  • Page 2 First Edition, November 2001, SME-1-118 (A) All Rights Reserved, Copyright  2001, Hitachi, Ltd. The contents of this publication may be revised without prior notice. No part of this publication may be reproduced in any form or by any means without permission in writing from the publisher.
  • Page 3 SAFETY PRECAUTIONS Be sure to read this manual and all other attached documents carefully before installing, operating inspecting or conducting maintenance on this unit. Always use this unit properly. Be sure to carefully read the information about the device, the safety information and precautions before using this unit.
  • Page 4 DANGER Devise an emergency stop circuit, interlock circuit, and other similar circuits outside the programmable controller. Disregarding this rule may result in damage to the equipment or cause an accident if the programmable controller fails. Keep it in mind that this hardware unit operates on a high voltage. If the user touches a high-voltage terminal inadvertently during connection or disconnection of this hardware unit or its cable, he or she may suffer from an electric shock.
  • Page 5 REQUIREMENT An electric shock may lead to a death or burn. Noise may cause the system to malfunction. Ground the line ground (LG), frame ground (FG), and shield (SHD) terminals, as described below. • Electrically insulate the mount base from the cubicle. To assure this, do not remove the insulating sheet from the mount base.
  • Page 6 Hitachi Engineering Service Co., Ltd. The malfunctioning part will be replaced or repaired free of charge. If the malfunctioning is shipped, however, the shipment charge and packaging expenses must be paid for by the customer.
  • Page 7 PREFACE Thank you for purchasing the Hitachi Programmable Controller (S10mini). This manual describes how to handle the S10mini IR.Station module. For details on the CPU modules, I/O modules, and optional modules, refer to each respective manuals. Read this manual thoroughly to properly use this module.
  • Page 8: Table Of Contents

    1. BEFORE USE........................2. GENERAL INFORMATION ....................2.1 System Overview ......................2.2 I/O Unit Modules ......................3. NAMES AND FUNCTIONS OF EACH PART ..............3.1 IR.Station Module......................3.2 I/O Module........................3.3 Power Supply Module....................... 3.4 Mount Base ........................4. INSTALLATION........................
  • Page 9 8. SPECIFICATIONS ....................... 43 8.1 Specifications ........................44 8.1.1 IR.Station module specifications................44 8.1.2 Line specifications..................... 44...
  • Page 10 FIGURES Figure 1-1 Installation Example ..................... Figure 1-2 Output Module Specifications ................Figure 1-3 Grounding Specifications ..................Figure 1-4 Power Supply Input Waveform ................Figure 1-5 Grounding Examples .................... Figure 2-1 System Configuration ................... Figure 2-2 Unit Configuration....................Figure 3-1 Module Front View....................Figure 3-2 I/O Module Front View ..................
  • Page 11: Before Use

    1 BEFORE USE...
  • Page 12: Figure 1-1 Installation Example

    1 BEFORE USE Installation The Programmable Controller is not fireproof, dustproof, or dripproof. When you install, mount the controller in a dust and dripproof iron cubicle as shown below: Iron cubicle CPU unit I/O unit Fill this opening with putty. Figure 1-1 Installation Example - 2 -...
  • Page 13: Figure 1-2 Output Module Specifications

    1 BEFORE USE Environment Operate the Programmable Controller in the following environment: Table 1-1 Operating Environment Supply voltage 100 to 120 VAC, single-phase, 50/60 Hz±4% Amplitude range 85 to 132 VAC Temperature At operation: 0 to 55°C; storage: -20 to 75°C Relative humidity At operation: 30 to 90% RH;...
  • Page 14: Figure 1-3 Grounding Specifications

    1 BEFORE USE Grounding point Provide Class D* or better independent grounding. Do not use any other existing ground as a substitute. It is particularly important that the grounding point for the Programmable Controller be at least 15 m away from an AC panel grounding point. * Class D grounding is defined in the Technical Standard for Electrical Facilities of Japan.
  • Page 15: Figure 1-4 Power Supply Input Waveform

    User must not replace internal parts of the Programmable Controller with anything other than the parts specified in the manual. Replace the entire module in which a defective part is included. For details on parts replacement, contact your Hitachi maintenance personnel. Module insertion/removal Power must be turned off while a module is inserted or removed.
  • Page 16: Figure 1-5 Grounding Examples

    1 BEFORE USE Grounding * Inspection of the ground wiring. − Check if a ground wire is shared with another ground wire. − Check if the grounding point is at least 15 m away from the grounding point of the AC panel.
  • Page 17: General Information

    2 GENERAL INFORMATION...
  • Page 18: System Overview

    2 GENERAL INFORMATION 2.1 System Overview System configuration of the IR.Station is shown below. The IR.Station module (Model LQS021) communicates data between master stations (IR.LINK module, etc.). CPU unit (configuration example) IR.LINK (LQP000, (LQE046) (LQV000) LQP010) IRST: IR.Station I/O unit...
  • Page 19: I/O Unit Modules

    POWER AC1 0 0 -1 2 0 V Module installation on the 2-slot mount base Required modules LQV0 0 0 LQS020 IR.Station J-NET POWER IR.Station module ST.NO RATE HITACHI (LQS021) DC5 V SERVICE CHECK POWER AC1 0 0 -1 2 0 V...
  • Page 20 THIS PAGE INTENTIONALLY LEFT BLANK.
  • Page 21: Names And Functions Of Each Part

    3 NAMES AND FUNCTIONS OF EACH PART...
  • Page 22: Ir.station Module

    3 NAMES AND FUNCTIONS OF EACH PART 3.1 IR.Station Module IR.Station IR.Station LQS021 LQS021 TX/RX TX/RX ST.NO ST.NO RATE RATE HITACHI HITACHI Figure 3-1 Module Front View 128M HOLD TERM LINK LINK <Signal assignment of the terminal block> - 12 -...
  • Page 23 3 NAMES AND FUNCTIONS OF EACH PART Name Fucntion Station No. Used to specify a station number. A total of 31 stations ① setting switch ranging from 01 to 7F can be set. Use the U switch to set a higher-level station number or the L switch to set a lower-level station number.
  • Page 24: I/O Module

    3 NAMES AND FUNCTIONS OF EACH PART 3.2 I/O Module LQX100 LQX100 D. INPUT D. INPUT Monitoring LEDs The LED lights when the corresponding external I/O is on. 100-120VAC 100-120VAC Terminal block The I/O processing devices are connected to these terminals. (Some modules have a connector type terminal block.) Figure 3-2 I/O Module Front View <Signal assignment of the terminal block>...
  • Page 25: Power Supply Module

    3 NAMES AND FUNCTIONS OF EACH PART 3.3 Power Supply Module The CPU unit and I/O unit use the same power supply module model. Example: LQV000 LQV000 LQV000 POWER POWER DC5V SERVICE CHECK POWER AC100-120V INPUT Figure 3-3 Front View: Power Supply Module Table 3-1 List of the Power Supply Module Name Model...
  • Page 26 3 NAMES AND FUNCTIONS OF EACH PART Names and Functions Name Function ① Power indicator Lights on while the power switch is ON. (POWER) ② Voltage check terminal Voltage check terminal for 5 V output. (5 VDC) (Do not use this terminal for purposes other than voltage checkout.) ③...
  • Page 27: Mount Base

    3 NAMES AND FUNCTIONS OF EACH PART 3.4 Mount Base The mount base secures the IR.Station module, power supply module, and I/O module. Use I/O unit type for mount base. ① ② ③ Example: HSC1021 2-slot mount base ④ Table 3-2 List of Mount Base...
  • Page 28 THIS PAGE INTENTIONALLY LEFT BLANK.
  • Page 29: Installation

    4 INSTALLATION...
  • Page 30: Mounting Clearances

    4 INSTALLATION 4.1 Mounting Clearances For proper operation of this product, make air aperture at the top and bottom of the cubicle. This cubicle and each unit should be installed with certain spaces as indicated below. Cubicle 50 mm or more CPU unit 50 mm 50 mm...
  • Page 31: Outside Dimensions

    HITACHI 100-120VAC 100-120VAC DC5V SERVICE CHECK Center POWER AC100-120V Power supply module IR.Station module DI module DI module Front view (example of 2-slot mount base use) 2-slot mount base Top view (Unit: mm) Figure 4-2 Unit Dimensions - 21 -...
  • Page 32: Securing The Mount Base

    4 INSTALLATION 4.3 Securing the Mount Base Fasten the mount base to a vertical surface of the enclosure. Do not install mount base upward, downward, or sideways. The modules are designed to produce optimum heat dissipation effects when they are fastened to a vertical plane of the cubicle. M5 15 Cubicle M5 15...
  • Page 33: Securing The Module

    4 INSTALLATION 4.4 Securing the Module 2-slot mount base Phillips screwdriver insertion slot Figure 4-4 Mounting the Module Insert a screwdriver from an insertion groove to tighten the screws to fix the module. Phillips screwdriver (#2) Module mounting screw (supplied with the module) Module Mount base Figure 4-5 Securing the Module...
  • Page 34: Figure 4-6 Module Mounting Examples

    4 INSTALLATION DANGER You may be electrified if you install/remove a module or connect/disconnect a cable when power is ON by inadvertently touching a power supply terminal due to the presence of a high voltage. Also, note that a short circuit or noise may render the machine defective.
  • Page 35: Cabling

    5 CABLING...
  • Page 36: Grounding And Wiring The Power Module

    IR.LINK module of the CPU unit to the FG terminal of the CPU unit mount base and the FG terminal of the IR.Station module of the I/O unit to the FG terminal of the I/O unit mount base respectively. This connection puts their grounding potentials at the same level, makes the grounding performance higher, and consequently increases the noise resistance.
  • Page 37 5 CABLING An example of wiring when modules in different I/O units are connected When connecting modules in different I/O units, leave the FG terminal of the IR.Station module open. If connected, the noise resistance will decrease because of different grounding potentials.
  • Page 38: Connecting The Line Cables

    5 CABLING 5.2 Connecting the Line Cables Always terminate the CPU module (master station) and the IR.Station module which are at both ends of the line. The terminating resistance is 120 ohms (built-in) or any (externally connected). When using an external terminating resistor, select it according to the characteristic impedance of the cable.
  • Page 39: Inhibited Wiring

    CPU unit I/O unit I/O unit I/O unit Termination Termination IR.LINK IR.Station IR.Station IR.Station A maximum of 31 units can be connected to one line and units at both ends of the line must be terminated. I/O unit I/O unit...
  • Page 40: Example Of Connecting Line Cables

    5 CABLING 5.2.2 Example of connecting line cables An example below shows a cable connection of the IR.LINK module (LQE046) and IR.Station modules. IR.LINK module Field net terminals (LQE046) LQE046 IR.LINK Signal name Terminal MODU number RATE Termination with Symbol...
  • Page 41: Cable Specifications

    2500 MΩ・km 20℃ Minimum insulation resistance Static capacity 50 pF/m 1 kHz Recommended cable KPEV-SB 2P 0.5 mm Made by Hitachi type Cable, Ltd. Power supply cable Wire type Shielded twisted-pair cable or 3-core twisted cable Wire size 2 mm...
  • Page 42 THIS PAGE INTENTIONALLY LEFT BLANK.
  • Page 43: Setting

    6 SETTING...
  • Page 44: I/O Address Setting

    6 SETTING 6.1 I/O Address Setting (1) Input and output modules can be mounted any place in the mount base (free location). A module in a slot always has the same I/O address whether the module is an input module or an output module.
  • Page 45: Startup Procedure

    6 SETTING 6.2 Startup Procedure Start Check wiring (particularly the power supply wiring). Set the rotary switch correctly. Check the rotary switch setting. Check the number of points of the Set the number of points of I/O module. the I/O module correctly. Turn on power.
  • Page 46 THIS PAGE INTENTIONALLY LEFT BLANK.
  • Page 47: Maintenance

    7 MAINTENANCE...
  • Page 48: Preventive Maintenance

    7 MAINTENANCE 7.1 Preventive Maintenance For optimum use of the S10mini, it is essential that you carry out the following maintenance ever now and then (at least 2 times a year). Preventive maintenance items Module appearance check Screw/terminal strip screw looseness check Cable/wire coating check Dust adhesion check AC supply voltage check (85 to 132 V)
  • Page 49: Figure 7-1 Life Expectancy Of Relay

    7 MAINTENANCE Dust adhesion check Check if dust or other foreign matter adhered on the module. If any dust/foreign matter buildup is found, remove it with a vacuum cleaner. If you allow dust or other foreign matter to build up, the internal circuitry may be shorted or to cause a component burnout. Supply voltage check Check that the voltages of the module power supply and externally supplied power are within the specified ranges.
  • Page 50: Troubleshooting

    All items OK? Take proper action against the wrong items. Recovered normally? Check the contents of the ERR indicator, S register, and S table. Recovered normally? Contact your nearest Hitachi Troubleshooting ended Service Center. - 40 -...
  • Page 51: Preliminary Checks To Be Completed Before Troubleshooting

    Is the wiring OK? • Check whether the cables are connected correctly and firmly. Is the IR.Station module mounted correctly? • Check whether the IR.Station module is mounted correctly and mounting screws are tightened firmly. Is the terminal block fit for the module? •...
  • Page 52: Error Indication

    7 MAINTENANCE 7.3 Error Indication When detecting a hardware error, the IR.Station module turns on (or blinks) the ERR indicator. Turn off the power, turn it on again and make sure the ERR indicator is off. If the ERR indicator is on (or blinking) again, replace the IR.Station module. The ERR indicator turns on...
  • Page 53 8 SPECIFICATIONS...
  • Page 54: Table 8-1 Module Specifications

    Electric interface RS-485 2 shielded twisted-pair cables Type Recommended cable: KPEV-SB, 2P, 0.5 mm (made by Hitachi Cable, Ltd.) Dependent upon the transmission speed as shown below. Cable Transmission speed ≦ 1.0 Mbps 240 m (maximum) Transmission speed ≦ 0.5 Mbps...
