Introduction

Major Components

Safety

operation
Extending the Room
Retracting the Room
Manually Overriding the Slide-Out
Maintenance
Introduction
The electric slide-out system is designed to provide years of trouble free operation and reflects the latest
state-of-the-art technology.
Note: Information for this document was obtained from Power Gear manual #82-S0380 Rev. 0B issued
May 2008. All information has been updated for current practices.
Read, study and understand all instructions in this manual before operating the electric
Major Components
The slide-out system is a rack and pinion design operated by a 12 V DC electric motor.
• Inner rail assemblies are designed to support the room weight.
• The 12 V DC gear motor will operate the room using power from the on board unit battery.
• Slide-out systems are equipped with a manual override that extends or retracts the room in the event of a
loss of power.
Safety
Always make sure that the slide-out room path is clear before and during operation
Always keep away from the slide-out rails when the room is being operated. the gear assembly may
Always utilize a room locking device on the slide-out room during storage and transportation.
Failure to follow these instructions could result in serious injury or death.
Rev: 04.04.19
tABLe oF CoNteNtS
motor driven slide-out system.
of the slide-out room.
pinch or catch on loose clothing causing personal injury.
