PCAN-Router Pro – User Manual
8 - 27 V power supply, protection against overvoltage and
reverse polarity
Extended operating temperature range from -40 to 85 °C (-40 to
185 °F)
Properties of the standard firmware:
Detailed configuration with the software PPCAN-Editor 2 for
Windows
Various function blocks for data processing and manipulation
Configurable beeper
Configurable CAN channel status LEDs
Recording of CAN data and error frames to a CompactFlash card
Conversion of logging data to various output formats using the
Windows software PEAK-Converter
1.2

Operation Requirements

Voltage supply 8 – 27 V DC (e.g. car battery)
For configuring via CAN (standard firmware):
• Computer with CAN interface of the PCAN series
(e.g. PCAN-USB)
• CAN cabling with correct termination
• Windows 10 or 8.1 (32/64-bit) for the configuration
program
For converting logged CAN data:
• Computer with card reader for CompactFlash cards
• Windows 10 or 8.1 (32/64-bit) for the conversion program
7
