1. Module Overview

1. Module Overview
1.1 Features
MCU
• ESP32 embedded, Xtensa
microprocessor, up to 240 MHz
• 448 KB ROM for booting and core functions
• 520 KB SRAM for data and instructions
• 16 KB SRAM in RTC
Wi-Fi
• 802.11b/g/n20/n40
• Bit rate: 802.11n up to 150 Mbps
• A-MPDU and A-MSDU aggregation
• 0.4 µs guard interval support
• Center frequency range of operating channel:
2412 ~ 2462 MHz
®
Bluetooth
• Bluetooth V4.2 BR/EDR and Bluetooth LE speci-
fication
1.2 Description
The ESP32-PICO-V3-ZERO is a module that is based on ESP32-PICO-V3, a System-in-Package (SiP) device. It
provides complete Wi-Fi and Bluetooth
At the core of this module is the ESP32 chip, which is a single 2.4 GHz Wi-Fi and Bluetooth combo chip designed
with TSMC's 40 nm low-power technology. ESP32-PICO-V3-ZERO integrates all peripheral components seam-
lessly, including a crystal oscillator, flash, filter capacitors and RF matching links in one single package. Module
assembly and testing are already done at SiP level. As such, ESP32-PICO-V3-ZERO reduces the complexity of
supply chain and improves control efficiency.
With its ultra-small size, robust performance and low-energy consumption, ESP32-PICO-V3-ZERO is well suited
for any space-limited or battery-operated applications, such as wearable electronics, medical equipment, sensors
and other IoT products.
Note:
• For more information on ESP32, please refer to
• For more information on ESP32-PICO-V3, please refer to ESP32-PICO-V3 User Manual.
Espressif Systems
®
dual-core 32-bit LX6
®
functionalities. The module integrates a 4 MB SPI flash.
ESP32 User
• NZIF receiver with –97 dBm sensitivity
• Class-1, class-2 and class-3 transmitter
• AFH
• CVSD and SBC
Hardware
• Interfaces: 3 × UART, I
pin, EN pin, interrupt pin and other GPIOs
• 40 MHz crystal oscillator
• 4 MB SPI flash
• Operating voltage/Power supply: 3.0
• Operating temperature range: –40
• Dimensions: (16 × 23 × 2.3) mm
Certification
• Bluetooth certification: BQB
• RF certification: FCC/CE-RED/SRRC/IC
• Green certification: REACH/RoHS
Manual.
2 2
C, I S, SPI, SDIO, touch
~ 3.6 V
~ 85 °C
