ANR-C236N1-K
Networking 1U Rackmount Server
®
• Intel
C236 PCH
®
®
• Intel
Xeon
E3-1200 V6/Kabylake-S Embeded SKUs
• 12x GbE Copper (4-pair bypass), 1x Mgmt. Port
• 2x 10G Fiber (SFP+)
• 1x Exp. NIM (1G/10G/40G, Fiber/Copper/LAN Bypass)
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com
ANR-C236N1-K Series User Manual
Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANR-C236N1-K2D00 and is the answer not in the manual?

Questions and answers

Related Manuals for Acrosser Technology ANR-C236N1-K2D00

Summary of Contents for Acrosser Technology ANR-C236N1-K2D00

  • Page 1 • Intel C236 PCH ® ® • Intel Xeon E3-1200 V6/Kabylake-S Embeded SKUs • 12x GbE Copper (4-pair bypass), 1x Mgmt. Port • 2x 10G Fiber (SFP+) • 1x Exp. NIM (1G/10G/40G, Fiber/Copper/LAN Bypass) User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    ANR-C236N1-K Series User Manual Table of Contents 1. Introduction ..............5 1.1. Models ........................5 1.2. Specifications ......................5 1.3. Packing List ........................ 7 1.4. Layout & Dimension ....................8 1.5. Front Panel ......................... 9 1.5.1. Module A: Network expansion module connector ........... 9 1.5.2.
  • Page 4 4.3.9. Chassis Opened .................... 55 4.3.10. Notes ......................55 5. FAQ ................57 Q 1. Where can I find the serial number of this product? ..........57 Q 2. How to enable the PXE function? ................57 Acrosser Technology Co., Ltd.

  • Page 5: Introduction

    SSD for RAID0/1 and 1+1 redundant power supply units (RPSU) with AC-IN (100 ~ 240V) or DC-IN (48V), enabling reliable options for system recovery. 1.1. Models This manual is applied to the following models: 1. ANR-C236N1-K2D0T 2. ANR-C236N1-K2D00 3. ANR-C236N1-K1D00 1.2. Specifications System Thermal Solution •...
  • Page 6 Relative Humidity • 0 ~ 90% @40°C, non-condensing Power Supply Unit • 1+1 ATX PSU (250W~300W) • 1+Dummy ATX PSU (250W~300W) • Single ATX PSU (250W~300W) Power Requirements • ATX Circuit as AT Mode with Power Switch Acrosser Technology Co., Ltd.

  • Page 7: Packing List

    ANR-C236N1-K Series User Manual Mechanical & Environment Certification • CE, FCC Class A, RoHS 2, cULus Vibration Test • IEC 60068-2-64, 5~500Hz, 3GRMS Drop Test • ISTA-2A 2006 1.3. Packing List Check if the following items are included in the package. Item Q’ty ANR-C236N1-K Series System...

  • Page 8: Layout & Dimension

    ANR-C236N1-K Series User Manual 1.4. Layout & Dimension (Illustration model: ANR-C236N1-K2D0T) Acrosser Technology Co., Ltd.

  • Page 9: Front Panel

    ANR-C236N1-K Series User Manual 1.5. Front Panel 1.5.1. Module A: Network expansion module connector Available LAN Modules: Note: The model name, type number, or layout design of these options might change due to product revision. 1. ACC-NM1Z1-01C8B: 1G Copper x8 (RJ-45 w/ 4-pair Bypass) 2.
  • Page 10 ANR-C236N1-K Series User Manual 3. ACC-NM1Z1-01F8: 1G Fiber x8 (SFP) 4. ACC-NM1Z1-01H8B: 1G Hybrid x8 (SFP + RJ-45 w/ 2-pair Bypass) 5. ACC-NM1Z1-01H8: 1G Hybrid x8 (SFP + RJ-45) 6. ACC-NM1Z1-10F2: 10G Fiber x2 (SFP+) Acrosser Technology Co., Ltd.
  • Page 11 ANR-C236N1-K Series User Manual 7. ACC-NM1Z1-10F4: 10G Fiber x4 (SFP+) 8. ACC-NM1Z1-40F1: 40G Fiber x1 (QSFP+) 9. ACC-NM1Z1-40F2: 40G Fiber x2 (QSFP+) 10. ACC-NM1Z1-01C4B: 1G Copper x4 (RJ-45 w/ 2-pair Bypass) www.acrosser.com...
  • Page 12 ANR-C236N1-K Series User Manual 11. ACC-NM1Z1-01C4: 1G Copper x4 (RJ-45) 12. ACC-NM1Z1-01F4: 1G Fiber x4 (SFP) Acrosser Technology Co., Ltd.

  • Page 13: Sfp+ 10Gbe Lan Ports

    ANR-C236N1-K Series User Manual 1.5.2. SFP+ 10GbE LAN Ports Light Status Blue On 10Gbps Blue 1Gbps or below If this LAN port funtion fail after connected a 1GbE module, you may try the following steps: Step 1: Remove the 1GbE module from the LAN port. Step 2: Disable the LAN port function.

  • Page 14: Console / 2X Usb 3.0

    1.5.5. LCM Display / Menu Buttons / Indicators Graphic Mode: 100 x 16 Pixels LCM Display Character Mode: 16-character x 2-line Menu Buttons LCM menu control buttons Reset button HDD activity indicator Power indicator 1.5.6. HDD Trays 2x 2.5" HDD trays. Acrosser Technology Co., Ltd.

  • Page 15: Rear Panel

    ANR-C236N1-K Series User Manual 1.6. Rear Panel AC Inlets Expansion Card Slot Power Switch HDMI • AC Inlets Redundant AC power inlets. • Power Switch Power on/off switch. • 2x USB 2.0 ports. • HDMI HDMI connector. • Expansion Card Slot PCI express card insert slot.

  • Page 16: Installation

    Secure both left and right 1U mounting ears to the server’s front panel chassis with your Phillips screwdriver. Step 3: Secure both left and right inner brackets by three M4 or M5x5 screws to each of the server’s left and right side with your Phillips screwdriver. Acrosser Technology Co., Ltd.
  • Page 17 ANR-C236N1-K Series User Manual Step 4: Determine which rack hole numbers to use. (a) If your rack has threaded mounting holes in the rack posts, determine whether the threads are metric or standard. Select the appropriate screws from the package included in the mounting kit. (b) If your rack does not have threaded mounting holes, the mounting screws are secured with caged nuts.
  • Page 18 Step 10: Slide the chassis all the way into the rack until the chassis mounting ears are against the front posts. Step 11: Tighten the chassis mounting ears to the rack posts each by using one screw into the middle hole. Acrosser Technology Co., Ltd.

  • Page 19: Lan Module Insertion

    ANR-C236N1-K Series User Manual 2.2. LAN Module Insertion To install the LAN module into the ANR-C236N1-K system: Step 1: Remove the plate that originally covers the Module A slot on ANR- C236N1-K system. Step 2: Insert the LAN module into the Module A slot on ANR-C236N1-K system. (ANR-C236N1-K Series) Step 3: Push the locker left to lock the board into system.

  • Page 20: Lan Module Extraction

    Step 1: Push the locker right to loosen the board. (ANR-C236N1-K Series) Step 2: Grab both knobs of the LAN module. Carefully pull the board out of the slot. Do not drop the board. (ANR-C236N1-K Series) Acrosser Technology Co., Ltd.

  • Page 21: Hard Disk Insertion

    ANR-C236N1-K Series User Manual 2.3. Hard Disk Insertion To install your 2.5" HDD: Step 1: Push the latch right, a white circle appears. The door is unlocked. (ANR-C236N1-K Series) Step 2: Push the door open. (ANR-C236N1-K Series) Step 3: Insert your HDD into the tray. Close the door, the HDD will be slided into its position.

  • Page 22: Riser Card Installation

    PCIEXP2 slot. And then unscrew the two screws that were originally securing a cover plate to the real panel. Step 2: Unscrew the cover plate shield. Note: Keep these screws safely on your table. Acrosser Technology Co., Ltd.
  • Page 23 ANR-C236N1-K Series User Manual Step 2: Secure your riser card with one screw to the cover plate. Step 3: Insert your riser card into the holder plate. www.acrosser.com...
  • Page 24 ANR-C236N1-K Series User Manual Step 4: Firmly insert your riser card into the PCIEXP2 slot on ANR-C236N1-K Series. Screw the holder plate with two screws to secure the riser card to the PCIEXP2 slot. Acrosser Technology Co., Ltd.
  • Page 25 ANR-C236N1-K Series User Manual Step 5: Screw the cover plate with two screws to secure the riser card to the real panel. Step 6: Replace the top cover. www.acrosser.com...

  • Page 26: Lcm Display

    ANR-C236N1-K Series User Manual 2.5. LCM Display Graphic Mode: 100 x 16 Pixels Character Mode: 16-character x 2-line 2.5.1. Board Layout (Model: ADB-LCM3Z1) Top Side: Acrosser Technology Co., Ltd.

  • Page 27: Connector Pin Definition

    ANR-C236N1-K Series User Manual 2.5.2. Connector Pin Definition • LCM Module Connector Pin # Signal Pin # Signal VSS:0V VDD:5V R/W# Chip Enable BL VCC BL CTL • Button In Connector Pin # Signal KEY0 (Up) KEY1 (Right) KEY2 (Left) KEY3 (Down) •...
  • Page 28 ANR-C236N1-K Series User Manual • H/W Strapping Connector Pin 1, 2 Function Short Character Mode LCM Open Graphic Mode LCM • CON7 UART & Power In Connector Pin # Signal POR (Reserved) +5V VCCIN CTS# (Reserved) RTS# (Reserved) Acrosser Technology Co., Ltd.

  • Page 29: Menu Buttons / Indicators

    ANR-C236N1-K Series User Manual 2.6. Menu Buttons / Indicators • Menu Buttons ▲Up LCM menu control buttons. ◄Left ►Right ▼Down • Reset button. • HDD activity indicator. • Power indicator. 2.6.1. Board Layout (Model: ADB-FPIOZ1) Top Side: Bottom Side: www.acrosser.com...

  • Page 30: Connector/Button Pin Definition

    SW-RST1 Pin1, Pin2 LED-PWR1+, LED-HDD1+ LED-PWR1- (Green) LED-HDD1- (Yellow) • SW-RST1 Reset Button Pin # Signal 1, 2 CN-RST1 Pin2 3, 4 • SW-UP1 KEY0 (Up) Button Pin # Signal 1, 2 CN-LCM1 Pin2 3, 4 Acrosser Technology Co., Ltd.
  • Page 31 ANR-C236N1-K Series User Manual • SW-R1 KEY1 (Right) Button Pin # Signal 1, 2 CN-LCM1 Pin3 3, 4 • SW-L1 KEY2 (Left) Button Pin # Signal 1, 2 CN-LCM1 Pin4 3, 4 • SW-DOWN1 KEY3 (Down) Button Pin # Signal 1, 2 CN-LCM1 Pin5 3, 4...

  • Page 32: Bios Settings

    Version 2.18.1256. Copyright (C) 2017 American Megatrends, Inc. Note: Listed at the bottom of the menu are the control keys. If you need any help with the item fields, you can press <F1> key, and it will display the relevant information. Acrosser Technology Co., Ltd.

  • Page 33: Advanced Setup

    ANR-C236N1-K Series User Manual • System Date Set the system date. Note that the ‘Day’ automatically changes when you set the date. • System Time Set the system time. 3.2. Advanced Setup Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc. Main Advanced Chipset...

  • Page 34: Sata Configuration

    SATA 1, SATA 2, MSATA 1, CFAST 1 Enable or disable SATA port. • Hot Plug Designates this port as Hot Pluggable. • SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard Disk Drive. Acrosser Technology Co., Ltd.

  • Page 35: W83627Dhg Hw Monitor

    ANR-C236N1-K Series User Manual 3.2.2. W83627DHG HW Monitor Dsiplay hardware monitor status. Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc. Advanced PC Health Status Enable or Disable Smart Smart Fan Function [Enabled] System temperature : +29°C CPU temperature : +47°C SYSFAN1 Speed : 6000 RPM...

  • Page 36: Serial Port Console Redirection

    Console Redirection Enable/Disable Consol Redirection. • Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible setttings. Acrosser Technology Co., Ltd.

  • Page 37: Lan Bypass Function

    ANR-C236N1-K Series User Manual 3.2.4. Lan Bypass Function Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc. Advanced PIC 1-1 POWER ON [NORMAL] PIC 1-1 POWER OFF [NORMAL] PIC 1-1 WATCH DOG TIMEOUT [PASS] PIC 1-2 POWER ON [NORMAL] PIC 1-2 POWER OFF [NORMAL] PIC 1-2 WATCH DOG TIMEOUT...

  • Page 38: Security Setup

    At last, press <F4> then <Enter> to save and reboot the system to make the password effective. The administrator password allows you to make changes to all BIOS settings. Acrosser Technology Co., Ltd.

  • Page 39: Boot Setup

    ANR-C236N1-K Series User Manual 3.5. Boot Setup Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Boot LOGO [Enabled] Enables or disables Quiet Boot option. Boot Option Priorities →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt.
  • Page 40 Press <Enter> on this item and select [Yes] to load the default settings of the BIOS. The BIOS default settings help the system to operate in optimum state. Always load the Optimized defaults after updating the BIOS or after clearing the CMOS values. Acrosser Technology Co., Ltd.

  • Page 41: Software Installation And Programming Guide

    ANR-C236N1-K Series User Manual Software Installation and Programming Guide 4.1. Introduction 4.1.1. Environment This test utility develop based on kernel 4.4 or above (Ubuntu 16.10 Server 64bit). 4.1.2. GPIO The ANR-C236N1-K Series provides GPIO interface. Users can use the GPIO APIs to control GPO Pin.

  • Page 42: Power Supply Unit

    The chassis supply APIs provide to control the module. By invoking these APIs, programmers can implement the applications which have the functions listed below. 1. Get chassis opened status. 2. Set chassis opened (Enabled or Disabled). Acrosser Technology Co., Ltd.

  • Page 43: File Descriptions

    ANR-C236N1-K Series User Manual 4.2. File Descriptions 4.2.1. GPIO/Watchdog/LAN Bypass Subsystem/LCM 1. TestUtility.exe The Watchdog, LAN Bypass Subsystem, Power Supply Unit, LCM Control Module and chassis open. Graphic user interface bin binary. 2. Libw83627.h This file includes the declarations of the APIs and macro definitions. 3.

  • Page 44: Watchdog

    4.3.3. LAN Bypass Subsystem Syntax: int get_bypass_firmware_ver(char *ver) Description: This function can get bypass firmware version and data to save in char pointer. Parameters: char pointer, this pointer to 7 character array. Return Value: 0: Successful, -1: fail. Acrosser Technology Co., Ltd.
  • Page 45 ANR-C236N1-K Series User Manual Syntax: int set_bypass_wdt(int pair, int time) Description: This function can set which pair bypass Wdt timer. Parameters: pair: 1-4 , time: 1-255(sec), 0: stop. Return Value: 0: Successful, -1: fail. Syntax: int set_bypass_wdt_action(int pair, int action) Description: This function can set which pair bypass Wdt time up action.

  • Page 46: Lcd Control Module

    LCM screen or eliminate the cursor on the LCM screen. The position of the cursor is unchanged. mode = true, show the cursor. mode = false, eliminate the cursor. Parameters: None. Return Value: 0 after the cursor has been shown or eliminated. Acrosser Technology Co., Ltd.
  • Page 47 ANR-C236N1-K Series User Manual Syntax: i32 cursorActionLcm(i32 type) Description: According to the argument ‘type’, move the cursor to the indicated position. The displayed text is not altered. type = HOME, move the cursor to row 0, column 0. type = MOVERIGHT, move the cursor to the column which is to the right of its original position if the original column <...
  • Page 48 Return Value: None. Syntax: int setBacklight(int mode) Description: This function can set LCM backlight, but only support LCD panel, not support OLED panel. Parameters: mode: 0: Turn off backlight, 1: Turn on backlight Return Value: None. Acrosser Technology Co., Ltd.

  • Page 49: Power Supply Unit (Pmbus)

    ANR-C236N1-K Series User Manual 4.3.5. Power Supply Unit (PMBUS) Syntax: float pmbus_read_vout_12V(void) Description: This function can get power supply unit Vout 12V. Parameters: None. Return Value: float Vout 12V Syntax: float pmbus_read_vout_3V3(void) Description: This function can get power supply unit Vout 3.3V. Parameters: None.
  • Page 50 Note 4: Buzzer will alert when any PSU fault occurs. Write 0x20 command in PMBus will be able to mute buzzer alarm. When PSU goes back to normal state, the register will be set at 0x00. Acrosser Technology Co., Ltd.
  • Page 51 ANR-C236N1-K Series User Manual Contents in 20h (VOUT_MODE) Command Code: Mode Bits [7:5] Bits [4:0] (Parameter) Five bit two’s complement exponent for the mantissa delivered as Linear 000b the data bytes for an output voltage related command. Note: The Mode bits are set to 000b. The Voltage (ex.+12V_VOUT , 3V3_VOUT , 5V_VOUT), in volts, is calculated from the equation: Voltage = V x 2 Where:...
  • Page 52 Module Plug OUT = 1 ; Module Plug IN = 0 PSU1 PRESENT Module Plug OUT = 1 ; Module Plug IN = 0 PSU2 STATUS FAIL = 1 ; OK = 0 PSU1 STATUS FAIL = 1 ; OK = 0 Acrosser Technology Co., Ltd.

  • Page 53: Power Supply Unit (I C)

    ANR-C236N1-K Series User Manual MFR Meaning: Command Code Command Name Meaning MFR_ID ETASIS MFR_MODEL EFRP-S2287HPM MFR_REVSION A0 ~ Z9 MFR_SERIAL Code = 12 (ex. T201XXG00001) MFR_POUT_MAX 280 (W) MFR_TAMBIENT_MAX 40 (°C) C Address Set Table: PDB MCU Device FRU Device (Option) 4.3.7.

  • Page 54: Application Notes For R1V2-5275V/I C

    If CR10 = D7, then the +3.3V voltage = 0.0078125 * D7 * 2 = 3.359V If CR11 = 6C, then the +5V voltage = 0.0078125 * 6C * 6 = 5.06V If CR12 = 92, then the monitor +12V voltage = 0.0078125 * 92 * 11 = 12.5V Acrosser Technology Co., Ltd.

  • Page 55: Chassis Opened

    ANR-C236N1-K Series User Manual 4.3.9. Chassis Opened Syntax: int get_chassis_open_status(void) Description: This function can get chassis status. Parameters: None. Return Value: 0: Disabled, 1: Enabled. Syntax: void set_chassis_open(int value) Description: This function can set chassis opened. Parameters: 0: Disabled, 1: Enabled. Return Value: None.
  • Page 56 ANR-C236N1-K Series User Manual Syntax: void CloseSerialPort(void) Description: if lcm function not use on your program, please call this function. Parameters: None. Return Value: None. Acrosser Technology Co., Ltd.

  • Page 57: Faq

    ANR-C236N1-K Series User Manual Q 1. Where can I find the serial number of this product? • The serial number (S/N) is a label printed with alpha-numeric character. You can find the S/N label on the bottom of this product or on its packing box. Q 2.
  • Page 58 ANR-C236N1-K Series User Manual Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
  • Page 59 Acrosser Headquarters Acrosser Nanjing Office 欣扬通电子有限公司 南京办事处 241新北市三重區光復路一段61巷26號10樓 江苏省南京市江宁区天元东路228号504室 10F., No.26, Ln. 61, Sec. 1, Guangfu Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241, Taiwan Room 504, No. 228, Tian Yuan East Rd., Jiang (R.O.C.) Ning Dist., Nanjing City, Jiangsu Province, China TEL: +886-2-29999000 (Postal: 211100) FAX: +886-2-29992887 / +886-2-29993960...
