Summary of Contents for ATEN CS-1742

  • Page 1 User Manual CS-1742 CS-1744 2004-09-24...
  • Page 2 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Subpart J of Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer- ence to radio communications.

  • Page 3: Packing List

    Packing List The complete Master View CS-1742 / CS-1744 package consists of: CS-1742 or CS-1744 USB KVM Switch CS Custom Audio/Video Cables (CS-1742) CS Custom USB/Video Cables (CS-1742) CS Custom Audio/Video Cables (CS-1744) CS Custom USB/Video Cables (CS-1744) Firmware Upgrade Cable...

  • Page 4: Table Of Contents

    CS-1742 / CS-1744 User Manual 1. Introduction Overview ....... . . 1 Features .
  • Page 5 Hotkey Default Settings ......31 Limited Warranty ......31 2004-09-24 CS-1742 / CS-1744 User Manual...
  • Page 6 CS-1742 / CS-1744 User Manual Conventions This manual uses the following conventions: Indicates text that you should key in. Courier Indicates keys you should press. For example, [Enter] means to press the Enter key. If keys need to be chorded, they appear together in the same bracket with a plus sign between them: [Ctrl+Alt].

  • Page 7: Introduction

    USB keyboard, USB mouse, and two VGA, SVGA, or Multisync monitors. In addition, the CS-1742 / CS-1744 incorporates a two port USB hub that allows each of the computers to share any USB peripherals connected to the hub on a one computer at a time basis.

  • Page 8: Features

    CS-1742 / CS-1744 User Manual Features Provides a second video channel to support dual head computers One console controls 2 (CS-1742) or 4 (CS-1744) dual head computers Two USB ports for USB device sharing Audio jacks for speaker and microphone sharing Independent (asynchronous) switching of the KVM, USB, and audio focus Fully compliant with the USB 1.1 specification - supports transfer rates of...

  • Page 9: Hardware Requirements

    Only CS Custom cable sets specifically designed to work with this switch may be used to link to the computers. Two (CS-1742) or four (CS-1744) cable sets are provided with this package. Additional cable sets can be purchased from your dealer.

  • Page 10: Front View

    CS-1742 / CS-1744 User Manual Front View CS-1742: 1 & 2 CS-1744: 1 & 2 2004-09-24...
  • Page 11 The front panel components are described in the table below: Port Press a switch to access the computer attached to its Selection corresponding port. Switches Pressing Buttons 1 and 2 simultaneously for 2 seconds starts Auto Scan Mode. See p. 15 for details. Port LEDs The Port LEDs are built into the Port Selection Switches.

  • Page 12: Rear View

    CS-1742 / CS-1744 User Manual Rear View CS-1742: CS-1744: 2004-09-24...
  • Page 13 The Firmware Upgrade Cable that transfers the firmware Upgrade Port upgrade data from the administrator’s computer to the CS-1742 / CS-1744 plugs into this RJ-11 connector. See p. 23 for firmware upgrading details. Console Port The cables from your console components (keyboard,...
  • Page 14 CS-1742 / CS-1744 User Manual Notes: 2004-09-24...

  • Page 15: Installation

    2. Make sure that all devices on the installation are properly grounded. Cable Connection To set up your Master View CS-1742 / CS-1744 installation, refer to the installation diagram on the next page (the numbers in the diagram correspond to the steps below), and do the following: 1.
  • Page 16 CS-1742 / CS-1744 User Manual 5. If you choose to use external power, plug the power adapter cable into the switch’s Power Jack, then plug the power adapter into an AC power source. Note: The power adapter should be DC5V 2.6A with the inside positive and the outside negative: 6.

  • Page 17: Basic Operation

    Hot Plugging The Master View CS-1742 / CS-1744 supports USB hot plugging - components can be removed and added back into the installation by unplugging their cables from the USB hub ports without the need to shut the unit down.

  • Page 18: Powering Off And Restarting

    Each CPU port on the CS-1742 / CS-1744 switch is assigned a port number (1 or 2 for the CS-1742; 1 to 4 for the CS-1744). The port numbers are marked on the rear panel of the switch (see p. 6).

  • Page 19: Hotkey Operation

    [Enter] port that currently has the KVM focus to the next port on the installation (1 to 2; 2 to 1 for the CS-1742; 1 to 2; 2 to 3; 3 to 4; 4 to 1 for the CS-1744). Note that the KVM, USB hub, and audio focus all go to this port even if they were on different ports to begin with.

  • Page 20: Going Directly To A Port

    CS-1742 / CS-1744 User Manual Going Directly to a Port Hotkey [Scroll Lock] [Scroll Lock] [n] Brings the KVM, USB hub, and audio focus to the [Enter] computer attached to the port corresponding to the specified Port ID. Note that the KVM, USB hub, and audio focus all go to this port even if they were on different ports to begin with.

  • Page 21: Auto Scanning

    [A] [n] [Enter] at n second intervals. Note: 1. The n stands for the number of seconds that the CS-1742 / CS-1744 should dwell on a port before moving on to the next. Replace the n with a number between 1 and 99 when entering this hotkey combination.

  • Page 22: Hotkey Setting Mode

    CS-1742 / CS-1744 User Manual Hotkey Setting Mode Hotkey Setting Mode is used to set up your CS-1742 / CS-1744 switch configuration. All operations begin with invoking Hotkey Setting Mode (HSM). Invoking HSM To invoke HSM do the following: 1. Press and hold down the Num Lock key 2.

  • Page 23: Alternate Hsm Invocation Keys

    Alternate HSM Invocation Keys An alternate set of HSM invocation keys is provided in case the default set conflicts with programs running on the computers. To switch to the alternate HSM invocation set, do the following: 1. Invoke HSM (see above) 2.

  • Page 24: Keyboard Operating Platform

    CS-1742 / CS-1744 User Manual Keyboard Operating Platform The CS-1742 / CS-1744’s default port configuration is for a PC Compatible keyboard operating platform. If you have a Mac or Sun attached to a port, you can change the port’s keyboard operating platform configuration as follows: 1.

  • Page 25: Usb Reset

    This procedure is a toggle. To enable the Port Switching keys repeat steps 1 and 2. Firmware Upgrade Mode To set the CS-1742 / CS-1744 to Firmware Upgrade Mode, do the following: 1. Invoke HSM (see p. 16). 2. Key in: upgrade 3.

  • Page 26: Restore Default Settings

    CS-1742 / CS-1744 User Manual Restore Default Settings To reset the CS-1742 / CS-1744 to its default hotkey settings, do the following: 1. Invoke HSM (see p. 16). 2. Press [R] [Enter]. All hotkey settings return to the factory default settings. A table showing the CS-1742 / CS-1744’s default settings is provided in the appendix on p.

  • Page 27: Keyboard Emulation

    Keyboard Emulation Sun Keyboard The PC compatible (101/104 key) keyboard can emulate the functions of the Sun keyboard when the Control key [Ctrl] is used in conjunction with other keys. The corresponding functions are shown in the table below. Note: When using [Ctrl] combinatons, press and release the Ctrl key, then press and release the activation key.

  • Page 28: Mac Keyboard

    CS-1742 / CS-1744 User Manual Mac Keyboard The PC compatible (101/104 key) keyboard can emulate the functions of the Mac keyboard. The emulation mappings are listed in the table below. Note: When using key combinatons, press and release the first key, then press and release the second one.

  • Page 29: The Firmware Upgrade Utility

    1. From a computer that is not part of your KVM installation go to our Internet support site and choose the model name that relates to your device (CS-1742 or CS-1744) to get a list of available Firmware Upgrade Packages. 2. Choose the Firmware Upgrade Package you want to install (usually the most recent), and download it to your computer.

  • Page 30: Starting The Upgrade

    CS-1742 / CS-1744 User Manual Starting the Upgrade To upgrade your firmware: 1. Run the downloaded Firmware Upgrade Package file - either by double clicking the file icon, or by opening a command line and entering the full path to it. The Firmware Upgrade Utility Welcome screen appears: Note: The screenshots in this section are for example purposes.
  • Page 31 1. Read and Agree to the License Agreement (enable the I Agree radio button). 2. Click Next to continue. The Firmware Upgrade Utility main screen appears: The Utility inspects your installation. All the devices capable of being upgraded by the package are listed in the Device List panel. 3.
  • Page 32 CS-1742 / CS-1744 User Manual 4. After you have made your device selection(s), Click Next to perform the upgrade. If you enabled Check Firmware Version, the Utility compares the device’s firmware level with that of the upgrade files. If it finds that the device’s...

  • Page 33: Upgrade Succeeded

    Upgrade Succeeded After the upgrade has completed, a screen appears to inform you that the procedure was successful. To complete the upgrade: 1. Click Finish to close the Firmware Upgrade Utility. 2. Power off the switch Unplug the KVM cables from the back of the switch. If you are using a power adapter with your switch, unplug its power adapter cable from the power jack.

  • Page 34: Upgrade Failed

    CS-1742 / CS-1744 User Manual Upgrade Failed If the Upgrade Succeeded screen doesn’t appear, it means that the upgrade failed to complete successfully, in which case you should repeat the upgrade procedure from the beginning. Upgrade Interrupted If the firmware upgrade procedure is abnormally halted (due to computer crash, power failure, etc.), the switch may become inoperable.

  • Page 35: Appendix

    0 - 80% RH Housing Metal Weight 0.82 kg Dimensions (L x W x H) 20.0 x 7.45 x 4.2cm Appendix CS-1742 CS-1744 4 (Orange) 4 (Green) 4 x SPHD-15 - F 4 x SPHD-15 - M DC 5V; 1.35W 1.03 kg 26 x 7.45 x 4.2cm...

  • Page 36: Troubleshooting

    CS-1742 / CS-1744 User Manual Troubleshooting Symptom Possible Cause Erratic Unit not receiving Use a DC 5V power adapter if you are not behavior. enough power. already using one. If you are already using a power adapter, check that it matches the system specifications (DC 5V), and that it is plugged in and functioning properly.

  • Page 37: Hotkey Default Settings

    Hotkey Default Settings The hotkey factory default settings are given in the table below: Setting Port Switching [Scroll Lock] [Scroll Lock] Invoking HSM [Num Lock] [ - ] Auto Scan Interval 5 seconds Beeper Keyboard Operating Platform PC Compatible - Auto Detect Port Switching Keys Enabled Limited Warranty...
