BSG TID-05-T30-01-005 User Instructions 1.1. About this Manual This manual contains all the information you need for installing and operating the Balluff Easy Tool-ID system. 1.2. Structure This manual is organized so that the sections build on one another. Example:...
BSG TID-05-T30-01-005 Version Overview 2.1. Manual Version Log Date Version Description 2016-08-07 Initial version 2016-12-06 Final version 2017-02-07 Addition of the function "Convert radius to diameter" 2018-03-21 Addition of the functions "Convert to inch", "Cancel function", "Copy and paste" and "Firmware update". Update of the revised functions of the new firmware version 2018-08-27 Addition of the "Decimal Places"...
BSG TID-05-T30-01-005 Introduction RFID-based tool identification is an ever more important topic today when it comes to opti- mizing production processes and reducing costs. Easy Tool-ID represents a cost-effective and simple solution for covering the basic functions of tool identification. Principle of tool identification using RFID All tool-relevant data is stored without contact on a data carrier embedded in the tool holder.
A simple but highly effective alternative is to enter the tool data into the screen at the ma- chine automatically. Balluff has developed a solution called "Easy Tool-ID", enabling you to read tool data from the RFID chip and enter the data machine-specific into the screen at the push of a button.
BSG TID-05-T30-01-005 The Easy Tool-ID System 4.1. System Overview The Easy Tool-ID system is a special tool stand with RFID function. An integrated microcon- troller can be used to read out data that is stored on an RFID data carrier, and then the data can be forwarded to an HMI via USB.
Caution Proper connection of the power supply must be carried out by specialist personnel. Balluff shall assume no liability for improper use. It must be ensured that the system is connected to ground. Figure 4: Components...
Presetter with integrated RFID functionality (BIS C or BIS M) • Balluff standard data mapping (see Section 4.5 Balluff standard data mapping) Note The Easy Tool-ID system is a BIS C or BIS M system. For more details on this, refer...
BSG TID-05-T30-01-005 The Easy Tool-ID System 4.4. Installation and Startup Once the configuration plans are created and have been uploaded to the microcontroller (see Section 5), the system is ready for use. The system has to be installed next to the machine tool near the HMI. The stand has to be firmly anchored to the floor to prevent the possibility of tipping.
BSG TID-05-T30-01-005 The Easy Tool-ID System 4.5. Safety Notes Installation and operation Installation and operation may only be performed by trained technical personnel. Unauthorized intervention and improper use shall void warranty and liability claims. Use and testing When using the Easy Tool-ID system, you must follow the applicable safety regulations. In particu- lar, measures must be taken so that no person or object is put in danger if the identification sys- tem has a defect.
The Easy Tool-ID System 4.6. Balluff Standard Data Mapping To transfer the correct data, you need to have the Balluff standard data mapping on the pre- setter. This mapping determines the location at which the RFID data carrier stores the infor- mation and in which format it is stored.
BSG TID-05-T30-01-005 The Easy Tool-ID System 4.7. Usage The Easy Tool-ID system can be used once it is provided with power and connected to the HMI via USB. To do so, place a tool with RFID data carrier into the tool holder. Note Make sure that the tool has been put in the holder correctly.
BSG TID-05-T30-01-005 The Easy Tool-ID System 4.8. Status Indicators The system's status can be indicated by the LEDs on the microcontroller. These are visible on the tool stand from the outside. There are 3 LEDs in total: • ON (blue): Once the system is connected to the HMI or a computer via USB, the blue LED lights up and stays lit.
Check whether the configuration was prepared according to the specifications • Verify that the data were correctly written on the RFID data carrier • Reinstall the configuration if necessary Note If none of the aforementioned measures remedies the error, Balluff Service will be happy to help you. https://www.balluff.com/local/de/support/...
Easy Tool-ID setup. If driver installation failed, you can always reinstall it in the program directory of Easy Tool-ID (usually C:\Program Files (x86)\Balluff GmbH\Balluff Easy Tool-ID\Driver). Note The drivers and configuration software only have to be installed on the computer to be used for configuring the system.
icon or Start All Programs Balluff GmbH Balluff Easy Tool-ID Balluff Easy Tool- Function Overview After starting the application you are able to make various settings. The following pages provide a detailed description of the respective configuration options.
BSG TID-05-T30-01-005 The Configuration Software 5.4. Creating Plans • Click the Create button. (1) • Enter a unique name. (2) • Enter a tool type number in the range from 0 to 30000. (3) • After entering valid values, confirm them with Add. (4) •...
BSG TID-05-T30-01-005 The Configuration Software 5.5. Creating Multiple Plans In some cases it may be necessary to create multiple plans. For different tool types, there- fore, different entries may need to be made in the respective HMI. For example: Tool type 1 has only one cutting edge with a radius and a length. The plan looks as follows: Figure 9: Creating multiple plans Tool type 2, however, has 2 cutting edges:...
BSG TID-05-T30-01-005 The Configuration Software To execute the corresponding plans for the respective tool type, the number from the "Tool Type" field has to be stored on the RFID tag at bytes 116 and 117 (step data 1 type). Figure 11: Tool type number Then, based on the number, the microcontroller filters the respective plan on the RFID tag and executes it.
BSG TID-05-T30-01-005 The Configuration Software 5.6. Entry Instructions When creating a configuration plan, you need to note several things: • The name of a configuration plan must never be blank (no characters). • The Tool Type must never be blank and must always consist of a number from 0 to 30000.
BSG TID-05-T30-01-005 The Configuration Software 5.7. Deleting a Configuration Plan • Select the configuration plan you wish to delete. (1) • Click the Delete button. (2) • You are prompted whether you really want to delete the plan. Click on OK to delete the plan or on Cancel to not delete it.
BSG TID-05-T30-01-005 The Configuration Software 5.8. Sorting Plans • Click the plan you wish to move. (1) • Click Up or Down to move the plan up or down in the list. (2) Figure 14: Sorting plans...
BSG TID-05-T30-01-005 The Configuration Software 5.9. Modifying a Configuration Plan • Select an existing configuration plan. • Click the Edit button or double-click the plan. (1) • Now you can change the plan name and the tool type number in the Edit window. (2) The same rules apply as for creating plans.
BSG TID-05-T30-01-005 The Configuration Software 5.10. Duplicating a Configuration Plan • Select an existing configuration plan. • Click on Duplicate. (1) • Enter a new plan name and a new tool type number. (2, 3) The same rules apply as for creating plans. (Unique name and filter) •...
BSG TID-05-T30-01-005 The Configuration Software 5.11. Creating a Shortcut Step • To add a shortcut step, a plan must be selected. • Click Add Shortcut. (1) • You can optionally enter a name. (2) • Click in the keyboard input field and enter a valid key combination (e.g. Ctrl + A). For enter- ing press the required keys on your keyboard.
BSG TID-05-T30-01-005 The Configuration Software 5.12. Creating a Data Step • Click Add data. (1) • Select the desired data field. (2, 3) • Enter a delay time after the step in milliseconds. (4) • Confirm your entry by clicking on Add. (5) •...
BSG TID-05-T30-01-005 The Configuration Software 5.13. Special Function "Convert to Diameter" A presetter always outputs the cross dimension as a radius. However, sometimes the ma- chine tool needs this value as a diameter. To enable this through the Easy Tool-ID system, you can use the additional "Convert to diameter"...
Page 30
BSG TID-05-T30-01-005 The Configuration Software 5.14. Special Function "Decimal Places" The Easy Tool-ID System outputs three decimal places by default. Some machines only ac- cept less than three decimal places. You can change the amount of decimal places in the software.
BSG TID-05-T30-01-005 The Configuration Software 5.15. Sorting Steps • Click on the step you wish to move. (1) • Click on Up or Down to move the step up or down in the list. (2) Figure 21: Sorting steps...
BSG TID-05-T30-01-005 The Configuration Software 5.16. Editing Steps • Click the step you wish to edit. (1) • Clicking "Edit" or double-clicking the step opens the "Edit" dialog. (2) • Modify the step as desired. (3) Figure 22: Editing steps...
BSG TID-05-T30-01-005 The Configuration Software 5.17. Deleting Steps • Click on the step you wish to delete. (1) • Clicking on Delete deletes the selected step after the following security prompt is con- firmed by clicking on OK. (2) Figure 23: Deleting a step...
BSG TID-05-T30-01-005 The Configuration Software 5.18. Duplicating Steps • Click the step you wish to duplicate. (1) • Click Duplicate. (2) • If desired, change the settings of the duplicated step. (3) • Click "Duplicate" to complete the duplication. Figure 24: Duplicating steps...
BSG TID-05-T30-01-005 The Configuration Software 5.19. Copy and Paste Steps The configuration software enables you to copy steps and then paste them in the same in- stance of the program or in another one. Thus you can copy individual steps from one plan and paste them into another.
BSG TID-05-T30-01-005 The Configuration Software 5.20. Loading a Configuration • Clicking on Open opens the Open File dialog. (1) • Select the configuration you wish to open and click on Open. (2, 3) Figure 26: Loading a configuration Note Only files with the extension *.easy can be opened.
BSG TID-05-T30-01-005 The Configuration Software 5.21. Saving a Configuration • Clicking on Save opens the Save File dialog. (1) • Assign a location as well as a file name and lick on Save. (2, 3) Figure 27: Saving a configuration Note Only files with the extension *.easy can be saved.
BSG TID-05-T30-01-005 The Configuration Software 5.22. Keyboard Input Language The keyboard input language enables you to use a country-specific, simulated keyboard. For example with an English keyboard setting "Y" and "Z" are reversed compared to the German keyboard. This ensures that the correct country-specific keyboard layout is always used. Note The keyboard layout of the operating system is always determined and automatically entered when the program is started.
BSG TID-05-T30-01-005 The Configuration Software 5.23. Decimal Separators The decimal separator character is a character which separates the whole number part of a decimal number from the decimal places. If Dot is set, the number 100.23 will be displayed in the application, and if Comma is set the number will appear as 100,23 in the application.
BSG TID-05-T30-01-005 The Configuration Software 5.24. Converting Values to Inches Easy Tool-ID enables you to convert certain values to inches. You can see whether a value is converted to inches when you create or edit a data step. Figure 30: Converting to inches in the data step The setting for converting to inches is implemented globally.
BSG TID-05-T30-01-005 The Configuration Software 5.25. Global Writing Speed When creating steps, you can specify a delay time in milliseconds. This time value means that the keyboard program always waits the set time after the step has been executed. The global writing speed inserts an additional time value. This value determines how long the wait will be after a character is entered.
BSG TID-05-T30-01-005 The Configuration Software 5.26. Connection Status The connection status of the Easy Tool-ID Hardware is displayed in the application. Whenever the hardware at an USB port is changed, the connection status and the version of the connected firmware are automatically updated in the application. Viewing the connection status •...
BSG TID-05-T30-01-005 The Configuration Software 5.27. Data Transmission Data can be sent to the hardware only if there is an active connection. Sending data to the hardware • Click the "Start transfer" button. (1) • The Transfer Status window opens. (2) •...
If a red X (X) is displayed next to "FW" in the software, the firmware has to be updated. This is done by going to Start All Programs Balluff GmbH Balluff Easy Tool-ID and selecting the "Firmware Update" software. Run this software and follow the displayed steps.
