12 Enterprise Management Engine Quick Start Guide
Connecting to a
Terminal or Modem
Troubleshooting the
EME
You need to connect a PC, terminal, or modem to the EME console port
to enter commands to configure and monitor your chassis and EME. You
can manage your system locally through a terminal connection or
remotely using a Telnet or modem connection.
To connect the EME to a terminal or modem, use either the RS-232
Console Port (RS-232) or the RS-232 Auxiliary Port (AUX) connectors that
are located on the EME front panel.
The EME uses male 9-pin connectors. For information about pin
connector assignments and the cable, see Chapter 2 of the
CoreBuilder 9000 Enterprise Management Engine User Guide.
Table 3 describes the access types and what each access type allows you
to do.
Table 3 Access Types
Access
Type Allows you to
Terminal Connect directly to the command interface.
Modem Access the command interface from remote sites. Auxiliary RS-232
IP Access the command interface using the
rlogin or telnet commands. Or use an
external SNMP management application to
communicate with the CoreBuilder
agent.
If the EME character display shows
one of these error conditions exists:
The expansion card is incorrectly installed.
The on-board DRAM failed.
If one of these error conditions exists, remove and reinstall the expansion
memory card.
Using
RS-232 serial port
serial port (AUX)
10BASE-T Ethernet
port assigned to an
IP interface
®
9000 SNMP
when you power on the EME,
CARD
