6.3.4

"REF" Button (Channel 3)

Normally enabled for weighing applications other than front-end loaders, e.g.
for trailer weighing. When switched on, pressing the REF button in the
operating mode triggers a weighing sample. In effect, the REF button manually
performs the function of a reference/direction sensor.
"OFF"
"ON"
"AUTO" Ref/Dir sensor can be used in conjunction with REF button to take a
Press
6.3.5

Time / Date (Channel 4)

The display alternates between "Hr.Mn" and "00.00".
1.
Programme the hours (24 hr format) and minutes (section 6.1).
2.
Press
"Mt.Dt" and "01.01".
3.
Programme the month (01-12) and the date.
4.
Press
"Yr.Dy" and "01.01".
5
Programme the year and the day of the week (01=Monday – 07=Sunday).
6.3.6

Language (Channel 5)

Sets the language for the printout and certain display prompts.
Press
REF button disabled. Weight reading triggered from Ref/Dir sensor
only.
REF button enabled (where Ref/Dir sensor not fitted).
weight measurement.
to toggle.
to toggle to the Month/Date setting. The display alternates between
to toggle to the Year/Day setting. The display alternates between
to toggle.
CALIBRATION
27
