2.6 Power Management Setup

ACPI Suspend Type
- Resume by USB from S3
Power Button Function
Wake Up by WAKE# of PCIe
Wake Up by PME# of PCI
Wake Up by Onboard LAN1
Wake Up by Onboard LAN2
Resume by Alarm
x - Date(of month) Alarm
x - Time(hh:mm:ss) Alarm
POWER ON Function
x - KB Power ON Password
x - Hot Key Power ON
Restore On AC Power Loss
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
ACPI Suspend Type
This item selects the type of Suspend mode.
- Resume by USB from S3
When set to [Enabled], this item allows you to use a USB device to wake up a system that is in
the S3 (STR - Suspend To RAM) state. This item can be configured only if the item "ACPI
Suspend Type" is set to [S3(STR)].
Power Button Function
This item selects the method of powering off your system:
[Delay 4 Sec.]: Pushing the power button for more than 4 seconds will power off the system.
This will prevent the system from powering off in case you accidentally hit or pushed the power
button.
[Instant-Off]: Pressing and then releasing the power button at once will immediately power
off the system.
Wake Up by WAKE# of PCIe
When set to [Enabled], access through the add-on PCI Express card can remotely wake up the
system that was in Soft-Off condition. The PCI Express card must support the wake up function.
Wake Up by PME# of PCI
When set to [Enabled], access through the add-on PCI card can remotely wake up the system
that was in Soft-Off condition. The PCI card must support the wake up function.
Wake Up by Onboard LAN1/LAN2
When set to [Enabled], access through the onboard LAN1/LAN2 port can remotely wake up the
system that was in Soft-Off condition.
IP35 Pro
Phoenix – AwardBIOS CMOS Setup Utility
Power Management Setup
S3(Suspend-To-RAM)
Enabled
Instant-Off
Disabled
Disabled
Disabled
Disabled
Disabled
0
0 : 0 : 0
Button Only
Enter
Ctrl-F1
Power Off
F6: Fail-Safe Defaults
Item Help
F7: Optimized Defaults
2-21
