CALIBRATION
"GrAd" xxxx (no units).
Compensation Curve Factor: This gives the correction for the change in lift
speed. If a faster lift gives a lower weight reading, then decrease the "GrAd"
figure.
"ProP" xxxx (%)
Proportional Correction Factor: This gives the reduction in speed
compensation for an empty bucket, compared to a full bucket. Sometimes
after an Autocal, it is found that the speed correction with a full bucket is OK,
but with an empty bucket there is a larger error (e.g. 50 –60kg).
If with an empty bucket, the weight reading is lower at a slower lift speed than
at a fast speed, then reduce the factor by 2 – 3% until the error is removed.
"FrEq" xxxx (Hertz)
Frequency at full load (determined from Autocal):
6.3.3

Live Static (Channel 2)

This sets how the weight reading is displayed in Static Weighing mode.
"OFF"
"ON"
"AUTO" You get a live reading, but it will only change if there is a change of
Press
26
The weight reading is "frozen" on the display after the weight has
been sampled.
You get a "live" weight reading while the bucket is at the weighing
position.
5% or more in the calculated weight (default setting).
to toggle.
