3.3.1

Main Menu

The Main Menu offers a quick status overview of the
battery system and battery charger. It is immediately
accessible by pressing the Select button shortly. None of
the displayed information can be modified at this menu.
There are two modes to display the measured parameters
at the Main Menu:
•
Standard menu. If this mode is chosen, all below
mentioned screens will be shown, except the screen
marked with *. (Install menu, F2 = OFF)
•
Short menu. If this mode is chosen, the screens which
are marked with ** will not be shown. (Install menu, F2
= ON)
The desired mode can be selected at the Install menu,
function F2 (see section 3.3.2).
If the GMDSS Interface is adjusted to the
Standard menu, and function F1: Scroll main
menu is set to ON, scrolling through the Main
Menu is done automatically. If the function F1:
Scroll main menu is set to OFF, you can scroll
through the Main Menu by touching the Select
button shortly.
Status charger
M 24/25
Shows the model of the connected
Bulk
Mass series battery charger and the
actual charge stage of the Three
Stage Charge algorithm.
Voltage and charge current*
26.4V
Shows the actual battery voltage
024.0A
(Volt) and the charge current (Amps).
Charge current**
CHG CUR.
Shows the actual charge current (%)
089%
as percentage of the nominal charge
current.
Battery voltage **
BAT VOLT
Shows the actual battery voltage
26.4V
(Volt).
Battery current**
BAT CUR.
Shows the actual charge current
024.0A
(Amps).
EN / GMDSS Mass Charger Alarm Interface / January 2013 / Copyright © 2013 Mastervolt
3.3.2

Install menu

The Install menu is used to adjust the GMDSS-Interface
in accordance with the electrical installation.
To enter the Install Menu, hold the Select button pressed
for at least 1 second.
To leave the Install Menu wait 20 seconds or scroll to
RETURN and hold the Select button pressed until you
return to the Main Menu.
Touch the Select button shortly to scroll
through the functions as described below.
If a value can be adjusted, the display shows
an arrow. When the arrow is pointing
downwards ( ) the displayed value can be
decreased by pressing the Mute button
shortly. If the arrow is pointing upwards ( )
the value can be increased.
To change the direction of this arrow, hold the
Select button pressed until the pointing
direction of the arrow changes.
To protect the GMDSS-Interface against
unintended adjustment of set points, the Lock
all settings function is activated every time
you enter the Install menu. When activated
("ON"), the settings mentioned in this chapter
cannot be changed. See F0 Lock all settings
to unlock.
F0: Lock all settings
To unlock the settings of the GMDSS Interface, hold the
Select button pressed until this function switches to OFF.
Factory setting: ON
Adjustable range: ON/OFF
F1: Scroll main menu
If this function is set to ON, scrolling through the Main
Menu is done automatically. If set to OFF, you can scroll
through the Main Menu manually by touching the Select
button.
Factory setting: ON
Adjustable range: ON/OFF
F2: Main menu short
If this function is set to OFF, all screens mentioned in
section 3.3.1 will be shown, except screen marked with *.
If set to ON, screens marked with ** will not be shown.
Factory setting: OFF
Adjustable range: ON/OFF
OPERATION
7
