ANR-C62xN1
Networking 2U Rackmount Server
®
®
• Intel
Xeon
®
• 8x Acrosser
(for 1G/10G/25G/40G, Fiber/Copper/LAN Bypass)
• 2x SFP+ (10G Fiber)
• 1x Management Port
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com
+ C627/C622 PCH
Swappable Expansion NIM
ANR-C62xN1 Series
Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANR-C62 N1Series and is the answer not in the manual?

Questions and answers

Related Manuals for Acrosser Technology ANR-C62 N1Series

Summary of Contents for Acrosser Technology ANR-C62 N1Series

  • Page 1 Series Networking 2U Rackmount Server ® ® • Intel Xeon + C627/C622 PCH ® • 8x Acrosser Swappable Expansion NIM (for 1G/10G/25G/40G, Fiber/Copper/LAN Bypass) • 2x SFP+ (10G Fiber) • 1x Management Port User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    ANR-C62xN1 Series Table of Contents 1. Introduction ..............5 1.1. Models ........................5 1.2. Specifications ......................6 1.3. Packing List ........................ 7 1.4. Layout & Dimension ....................8 1.5. Front Panel ......................... 9 1.5.1. Module A: Network expansion module connector ........... 9 1.5.2.
  • Page 4 4.3.4. Power Supply Unit (PMBUS) ................ 49 4.3.5. Pmbus Command Code Summary ............... 50 4.3.6. Chassis Opened .................... 54 4.3.7. Notes ......................54 5. FAQ ................56 Q 1. Where can I find the serial number of this product? ..........56 Acrosser Technology Co., Ltd.

  • Page 5: Introduction

    ANR-C62xN1 Series Introduction Acrosser’s brand new 2U rack mount server, ANR-C627/622N1 series, are designed ® with X86 processor and positioned for Intel Xeon-based 2U network appliances which require high-performance computing (HPC) and multi-core (up to 28 cores) with hyper-threading (HT) functionality for a wide range of workloads with high memory bandwidth (DDR4-2666) and capacity.

  • Page 6: Specifications

    • SYS FAN Speed Security & Mgmt. • On-board TPM 2.0 • Chassis Intrusion Detection (default: Disable) OS support • Linux Kernel 4.4 or above, (64-bit) • DPDK for ANR-C62xN1(U) series • QAT for ANR-C627N1(U) series Acrosser Technology Co., Ltd.

  • Page 7: Packing List

    ANR-C62xN1 Series Mechanical & Environment Chassis Dimension • 440 (W) x 88.5 (H) x 670 (D) mm Operating Temperature • 0 ~ 40°C (32 ~ 104°F) Storage Temperature • -20 ~ 80°C (-4 ~ 176°F) Relative Humidity • 0 ~ 90% @40°C, non-condensing Power Supply Unit •...

  • Page 8: Layout & Dimension

    ANR-C62xN1 Series 1.4. Layout & Dimension (Illustration model: ANR-C62xN1 with 8x optional LAN modules) 440.00 Acrosser Technology Co., Ltd.

  • Page 9: Front Panel

    ANR-C62xN1 Series 1.5. Front Panel 1.5.1. Module A: Network expansion module connector Available LAN Modules: Note: The model name, type number, or layout design of these options might change due to product revision. 1. ACC-NM1Z1-01C8B: 1G Copper x8 (RJ-45 w/ 4-pair Bypass) 2.
  • Page 10 ANR-C62xN1 Series 3. ACC-NM1Z1-01F8: 1G Fiber x8 (SFP) 4. ACC-NM1Z1-01H8B: 1G Hybrid x8 (SFP + RJ-45 w/ 2-pair Bypass) 5. ACC-NM1Z1-01H8: 1G Hybrid x8 (SFP + RJ-45) 6. ACC-NM1Z1-10F2: 10G Fiber x2 (SFP+) Acrosser Technology Co., Ltd.
  • Page 11 ANR-C62xN1 Series 7. ACC-NM1Z1-10F4: 10G Fiber x4 (SFP+) 8. ACC-NM1Z1-40F1: 40G Fiber x1 (QSFP+) 9. ACC-NM1Z1-40F2: 40G Fiber x2 (QSFP+) 10. ACC-NM1Z1-01C4B: 1G Copper x4 (RJ-45 w/ 2-pair Bypass) www.acrosser.com...
  • Page 12 ANR-C62xN1 Series 11. ACC-NM1Z1-01C4: 1G Copper x4 (RJ-45) 12. ACC-NM1Z1-01F4: 1G Fiber x4 (SFP) Acrosser Technology Co., Ltd.

  • Page 13: Hdd Trays

    ANR-C62xN1 Series 1.5.2. HDD Trays 4x 2.5” SATA3 Hot-swappable HDD trays (for ANR-C62xN1). 2x U.2 NVMe|SATA3 Hot-swappable HDD trays (for or ANR-C62xN1U). 1.5.3. SFP+ 10GbE LAN Ports Light Status Blue On 10Gbps Blue 1Gbps or below If this LAN port funtion fail after connected a 1GbE module, you may try the following steps: Step 1: Remove the 1GbE module from the LAN port.

  • Page 14: Lan / Console / 2X Usb 3.0 / Reset

    Either M.USB or RJ45 console can only be used only one at a time. • Reset System Reset Button • Console (RJ45) Pin # Signal Pin # Signal SOUT • Light Status 10Mbps LED2 Orange 100Mbps Green 1000Mbps Yellow Link/Active LED1 LAN Off Acrosser Technology Co., Ltd.

  • Page 15: Lcm Display / Navigation Joystick / Indicators

    ANR-C62xN1 Series • Standard USB 3.0 Type-A connector 1.5.5. LCM Display / Navigation Joystick / Indicators Navi. Joystick IPMI • LCM Display 128 * 32 Pixels Graphic mode only • Navigation Joystick LCM menu control buttons (Up/Down/Left/Right/Center) • IPMI IPMI indicator (Green) •...

  • Page 16: Rear Panel

    • AC Inlets 1+1 CRPS 2U Redundant ATX PSU • System Fan 4x Hot-swappable Smart Cooling Fans with 2-color LED (Green->Normal, Orange->Warning) • 2x USB 2.0 ports • VGA connector • Power Switch Power on/off switch Acrosser Technology Co., Ltd.

  • Page 17: Installation

    ANR-C62xN1 Series Installation To mount this server into a rack, you will need to do some preparation. 2.1. Package List Check the following items. Item Description Q’ty RJ45-console cable RJ45 <-> DB9 USB-console cable Micro-B <-> Type A Ear Bracket Screw Pack www.acrosser.com...

  • Page 18: Screw List

    Description Q’ty M4x6 (black) For ear bracket M3 Screw For 2.5” HDD with sponge (yellow) 6#32 Screw For 3.5” HDD with sponge (yellow) Sponge (yellow) For 2.5” & 3.5” HDD M3x4 (sliver) For HDD bay (2.5”-7mmx4) Acrosser Technology Co., Ltd.
  • Page 19 ANR-C62xN1 Series #1: Ear brackets #2: 2.5” HDD with sponge www.acrosser.com...
  • Page 20 ANR-C62xN1 Series #3: 3.5” HDD with sponge #5: 7mm-HDD bay with screws Acrosser Technology Co., Ltd.

  • Page 21: Slide-Rail Assembly

    ANR-C62xN1 Series 2.2. Slide-rail Assembly 1. Slide-rail & Screw: 2. Screw List: www.acrosser.com...
  • Page 22 Step 2: Fasten both inner brackets by M4x4 screws to each of the server’s left and right side. Step 3: Fasten both ear brackets by M4x6 (black) screws to each of the server’s left and right side. Acrosser Technology Co., Ltd.
  • Page 23 ANR-C62xN1 Series Step 4: Install the slide-rail with M5x15 screws on both sides of the rack. The length can be adjusted with the 7mm-nut. www.acrosser.com...
  • Page 24 ANR-C62xN1 Series Step 5: Slide the server in. Note: The slide-rail will stop and lock in center position. Poke to push it in or pull out. Acrosser Technology Co., Ltd.

  • Page 25: Pcie Card Installation

    ANR-C62xN1 Series 2.3. PCIe Card Installation Step 1: Open the top cover. The red-line frame is marked as the position to insert the add-on PCIe card. Remove the 2 screws shown in the red circle to remove the bracket. Step 2: Remove the 7 screws shown in the red circle of the next three figures, and then remove the bracket.
  • Page 26 ANR-C62xN1 Series Acrosser Technology Co., Ltd.
  • Page 27 ANR-C62xN1 Series Step 3: Remove the 2 screws shown in the figure below, and remove the 2 bracket plates. Step 4: Insert the add-on PCIe card into position. www.acrosser.com...
  • Page 28 ANR-C62xN1 Series Step 5: Lock all the screws back. Acrosser Technology Co., Ltd.
  • Page 29 ANR-C62xN1 Series Step 6: Adjust the bracket position according to the length of add-on card to clamp the card firmly. Lock the screws. www.acrosser.com...

  • Page 30: Bios Settings

    Total Memory 16384 MB Enter: Select usable Memory 16384 MB +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 31: Advanced Setup

    ANR-C62xN1 Series 3.2. Advanced Setup Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Platform Configuration Socket Configuration Security Trusted Computing Trusted Computing W83627DHG Super IO Configuration Settings W83627DHG HW Monitor Serial Port Console Redirection PCI Subsystem Settings USB Configuration Network Stack Configuration CSM Configuration...

  • Page 32: Trusted Computing

    Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc. • Change Settings Change the IO &IRQ Resource Settings. Acrosser Technology Co., Ltd.

  • Page 33: W83627Dhg Hw Monitor

    ANR-C62xN1 Series • Serial Port Enable/Disable Serial Port. 3.2.3. W83627DHG HW Monitor Dsiplays hardware monitor status. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced PC Health Status Enable or Disable Smart Smart Fan Function [Enabled] Smart Fan Mode Configuration System Temperature1 : +31 System Temperature3...

  • Page 34: Serial Port Console Redirection

    Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc. • Console Redirection Enable/Disable Console Function. By disabling this console function, both M.USB and RJ45 console function will be shut down. • Console Redirection Settings Set the Baut rate and Console Type. Acrosser Technology Co., Ltd.

  • Page 35: Pci Subsystem Settings

    ANR-C62xN1 Series 3.2.5. PCI Subsystem Settings Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced PCI Bus Driver Version Enables or Disables 64bit capable devices to be Decoded PCI Devices Common settings: in Above 4G Address Space Above 4G Decoding [Disabled] (Only if System Supports SR-I0V Support...

  • Page 36: Usb Configuration

    Media Detect Count →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 37: Csm Configuration

    ANR-C62xN1 Series • Network Stack When Enable UEFI Lan Boot, Disbale/Enable the Ipv4/Ipv6 Protocol. 3.2.8. CSM Configuration Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced Compatibility Support Module Configuration Enable/Disable CSM Support. CSM Support [Enabled] CSM16 Module Version 07.82 GateA20 Active [Upon Request]...

  • Page 38: Nvme Configuration

    No Intel VMD Controller →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 39: Platform Configuration

    ANR-C62xN1 Series 3.3. Platform Configuration Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Platform Configuration PCH Configuration sSATA devices and ------------------------------------------------------- Settings PCH sSATA Configuration PCH state after G3 [S0] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt.

  • Page 40: Processor Configuration

    +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc. • Memory Frequency Set the Memory frequency. Show all Memory Information. Acrosser Technology Co., Ltd.

  • Page 41: Iio Configuration

    ANR-C62xN1 Series 3.4.3. IIO Configuration Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Socket Configuration IOU0 (IIO PCIe Br1) [x8x8] Selects PCIe port IOU1 (IIO PCIe Br2) [x8x8] Bifurcation for IOU2 (IIO PCIe Br3) [x16] selected slot(s). Socket 1 PcieBr0D00F0 - Port 0 Socket 1 PcieBr1D00F0 - Port 1A Socket 1 PcieBr1D02F0 - Port 1C Socket 1 PcieBr2D00F0 - Port 2A...

  • Page 42: Intel. Vt For Directed I/O (Vt-D) Configuration

    →←: Select Screen ↑↓: Select Item Administrator Password Enter: Select User Password +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 43: Boot Setup

    ANR-C62xN1 Series • Administrator Password Set Administrator Password. • User Password Set User Password. 3.6. Boot Setup Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Boot Save & Exit Boot Configuration Number or seconds to wait Setup Prompt Timeout for setup activation key.

  • Page 44: Save & Exit Setup

    Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc. • Save Changes and Exit Exit the system after saving the changes. • Discard Changes and Exit Exit system setup without saving any changes. • Restore Defaults Restore/Load Default values for all the setup options. Acrosser Technology Co., Ltd.

  • Page 45: Software Installation And Programming Guide

    ANR-C62xN1 Series Software Installation and Programming Guide 4.1. Introduction 4.1.1. Environment This test utility develop based on kernel 4.4 above (Ubuntu 18.04.1 Server 64bit). 4.1.2. GPIO The C62XN1 provides GPIO interface. Users can use the GPIO APIs to Control GPO Pin.

  • Page 46: Power Supply Unit

    The dynamic library for linux. 6. Install_driver This file is linux shell script file. Run this file can help you install environment and modprobe driver on linux. 7. readme Use this utility first. Please read the readme file first. Acrosser Technology Co., Ltd.

  • Page 47: Api List And Descriptions

    ANR-C62xN1 Series 4.3. API List and Descriptions 4.3.1. GPIO Syntax: Get_gpi_status(int pin) Description: Get the status of GPIO input pins status. Parameters: This function fills in an integer variable as the parameter. The pin0 ~ pin3 is the status of the input pins. Return Value: 1:HIGH, 0:LOW.

  • Page 48: Lcd Control Module

    Return Value: ‘0: Success -1:Fail The pointer data : 0x1E is Center key 0x1D is Up key 0x1B is Right key 0x17 is Left key 0x0F is Down key Acrosser Technology Co., Ltd.

  • Page 49: Power Supply Unit (Pmbus)

    ANR-C62xN1 Series Syntax: void set_lcm_displayoff(void) Description: This function can turn off lcm display. Parameters: None. Return Value: None. Syntax: Void set_lcm_displayon(void) Description: This function can turn on lcm display. Parameters: None. Return Value: None. Syntax: Void get_lcm_firmware_ver( unsigned char *data) Description: This function can get LCM PIC Version.

  • Page 50: Pmbus Command Code Summary

    Read Linear READ_TEMPERATURE_1 Read Linear READ_+12V_POUT Read Linear MFR_ID Read ASCII MFR_MODEL Read ASCII MFR_REVSION Read ASCII MFR_SERIAL Read ASCII MFR_POUT_MAX Read Linear MFR_TAMBIENT_MAX Read Linear PSU_STATUS Read Byte READ_TOTAL_POUT (3) Read Linear READ_3V3_VOUT Read VOUT Mode Acrosser Technology Co., Ltd.
  • Page 51 ANR-C62xN1 Series Command Number of Command Name Data Format Code Data Bytes READ_3V3_IOUT Read Linear REDA_3V3_POUT Read Linear READ_5V_VOUT Read VOUT Mode READ_5V_IOUT Read Linear READ_5V_POUT Read Linear Buzzer_Mute (4) R/W Byte Note 1: Status will retain the last occurrence. Latch defined as the status. Must be cleared through the 03h (CLEAR_FAULTS) command.
  • Page 52 Status Bit Name Meaning [7:6] Reserved Return=0 +12V_IOUT > Max Current of +12V_OC_WARNING 110%@1Sec = 1 ; Normal = 0 [4:0] Reserved Return=0 Contents in 7Dh (STATUS_TEMPERATURE) Command Code: Bit Number Status Bit Name Meaning [7:3] Reserved Return=0 Acrosser Technology Co., Ltd.
  • Page 53 ANR-C62xN1 Series AMBIENT_OT_FAULT Ambient temperature >60°C = 1 ; Normal =0 AMBIENT_OT_WARNING Ambient temperature >55°C = 1 ; Normal = 0 [1:0] Reserved Return=0 Contents in 80h (STATUS_OF_3V3 And 5V) Command Code: Bit Number Status Bit Name Meaning 5V_IOUT > Max Current of 130%@ 1Sec = 1 ; 5V_OC_ FAULT Normal = 0 3V3_IOUT >...

  • Page 54: Chassis Opened

    Parameters: None. Return Value: None. Syntax: void i2c_init(void) Description: use the psu(i2c), psu(pmbus), chassis, lan bypass, these function before, must be call this function first. Parameters: None. Return Value: None. Acrosser Technology Co., Ltd.
  • Page 55 ANR-C62xN1 Series Syntax: void i2c_close(void) Description: if the psu(i2c), psu(pmbus), chassis, lan bypass, these function not use on your program please call this function. Parameters: None. Return Value: None. Syntax: void CloseSerialPort(void) Description: if lcm function not use on your program, please call this function.

  • Page 56: Faq

    Q 1. Where can I find the serial number of this product? • The serial number (S/N) is a label printed with alpha-numeric character. You can find the S/N label on the bottom of this product or on its packing box. Acrosser Technology Co., Ltd.
  • Page 57 ANR-C62xN1 Series Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
  • Page 58 Acrosser Headquarters Acrosser Nanjing Office 欣扬通电子有限公司 南京办事处 241新北市三重區光復路一段61巷26號10樓 江苏省南京市江宁区天元东路228号504室 10F., No.26, Ln. 61, Sec. 1, Guangfu Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241, Taiwan Room 504, No. 228, Tian Yuan East Rd., (R.O.C.) Jiang Ning Dist., Nanjing City, Jiangsu Province, TEL: +886-2-29999000 China (Postal: 211100) FAX: +886-2-29992887 / +886-2-29993960...
