Installing the EME
1 Before you start the installation process, read "Safety Precautions" and
2 To expose a slot for the module, remove a blank faceplate from slot 8 or
3 Open the module ejector handles (Figure 3).
4 Insert the module into the module guides:
5 Slide the EME module into the chassis by pressing firmly on the front
Install at least one EME (Model Number 3CB9EME) in each
CoreBuilder 9000 chassis. Each chassis has two slots that are dedicated
for EME installation (slot 8 and slot 9 in the 7-slot chassis, slot 9 and slot
10 in the 8-slot chassis, and slot 17 and slot 18 in the 16-slot chassis).
You can install the first EME in either slot. You can only install one of the
following modules in the second slot:
A second EME for standby management support
An EMC for standby controller support
You do not need to power off the CoreBuilder 9000 chassis to install,
remove, or replace the EME module. You can insert the module while the
chassis is operating. (This is called a hot swap.)
To install an EME module:
"Handling Precautions" earlier in this guide.
slot 9 in the 7-slot chassis, from slot 9 or slot 10 in the 8-slot chassis, or
from slot 17 or slot 18 in the 16-slot chassis.
WARNING: Hazardous energy levels exist inside the chassis. Do not place
hands or objects into the chassis or touch any components on an installed
module.
For a 7-slot chassis, hold the module horizontally with the LEDs at the
left. The module guides are on the left and right of the slot.
For the 8-slot chassis and 16-slot chassis, hold the module vertically
with the LEDs at the top. The module guides are at the top and
bottom of the slot.
CAUTION: Be careful not to twist or bend the EME module while you
insert it into the chassis.
panel. Figure 3 shows how to install the module into a 16-slot chassis.
Enterprise Management Engine Quick Start Guide 9
