Keysight Technologies DAQ970A Technical Overview page 14

www.allice.de
DAQM907A
Measurement Functionality
Digital I/O (Port 1,2)
Totalizer
Analog outputs
Characteristics - typical : [1, 2, 3, 4]
DAC (output & readback)
Voltage
Current
Characteristics - nominal
DIO Port 1, 2
Vin(L)
Vin(H)
Vout(L)
Vout(H)
Vin(H) max
Alarming
Speed
Latency
Read/write speed
Max count
Totalize input
Signal level
Threshold
Gate Input
Count reset
Read speed
DAC 1, 2
Resolution
Voltage mode current
Current mode compliance
Settling time
1. ACAL required within the last 30 days to achieve performance accuracies.
2. ACAL assumes ± 2C with no additional TC adders.
3. Mainframe DMM - calibrated through the 901 module.
4. Standard warranted performance is 1 year, Tcal ± 5 °C
Find us at www.keysight.com
16 bits, Input or Output, non-isolated
100 kHz Input
2 channels, ± 12 V or ± 24 mA
Accuracy
± 0.027% of output + 4.4 mV
± 0.115% of output + 4.4 uA
8 bit, input or output, nonisolated
< 0.8 V (TTL)
> 2.0 V (TTL)
< 0.8 V @ Iout = -400 mA
> 2.4 V @ Iout = 1 mA
< 42 V with external open drain pull-up
Maskable pattern match or state change
4 ms (max) alarm sampling
5 ms (typical) to DAQ970A alarm output
95/s
2^26 - 1
100 kHz (max) Rising or falling edge, programmable, min H or L time 5uS
1 Vp-p (min) 42 Vpk (max)
0 V or TTL, jumper selectable
TTL-Hi, TTL-Lo, or none
Manual or Read + Reset
85/s
± 12 V or ± 24 ma nonisolated
100uV, 0.2uA
15 mA max per channel
12 V
1 ms to 0.01% of output
