self-calibration menu is displayed as Figure 2-37. Figure 2-37 NOTE: 　 The oscilloscope must have been working or warm-up at least 30-minutes before running self-calibrate Copyright 2004 Rigol Electronic 2-43 User Manual for DS5000 Series...
  • Page 70 Pass condition detected Output beep when Pass Pass + condition detected Stop Stop test when output occur Output Continue test when output occur Load Load a pre-defined test mask 2-44 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 71 Set vertical clearance to the waveform < y div> (0.04div-4.00div) Create Create a test mask according to the Mask above clearance Save Store created test mask NOTE: Pass/fail function is unavailable in X-Y mode . Copyright 2004 Rigol Electronic 2-45 User Manual for DS5000 Series...
  • Page 72 (Play) ■ (Stop) Playing, press to stop Msg Display Turn on recorder information display Turn off recorder information display Play mode Set circular play mode Set single time play mode Copyright 2004 Rigol Electronic 2-46 User Manual for DS5000 Series...
  • Page 73 Set first frame to be saved <1-220> End frame Set last frame to be saved <1-220> Save Store the waveforms between start frame to End frame Load Recall the saved waveforms from non-volatile memory Copyright 2004 Rigol Electronic 2-47 User Manual for DS5000 Series...
  • Page 74 SCALE knobs. Test all keys and knobs, and check the blocks on the screen response whether or not. 2-48 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 75 　3.  Y ou could follow the prompting message of " <<Press RUN’ Key Three Times to Exit The Test>>" to exit the test. Copyright 2004 Rigol Electronic 2-49 User Manual for DS5000 Series...
  • Page 76 RIGOL Language: The DS5000 series oscilloscopes have multi-language user menu, choose as your desire. Press UTILITY → Language to select the language. 2-50 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 77: How To Measure Automatically

    Select voltage measurement Voltage parameter Time Select time measurement parameter Clear Clear measurement result on screen Turn off all measurement result Display All Turn on al measurement result Copyright 2004 Rigol Electronic 2-51 User Manual for DS5000 Series...
  • Page 78 Vbase Measure a flat top voltage of a Vtop square waveform Measure a flat base voltage of a Vbase square waveform Measure Root Mean Square Voltage Vrms of a waveform 2-52 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 79 Time measurement Freq Measure Frequency of a waveform Period Measure Period of a waveform Rise time Measure Rise Time of a waveform Fall time Measure Fall Time of a waveform Copyright 2004 Rigol Electronic 2-53 User Manual for DS5000 Series...
  • Page 80 NOTE: The results of the automatic measurements will be displayed on the bottom of the screen. Maximum 3 results could be displayed at the same time. The next new measurement result will make the previous results moving left out of screen. 2-54 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 81 Clear the measure values: press Clear. Now, all of the auto measure values disappear from the screen. Figure 2-54 Clear the display measure parameter Display 18 measurements Copyright 2004 Rigol Electronic 2-55 User Manual for DS5000 Series...
  • Page 82 Preshoot: Defined as (Vmin-Vbase)/Vamp, useful for square and pulse waveforms. Average: The arithmetic mean over the entire waveform. Vrms: The true Root Mean Square voltage over the entire waveform. 2-56 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 83 Delay 1→2 : the delay between the two channels at the rising edge. Delay 1→2 : the delay between the two channels at the falling edge. +Duty: +Duty Cycle, defined as +Width/Period -Duty: -Duty Cycle, defined as -Width/Period Copyright 2004 Rigol Electronic 2-57 User Manual for DS5000 Series...

  • Page 84: How To Measure With Cursors

    The instruments will display cursors while measuring parameters automatically. These cursors demonstrate the physical meanings of these measurements. NOTE: The Auto Measure mode for Cursor measuring will take no effect without automatic measurements. 2-58 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 85 (3). Select the cursors type by pressing soft button as CURSOR→ Type→ Voltage or Time. (4). Move the cursors to adjust the increment between the cursors: (Details in the following Table) Copyright 2004 Rigol Electronic 2-59 User Manual for DS5000 Series...
  • Page 86 Voltage Cursors: Voltage cursors appear as horizontal lines on the display and measure the vertical parameters. Time Cursors: Time cursors appear as vertical lines on the display and measure the horizontal parameters. Copyright 2004 Rigol Electronic 2-60 User Manual for DS5000 Series...
  • Page 87 (2). Select channel Source for Cursor A and Cursor B by pressing soft button as: CURSOR→Cursor A or Cursor B→CH1, CH2 or None. (3). Move the cursors to adjust the horizontal positions of the cursors: (Details in the following Table ) Copyright 2004 Rigol Electronic 2-61 User Manual for DS5000 Series...
  • Page 88 Y）: Voltage between cursors △ NOTE: the values will be automatically displayed on the right upper corner of screen when the cursor function menu is hidden or displaying other menus. 2-62 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 89 Figure 2-61: Auto Measure Mode of Cursor Measurement There will be no cursor display if no parameter were chosen in MEASURE menu. This oscilloscope could move cursor automatically to measure 20 parameters in MEASURE menu. Copyright 2004 Rigol Electronic 2-63 User Manual for DS5000 Series...

  • Page 90: How To Use Instant Execu E Buttons

    Press to display the waveform’s falling edge Fall edge and measure its fall time automatically Press to cancel all the Auto Set actions, the oscilloscope will recover to its previous （Cancel） status 2-64 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 91 That is, to zoom in/out the signal in vertical and horizontal directions. When the horizontal s/div is 50ms/div or faster, the horizontal time base can be expand 5 div up or down. Copyright 2004 Rigol Electronic 2-65 User Manual for DS5000 Series...

  • Page 93: Chapter 3 : Application & Examples

    3. Measure period Press Time → Time1/3 to select measurement page Press Period to select period measurements NOTE: The frequency, period, and peak-to-peak measurements are shown on the screen and are updated periodically. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 94: Example 2: View A Signal Delay Caused By A Circuit

    Press MEASURE →Source→ CH1 to set measurement source Press Time to select measurement Type Press Time3/3 to select measurement page. Press Delay1→2 to display the result on the screen. Figure 3-1: Delay of the signals Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 95: Example 3: Capture A Single-Shot Signal

    When the trigger conditions are met, data appears on the display representing the data points that the oscilloscope obtained with one acquisition. Press the RUN/STOP button again rearms the trigger circuit and erases the display. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 96: Example 4: To Reduce The Random Noise On A Signal

    LF Reject (Low frequency reject) adds a high pass filter with the 3 dB point at 8 kHz. Use LF Reject to remove low frequency signals such as power line noise from the trigger path. 3. Use averaging to reduce noise on the displayed waveform. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 97 You need to choose between how quickly the waveform responds to changes and how much noise there is on the signal. (See Figure 3-3) Figure 3-3 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 98: Example 5: Making Cursor Measurements

    5. Rotate horizontal POSITION knob to place cursor B on the second peak of the ring. You can see the delta time and frequency (the measured ring frequency) in the Cursor menu. Figure 3-4 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 99 You can see the following measurements in the cursor menu: (See Figure 3-5) ■ The delta voltage (peak-to-peak voltage of the ringing) ■ The voltage at Cursor 1 ■ The voltage at Cursor 2 Figure 3-5 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 100: Example 6: The Application Of The X-Y Operation

    8. Adjust the vertical SCALE and POSITION knobs to display a desirable waveform. 9. Apply the Ellipse method to observe the phase difference between the two channels. (See Figure 3-6) Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 101 If the main axis of the ellipse is at I and III quadrant, θ must be in the range of (0~ π/2) or (3π/2~2π). If the main axis is at I and III quadrant, θ m ust be in the range of (π/2~π) or (π~3π/2). Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 102: Example 7: T Iggering On A Video Signal

    4． Press Polarity to select 5． Press Sync as Odd Field or Even Field 6． Turn the horizontal SCALE knob to see a complete waveform on the screen. Figure 3-7 3-10 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 103 Press Sync to select Line Num Turn LEVEL to trigger on a specified line number Turn the horizontal SCALE knob to see a complete waveform on the screen Figure 3-8 Copyright 2004 Rigol Electronic 3-11 User Manual for DS5000 Series...

  • Page 104: Example 8: Fft Cursor Measurement

    1. Press CURSOR key to display menu 2. Press Type to select Time or Voltage 3. Press Source to select FFT 4. Turn vertical and horizontal POSITION to a interested point. Figure 3-9 Figure 3-10 3-12 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 105: Example 9: Pass/Fail Test

    Create Mask to create a new mask. Press Output to select the expected outputting waveforms. Press Operate to start the test. Figure 3-11: Running Pass/Fail Test Copyright 2004 Rigol Electronic 3-13 User Manual for DS5000 Series...

  • Page 107: Chapter 4: Prompt Messages & Troubleshooting

    Time/Div at limit: Prompts that the Time/Div is at limit while turning the horizontal SCALE knob to adjust time base. The storage is empty: Prompts that current position of the memory is empty for waveforms or settings saved. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 108 Delayed Scan mode while turning the horizontal SCALE knob. Delay position at limit: Prompts that the horizontal position of the zoom window is at limit under the Delayed Scan mode while turning the horizontal POSITION knob. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 109 (2) Ensure the power switch is turned on (3) After the inspections above, restart the oscilloscope (4) If the problem still remains, please contact RIGOL for help 2. After the signal acquisition the waveform does not appear, please check according to the following steps:...
  • Page 110 The time base maybe is too slow. You should turn the horizontal SCALE knob to increase horizontal resolution to improve the display. Maybe the display Type is set to “Vectors”. You could set it to “Dots” mode to improve the display. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 111: Chapter 5: Support & Service

    Chapter 5 : Support & Service Warranty RIGOL warrants that the products that it manufactures and sells will be free from defects in materials and workmanship for a period of three (3) years from the date of shipment from an authorized RIGOL distributor. If a product or LCD proves defective within the respective period, RIGOL will provide repair or replacement as described in the complete warranty statement.

  • Page 113: Chapter 6: Reference

    300V RMS CAT II or 300V DC 150V DC CAT II CAT II 100V RMS CAT III or 100V RMS CAT III or 100V DC CAT III 100V DC CAT III Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 114 ±100ppm over any ≥1ms time interval Delay Time Accuracy Delta Time Single-shot: ±(1 sample interval+100ppm×reading+0.6 ns) Measurement >16 averages: ±(1sample interval+100ppm×reading+0.4 ns) Accuracy (Full Bandwidth) * This characteristics varies by different models Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 115 Measurement waveforms acquired under same setup and ambient Accuracy (Average conditions: ±(3%×reading + 0.05 div) Acquisition Mode) * When Sampling rate is at 1GS/s, only one channel is available for use. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 116 Cursors are visible for Automatic Measurement Measure Auto Measure Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot, Preshoot, Freq, Period, Rise Time, Fall Time, +Width, -Width, +Duty, -Duty, Delay1→2 , Delay1->2 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 117 Dimensions Height 288 mm Width 350 mm Depth 145 mm Weight Without package 4.5 kg (approximate) Packaged 5.6 kg IP Degree IP2X Adjustment Interval The recommended calibration interval is one year Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 118: Appendix B: Ds5000-Series Accessories

    EM5-COM communication module: RS232, GPIB • EM5-P/F Pass/Fail output module • UltraScope for WIN98/ 2000/XP software • Accessories case: PA-5000 All accessories (standard and optional) are available by contacting your local RIGOL office. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 119: Appendix C: General Care And Cleaning

    2. Use a soft cloth dampened with water to clean the instrument. NOTICE: To avoid damage to the surface of the instrument or probes, do not use any abrasive or chemical cleaning agents. Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

  • Page 121: Index

    Ext and Ext/5 ......2-30 OFF ..........2-16 Options ......... V Factory Setup......2-40 FFT .......... 2-12 Power ........6-5 FORCE......1-15, 2-25 Pretrigger........2-32 Front panel .........1-2 Probe......... 6-1 Functional check......1-6 Probe Attenuation....... 2-6 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...
  • Page 122 Screen Test ......2-48 Video Signal......3-10 Self-test ........2-48 Video Trigger ......2-27 Single Trigger ......2-31 STORAGE ......... 2-39 X-Y ......2-20, 2-23, 3-8 Sync Pulses ......2-27 Y-T .......... 2-20 Copyright 2004 Rigol Electronic User Manual for DS5000 Series...

This manual is also suitable for:

Ds 5000caDs 5000cDs 5000maDs 5000m
