- Page 1 Electric Motor Slide-out OWNER'S MANUAL...
- Page 2 The electric slide-out system is designed to provide years of trouble free operation and reflects the latest state-of-the-art technology. Note: Information for this document was obtained from Power Gear manual #82-S0380 Rev. 0B issued May 2008. All information has been updated for current practices.
- Page 3 operation Extending the Room Level the coach. Verify the battery is fully charged and hooked up to the electrical system. If so equipped, remove the transit bars. Make sure the room path is clear, both inside and outside the coach. Check the slide-out awning.
- Page 4 After the previous items have been checked and the room still does not move when the slide-out switch is pressed, follow these simple steps to manually override the slide-out room. Locate applicable slide-out motor from Figure 1. A. The motor is located in the top of the center storage compartment under the slide-out room. B.
- Page 5 Fig. 3 Fig. 4 Rotate approximately 30 degrees counterclockwise to release motor brake. 0° " Hex. override Motor Leads Again, check the slide-out awning. Some awnings must be manually locked before traveling. If so equipped, re-install transit bars. 10. Take the coach to an authorized dealer for service. Maintenance The slide-out system has been designed to require very little maintenance.
- Page 6 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
