TABLE
I
OF CONTENTS
SECTION 1 OPERATING INSTRUCTIONS
Introduction
Instrument Description
installation and Removal
Operating Considerations
Output Terminations and Connections
Maintaining Pulse Fidelity
Impedance Matching
RisetimE Measurements In Linear Systems
Variable Pulse Delay
Operating Mode?.
Period and Duration Selection
output Levels
External Trigger
External Duration
Eunctions Available at Rear Connector
Definitions Of Pulse Characteristics
Specifications
Performance Conditions
SECTION 2 THEORY OF OPERATION
Introduction
Low Frequency Period Generator
4ns Period Generator
External Trigger Duration Buffer
Manual Trigger Multivibrator
Period and Trigger Out Buffers
Trigger Shaper
Duration Generator
Output Buffer
Output Driver
Output Amplifier
output Level Programmer
Power Supply
SECTION 3 SERVICE INFORMATION
Symbols and Reference Designators
Rear Interface Connector Assignments
Electrical Parts List
Internal Adjustment Procedure
Timing Board Parts Location Grid
Front Panel Controls and Connectors
Block Diagram
Output Board Parts Location Grid
Generators and Trigqer Schematic
Output Schematic
Switch Details and Power Supply Schematic
Mechanical Parts List
Exploded View
Accessories and Repackaging
