6.2.1

Enter CAL Mode 1

1. Press the
instrument.
2. Press
to calibrate (channels 1 to 5).
6.2.2

Set Weighing Mode

3. Hold the
button to toggle between Static mode
("StAt") and Dynamic mode ("dYn").
4. Release both buttons.
6.2.3

Set Initial Cal. Factor

This continues from section 6.2.2.
5. Press
calibration factor "CALF". (Fig.19).
Default Factor = 1.000
Set the initial calibration factor to equal
the lift capacity of the machine (e.g. if the
lift capacity is 1.5 tonnes, then set the
factor to 1.500).
NOTE: The Cal Factor will normally have a value
somewhere between 1 and 10.
If you are working in lbs units, regardless
if the instrument is set for "USA" units, you
must convert to decimal tons when
entering the initial cal factor. E.g for
10,000 lb capacity, enter Cal Factor of
5.000.
button and power-on the
to select the channel you want
button and press the
again to display the weight
CALIBRATION
HOLD
Figure 21 : Set Weigh Mode
Figure 22 : Set Initial Cal Factor
PRESS
21
