Legacy Flexzilla L1388LFZ Owner's Instructions page 4

WARNINGS / TIPS / WARRANTY (CONT.)
SYMBOLS
DC .....................................................................................................................................direct current
--- .......................................................................................................................... direct current symbol
V ..................................................................................................................................................... volts
Hz .................................................................................................................................................. hertz
psi ....................................................................................... pounds per square inch (units of pressure)
SPECIFICATIONS
• Model: L1388LFZ 20V DC Cordless Grease Gun
• Grease Reservoir Capacity: 14.5 oz. cartridge or 16 oz. bulk
• Lubricant (grease): Up to NLGI #2
• Battery Quick Charge: 1 hour charger
FUNCTIONAL DESCRIPTION
The Flexzilla 20V DC battery-powered, cordless grease gun allows convenient high-pressure greasing at grease pressures up to 7000 psi, utilizing a motor and set of gears to develop pressure for
dispensing grease as a single-action, positive displacement pump. The gun is operated (after grease-loading) by squeezing the trigger to dispense grease either freely from the grease nozzle (standard
zerk coupler) or by engaging the grease coupler onto standard grease zerk fittings on equipment and machinery for high-pressure greasing. The gun is equipped with a pressure-relief valve to limit grease
pressure to 7000 psi to reduce risk of motor overload, tool damage, and to extend battery life. Additionally, an automatic bleeder valve bleeds trapped air in the grease barrel to make priming faster and
easier. Do not exceed specifications or alter gun to perform beyond ratings. Such misuse will void the warranty.
WARRANTY*
LEGACY MANUFACTURING COMPANY ("LEGACY") warrants that this equipment will be free from defects in material and workmanship for a period of one (1) year from the date of purchase, under
normal use. LEGACY'S sole obligation under this warranty is limited to replacing or repairing, free of charge, any equipment that proves to be defective under normal conditions and use according to the
recommendations of LEGACY. To obtain repair or replacement, the equipment must be shipped to a LEGACY authorized Warranty and Service Center during the warranty period, transportation charges
prepaid, with proof of date of purchase. In the event of repair or replacement, the warranty period shall not be extended beyond the original warranty period. While necessary maintenance or repairs
on your Legacy equipment can be performed by any company, we recommend that you use only authorized Legacy service centers. Improper or incorrectly performed maintenance or repair voids this
warranty. Contact us at service@legacymfg.com or www.legacymfg.com for ordering or installation instructions.
4
AC ........................................................................................................................ alternating current
UL ............................................................................... Underwriter's Laboratories listing on charger
+ .................................................................................Positive terminal on battery pack and charger
- ................................................................................ Negative terminal on battery pack and charger
UL745-3 ...............................................................UL Standard for Safety for Battery-Operated Tools
• Maximum Operating Pressure: Intermittent pressure: 7000 psi
• Battery Voltage: 20v max / 18v nominal
• Battery Capacity: 1500 milliamp hours
• Input Power Source: 120V AC
