BIC 1I12-P2A25-M30MI1-BPX05-110
BIC 2I12-P2A25-M30MI1-BPX03-010
User´s Guide

Advertisement

Table of Contents
loading

Summary of Contents for Balluff BIC 1I12-P2A25-M30MI1-BPX05-110

  • Page 1 BIC 1I12-P2A25-M30MI1-BPX05-110 BIC 2I12-P2A25-M30MI1-BPX03-010 User´s Guide...
  • Page 2: Table Of Contents

    Block Diagram Base Display Timing Diagram Installation Transmission Distance Mutual Interference Offset Installation in Metal Angular Offset Commissioning InZone Output Technical Data Base Mechanical Data Electrical Data Terminal Assignment Remote Mechanical Data Electrical Data Terminal Assignment Attachment Ordering Information www.balluff.com...
  • Page 3: Safety

    (safety-related circuits). Safety Notes Caution! Metal objects may not cross Zones A, B, C or between active base and remote surfaces. Fire Hazard! www.balluff.com...
  • Page 4: Protection From Electromagnetic Fields

    Note In the interest of continuous improvement of the product, Balluff GmbH reserves the right to change the technical data of the product and the content of these instructions at any time without notice. www.balluff.com...
  • Page 5: System Overview

    Balluff Inductive Coupler BIC 1I12-P2A25-M30MI1-BPX05-110 (Base) BIC 2I12-P2A25-M30MI1-BPX03-010 (Remote) System Overview Topology Functionality The inductive coupler system consists of a Base- as well as a Remote-Unit and allows a signal transmission by an air gap. If the Remote is in the transmission range of the Base the signal is transmitted via.
  • Page 6: Timing Diagram

    REMOTE "S" closed Switch "S" rotate BASE "Data Valid" BASE "Signal" depends on the rotating speed. rotate Customer's specification: maximum rotating speed of 44 rpm and mounting position (radius = 600 mm) => t =1.37s rotate = 50 msec www.balluff.com...
  • Page 7: Installation

    Balluff Inductive Coupler BIC 1I12-P2A25-M30MI1-BPX05-110 (Base) BIC 2I12-P2A25-M30MI1-BPX03-010 (Remote) Installation Transmission Attention! Distance Improper assembly can negatively impact the system and lead to damages. The distances indicated for installation must be observed. Compliance with permitted transmission distances is required for fault-free operation of the...
  • Page 8: Angular Offset

    Of a longer cable is used nonetheless, take all possible measures to protect the receiver from over-voltage peaks. Note Operate base coupler (BIC 1I12-P2A25-M30MI1-BPX05-110) exclusively with remote coupler (BIC 2I12-P2A25-M30MI1-BPX03-010). Commissioning is only possible after complete assembly of an entire transmission chain between base and remote.
  • Page 9: Technical Data

    Balluff Inductive Coupler BIC 1I12-P2A25-M30MI1-BPX05-110 (Base) BIC 2I12-P2A25-M30MI1-BPX03-010 (Remote) Technical Data Base Display Function static Connection established green slowly flashing Power on, no remote found rapidly flashing Overload/short-circuit Mechanical Housing material Stainless steel (1.4305) Data Sensing surface material PA66 Housing degree of protection...
  • Page 10: Remote

    PUR, 2 strands 2 x 0.5 shielded Cable length Cable diameter D 5.6 mm Least bending radius 10 x D Terminal Color Signal Signal Type / Assignment brown Signal IN (S+) Digital IN white Signal GND (S-) Digital RTN blue Shield www.balluff.com...
  • Page 11: Attachment

    Balluff Inductive Coupler BIC 1I12-P2A25-M30MI1-BPX05-110 (Base) BIC 2I12-P2A25-M30MI1-BPX03-010 (Remote) Attachment Ordering Product Name Item Number Information BIC 1I12-P2A25-M30MI1-BPX05-110 (Base) BIC007Z BIC 2I12-P2A25-M30MI1-BPX03-010 (Remote) BIC0080 www.balluff.com...
  • Page 12 Balluff GmbH Schurwaldstrasse 9 D-73765 Neuhausen a.d.F. Germany Phone +49 7158 173-0 Fax +49 7158 5010 www.balluff.com balluff@balluff.de...
