INSTALLATION AND COMMISSIONING
4.6

COMMISSIONING

CAUTION!
Check the polarity of all wiring before
commissioning: plus connected to plus (red
cables), minus connected to minus (black
cables)
Follow the steps described below to switch on the GMDSS
Interface.
Mount this assembly into the instrumentation panel
1 Tighten all cable glands of the battery charger to
ensure the pull relief
2 Check all wiring and connections
3 Close the front cover plate of the battery charger.
Beware that the wiring does not obstruct the cooling
fans and air flow.
4 If all wiring is OK, place the DC-fuse(s) to connect the
Interface to the DC power supply
5 The GMDSS Interface will switch on: an audible alarm
can be heard, all LED's will illuminate for a few
seconds and a welcome message is shown on the
display.
6 If required, go to the Install menu to adjust the
GMDSS-Interface in accordance with the electrical
installation (refer to section 3.3.2)
7 Test the alarm functions of the GMDSS Interface; see
function F17 of the Install menu (refer to section 3.3.2)
Now the GMDSS Interface is ready for operation.
14
Copyright © 2013 Mastervolt / January 2013 / GMDSS Mass Charger Alarm Interface Copyright / EN
4.7

DECOMMISSIONING

If it is necessary to put the GMDSS Interface out of
operation, follow the instructions in order of succession as
described below:
1 Switch off the battery charger
2 Remove the DC-fuse(s) of the DC-distribution and/or
disconnect the batteries.
3 Remove the fuses from the DC power supply and the
voltage sensing wires
4 Check with a suitable voltage meter whether the
inputs and the outputs of the GMDSS Interface are
voltage free.
5 Disconnect all the wiring
Now the GMDSS Interface can be demounted in a safe
way.
4.8

STORAGE AND TRANSPORTATION

When not installed, store the Interface in the original
packing, in a dry and dust free environment.
Always use the original packing for transportation. Contact
your local Mastervolt Service Centre for further details if
you want to return the apparatus for repair.
4.9

RE-INSTALLATION

To reinstall the GMDSS Interface, follow the instructions
as described in this chapter (chapter 4).
