PCAN-Router Pro – User Manual
3.1

Alternative CAN Transceiver Modules

An alternative CAN transceiver module can be used for each of the
four CAN connections. The PCAN-Transceiver TJA1041 is preinstalled
by default. The following alternative modules are supported:
Order
Number
IPEH-001001 PCAN-Transceiver
Default
IPEH-001002 PCAN-Transceiver
IPEH-001003 PCAN-Transceiver
IPEH-001004 PCAN-Transceiver
IPEH-001005 PCAN-Transceiver
Do the following to replace a transceiver module:
Attention! Electrostatic discharge (ESD) can damage or destroy
components on the circuit board of the PCAN-Router Pro. Take
precautions to avoid ESD when handling the circuit board.
1. Disconnect the power supply.
2. Unscrew the four screws at the upper corners of the
housing on the front and back.
3. Remove the housing cover.
4. Unscrew the two screws at the lower corners of the front
cover.
5. Pull out with the front panel the board from the bottom side
of the housing to the front.
Name
TJA1041
PCA82C251
MAX3057-ISO
TH8056
TJA1055
Transmission
Standard
High-Speed-CAN
ISO 11898-2
High-Speed-CAN
ISO 11898-2
High-Speed-CAN
ISO 11898-2
Single-Wire-CAN
SAE J2411
Low-Speed-CAN
ISO 11898-3
13
Bit Rate Wake-
up
40 kbit/s to yes
1 Mbit/s
5 kbit/s to no
1 Mbit/s
5 kbit/s to no
1 Mbit/s
1.3 kbit/s yes
to 40 or
100 kbit/s
20 kbit/s to yes
125 kbit/s
Galvanic
Isolation
no
no
yes
no
no
