Legacy Flexzilla L8232FZ Manual

Owner's Instructions
Part No.: L8232FZ
Retractable Air Hose Reel, 30 ft.
Carrete retráctil para mangueras de aire de 9 m
Dévidoir de tuyau à air comprimé rétractable de 9 m de long
CAUTION: Read all instructions and warnings before operating this product.
CAUTION: Inspect hose before each use. Do not exceed 150 psi working pressure. Do not kink, twist, knot
or abrade hose. Do not wrap hose around body. Keep hose away from hot surfaces and/or chemicals. KEEP
CHILDREN AWAY FROM WORK AREA!
CAUTION: When using treated wipes or silicone-based lubricant, keep away from children. Wipe is not for use on skin. After use, wash
with soap and warm water. Do not ingest wipe or fluid from wipe. Keep away from eyes, nose, and mouth. Before using any wipe
product or silicone-based lubricant product, follow instructions and cautions on wipe or silicone product packaging. Dispose of any
waste material according to local regulations.
SAFETY INSTRUCTIONS
• Do not allow tools to hang on the end of the hose when not
in use. Do not allow the hose to contact hot, sharp or heated
surfaces that could damage it. Always recoil hose back into
the reel when work is completed.
• Do not allow hose to retract uncontrolled.
INSTALLATION
MOUNTING OPTIONS
Mounting on wall:
Recommended height is 5 ft. (1.5 m) to 8 ft. (2.5 m)
Mounting overhead:
Recommended ceiling height is 8 ft. (2.5 m) to 10 ft. (3 m)
• Choose fasteners suitable for the mounting surface, the
weight of the reel, and the force of pulling the hose.
Use a leveling device for proper positioning.
• See mounting diagram on last page.
• Use hex head fasteners up to 5/16" (8 mm) in diameter,
with a (minimum) ½" (12.5 mm) hex head.
Mounting fasteners not included.
Wall Installation:
1. On hose reel, locate the pivots at bracket ends.
2. Observe both sides of reel housing and remove screws
that hold bracket pivots in reel. Retain screws. Remove
pivots from reel and bracket.
3. Mount bracket to surface. Mounting fasteners not included.
4. Re-install reel to bracket with the pivots. Replace screws.
Ceiling / Overhead Installation:
Important: Use of the third mounting hole is required for
The color CHARTREUSE as applied to the body of the air hose is a registered trademark owned by Weems Industries, Inc.
El color CHARTREUSE aplicado a la manguera de aire es marca registrada es propiedad de Weems Industries, Inc.
La couleur CHARTREUSE telle qu'elle est appliquée sur le corps du tuyau à air est une marque de commerce de Weems Industries, Inc.
Legacy Manufacturing Company
Marion, IA, 52302 USA
SAVE THESE INSTRUCTIONS! READ ALL INSTRUCTIONS!
Ph: 319.373.7305
Fx: 319.373.7309
overhead installation to prevent reel from becoming
unmounted while pulling the hose
1. Perform steps 1-3 for "Wall Installation".
2. After completing steps 1-3 from "Wall Installation", install a
third fastner through the bracket's center hole.
3. Re-install reel to bracket with the pivots. Replace screws.
OPERATION
The retractable hose reel can lock the air hose at any length.
1. Latching Hose -
After pulling out the desired length of hose, allow it to
retract slightly until you feel it stop. The reel is now latched.
2. Rewinding Hose -
Pull out approximately one extra foot from latch position and
allow hose to retract. The reel will continue rewinding until
hose is fully retracted. Do not allow the hose to rewind
uncontrolled back into the reel. Personal injury can result.
