Modules characteristics
The Keysight DAQ970A accuracy specifications already include
the switching offset and reference junction errors shown below.
These errors are listed separately for determining system error
with external measurement devices.
Up to three modules, in any combination, can be inserted into
a single mainframe. The DAQ970A's internal DMM connections
General
Number of channels
Connects to internal DMM
Scanning speed
Open/close speed
Input
Voltage (dc, ac rms) 2
Current (dc, ac rms)
Power (W, VA)
DC characteristics
3
Offset voltage
3
Initial closed channel R
Isolation ch-ch, ch-earth
Risetime
Signal delay
Capacitance HI - LO
LO - Earth
Volt-Hertz limit
Other
T/C cold junction accuracy 3
(typical)
Switch life No load (typical)
Rated load (typical)
Temperature Operating
Storage
Humidity (non-condensing)
1. Not recommended for connection to ac line without external transient suppression. Up to 250 ch/s to internal memory. See scanning rates for measurement
condition and rate on each instrument.
2. Channel-to-channel or channel-to-earth
3. Errors included in DMM measurement accuracy specifications
4. 50 Ω source, 50 Ω load
5. Bandwidth direct to card SMB connectors
6. Isolation within channel 1 to 20 or 21 to 40 banks is –40 dB
7. Applies to resistive loads only
Find us at www.keysight.com
Multiplexer
DAQM900A DAQM901A DAQM902A
20 20 + 2
2/4 wire 2/4 wire
● ●
450 ch/s 80 ch/s 250 ch/s
120/s
120 V 300 V
1 A 1 A
50 W 50 W
< 3 uV < 3 uV
< 1 Ω < 1 Ω
> 10 GΩ > 10 GΩ
300 ps
< 3 ns
< 50 pF < 50 pF
< 80 pF < 80 pF
8 8
10 10
0.8 °C 0.8 °C
100 M
7
100 k
are accessible only through the DAQM900A, DAQM901A,
DAQM902A, and DAQM908A low-frequency multiplexers.
On-module screw terminals accept wire sizes from 16 gage to
22 gage. Twenty-gage wire is recommended for high channel
count applications. The DAQM905A RF Multiplexer uses SMB
connectors. A standard set of (10) BNC-to-SMB adapter cables is
provided with each RF module for convenient BNC connections.
Actuator
1
DAQM908A DAQM903A DAQM904A
16 40 20
2/4 wire 1 wire SPDT
● ●
[1] 100 ch/s
120/s 70/s 120/s
300 V 300 V 300 V
50 mA 1 A 1 A
2 W 50 W 50 W
< 6 uV < 3 uV < 3 uV
< 1 Ω < 1 Ω < 0.2 Ω
> 10 GΩ > 10 GΩ > 10 GΩ
< 50 pF < 50 pF < 10 pF
< 80 pF < 80 pF < 80 pF
8 8
10 10 10
0.8 °C
100 M 100 M 100 M
100 k 100 k 100 k
all cards: 0 to 55 °C
all cards: –40 to 70 °C
all cards: 40 °C to 80% RH
Allice Messtechnik GmbH
Matrix RF multiplexer Multifunction
DAQM905A
4 x 8 Dual 1 x 4
2 wire 50 Ω
120/s 60/s
300 V 42 V
1 A 0.7 A
50 W 20 W
< 3 uV < 6 uV
< 1 Ω < 0.5 Ω
> 10 GΩ > 1 GΩ
< 300 ps
< 3 ns
< 50 pF < 20 pF
< 80 pF —
8 8 10
10 10
100 M 5 M
100 k 100 k
DAQM907A
See page 23
for module
specifications
