PCAN-Router Pro – User Manual
The PCAN-Router Pro package can be downloaded from the product
page under Downloads or from the following page:
www.peak-system.com/quick/DL-Packages-E
This configuration has following properties:
All incoming messages from the four CAN channels are written
to an inserted CompactFlash card.
No forwarding is done between the four CAN channels.
The LEDs for the CAN ports blink during CAN traffic; LEDs 1, 3,
5, and 7 (green) for incoming, LEDs 2, 4, 6, and 8 (red) for
outgoing CAN messages.
Via CAN channel 1 status CAN messages are provided for
request (RTR) containing information related to the logging
function and the CompactFlash card (see following tables).
Optionally: The battery buffered real-time clock (RTC) can be set
and recalled via CAN channel 1 (see section 5.4
Time Clock
5.3.1

Structure of the Status Messages

Applies to the standard firmware.
CAN Property
ID
Data length
Transmit cycle
time
RTR
Format
Data
on page 32).
Message GetTraceStatus_R
7F0h
4 bytes
none (0 ms)
yes
Intel (Little Endian)
See following table
30
Setting the Real-
