Troubleshooting
Troubleshooting Introduction
This troubleshooting chart outlines some common problems, their causes and possible corrective actions.
If any part or serial number information is available, provide it to the service technician when asking for
assistance.
The Through Frame Electric Slide-out System is only one of four interrelated slide-out room system
components. These four components are: chassis, room, coach, and Through Frame Electric Slide-out
System. Each one needs to function correctly with the others or misalignment problems will occur.
Every travel trailer has its own personality and what may work to fix one trailer may not work on another
even if the symptoms appear to be the same.
When something restricts room travel, system performance will be unpredictable. It is very important that
slide tubes be free of contamination and allowed to travel full distance (stroke). Ice or mud buildup during
travel is an example of a type of contamination that can occur.
When you begin to troubleshoot the system, make sure the battery is fully charged, there are no visible
signs of external damage to the system and that all connections are secure.
During troubleshooting, remember that if you change something, that change may affect something else.
Be sure any changes you make will not create a new problem.
What Is Happening?
Room doesn't move when
switch is pressed.
Actuator motor runs but room
does not move.
Motor runs but room moves
slowly.
Room stalls in mid-travel.
Rev: 11.11.20
THROUGH FRAME ELECTRIC
SLIDE-OUT TROUBLESHOOTING
Why?
Restriction or obstruction inside or
outside of unit
Low battery voltage, blown fuse,
defective wiring.
Actuator not attached to front
mounting drive bracket.
Bad motor or gear housing.
Low battery voltage, poor ground,
extremely low outdoor temperature.
Room is in a bind.
Actuator in a bind.
Bad actuator.
Page 1
What Should Be Done?
Check for and clear obstruction.
Check battery voltage and charge
if needed. Find and check fuse,
replace if blown. Check battery
terminals and wiring. Look for
loose, disconnected or corroded
connectors.
Check jam nuts/nylock nuts.
Be sure that they are properly
tightened and adjusted.
Replace motor.
Charge battery and check ground
wire.
Check to see that room is
properly adjusted.
Crank manual override and move
room short distance then retry
electric switch to move room.
Replace actuator if above
instructions do not work.
