RDS Technology Weighlog 200 User Manual page 20

CALIBRATION
3.4
6.2.2
6.2.3
6.2.4 (i)
6.2.4 (ii)
20
Set Zero (with empty bucket)
Set Weighing Mode ("dYn" or "StAt")
Set Initial Cal Factor (= Max. Load Capacity in tonnes)
DYN. MODE
"Load FASt" Fast lift (full load)
"Load Slo" Slow lift (full load)
"Empt FASt" Fast lift (empty bucket) (note 1-p.18)
"Empt Slo" Slow lift (empty bucket)
"ZERO LIFT" – Sets Prop. Scaling/Speed
Comp. for all dynamic channels
Determine Cal Factor (the "LOAD" sequence)
Enter known weight on instrument
Place a known weight in the bucket and lift at normal speed
Weight Cal. Routine
"LOAd LIFt"
"DONE"
STAT. MODE
"ZERO LIFT"
Lift empty bucket
