Hitachi RU-1500JY Operating Instructions Manual

Hd color camera system remote control unit.
Hide thumbs


Advertisement

Additional information
Please read this operating instruction carefully for proper operation,
and keep it for future reference.
Note: The model and serial numbers of your product are important for you to keep for your
convenience and protection. These numbers appear on the nameplate located on bottom of
the product. Please record these numbers in the spaces provided below, and retain this
manual for future reference.
Model No.
HD COLOR CAMERA SYSTEM
REMOTE CONTROL UNIT
RU-1500JY
OPERATING INSTRUCTIONS
Serial No.
R1

Advertisement

   Summary of Contents for Hitachi RU-1500JY

  • Page 1

    Additional information HD COLOR CAMERA SYSTEM REMOTE CONTROL UNIT RU-1500JY OPERATING INSTRUCTIONS Please read this operating instruction carefully for proper operation, and keep it for future reference. Note: The model and serial numbers of your product are important for you to keep for your convenience and protection.

  • Page 2

    Procedure for Ethernet connection Connection Diagram The power of RU-1500 is supplied thorough the control cable. Therefore the control cable should be connected to the CCU even on Ethernet connection. The power cable(C-101ET) services the power of XLR4pin. (NOTE) The version for CCU supporting Ethernet connection is CU-HD1000: V 2.00 or later TU-HD1000: V 1.00 or later Power cable(C-101ET)

  • Page 3: Lcd Menu

    LCD menu 5.4.6 ETHERNET menu (CONFIG) & description. Item Setting RU-1500 Description Initialize ETHERNET ON/OFF OFF OFF:Remote control mode ON:ETHERNETmode Move to local address setting LOCAL ADDRESS menu Move to a menu that an REMOTE SELECT address setting of the connected CCU.

  • Page 4

    LCD menu 5.4.6 (4) ETHERNET(LOCAL.Netmask) menu (CONFIG) & description. Set the local Netmask by the Rotary encoder 1 to 4. Item Setting RU-1500 Description Initialize Store the new setting, and then move to previous page. Cancel the new setting, and CANCEL then move to previous page.

  • Page 5

    LCD menu 5.4.6 (7) ETHERNET(REMOTE.IP ADDRESS.CONNECT) menu (CONFIG) & description. A disconnection message will be displayed to press the CONNECT button at CONNECT ON. YES: Disconnected from the network. NO: Connecting to the network is continued. A connection message will be displayed to press the CONNECT button at CONNECT OFF.

  • Page 6

    LCD menu 5.4.6 (8) ETHERNET(REMOTE.IP ADDRESS.CONFIG) menu (CONFIG) & description. Set the IP address to connect by Rotary encoder 1 to 4. Item Setting RU-1500 Description Initialize Store the new setting, and then move to previous page. Cancel the new setting, and CANCEL then move to previous page.
