ANR-C62xN1
Networking 2U Rackmount Server
®
®
• Intel
Xeon
®
• 8x Acrosser
(for 1G/10G/25G/40G, Fiber/Copper/LAN Bypass)
• 2x SFP+ (10G Fiber)
• 1x Management Port
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com
+ C627/C622 PCH
Swappable Expansion NIM
ANR-C62xN1 Series
Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANR-C62-N1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acrosser Technology ANR-C62-N1 Series

Summary of Contents for Acrosser Technology ANR-C62-N1 Series

  • Page 1 Series Networking 2U Rackmount Server ® ® • Intel Xeon + C627/C622 PCH ® • 8x Acrosser Swappable Expansion NIM (for 1G/10G/25G/40G, Fiber/Copper/LAN Bypass) • 2x SFP+ (10G Fiber) • 1x Management Port User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    ANR-C62xN1 Series Table of Contents 1. Introduction ..............5 1.1. Models ........................5 1.2. Specifications ......................6 1.3. Packing List ........................ 7 1.4. Layout & Dimension ....................8 1.5. Front Panel ......................... 9 1.5.1. Module A: Network expansion module connector ........... 9 1.5.2.
  • Page 4 4.3.4. Power Supply Unit (PMBUS) ................ 48 4.3.5. Pmbus Command Code Summary ............... 49 4.3.6. Chassis Opened .................... 53 4.3.7. Notes ......................53 5. FAQ ................55 Q 1. Where can I find the serial number of this product? ..........55 Acrosser Technology Co., Ltd.

  • Page 5: Introduction

    ANR-C62xN1 Series Introduction Acrosser’s brand new 2U rack mount server, ANR-C627/622N1 series, are designed ® with X86 processor and positioned for Intel Xeon-based 2U network appliances which require high-performance computing (HPC) and multi-core (up to 28 cores) with hyper-threading (HT) functionality for a wide range of workloads with high memory bandwidth (DDR4-2666) and capacity.

  • Page 6: Specifications

    • SYS FAN Speed Security & Mgmt. • On-board TPM 2.0 • Chassis Intrusion Detection (default: Disable) OS support • Linux Kernel 4.4 or above, (64-bit) • DPDK for ANR-C62xN1(U) series • QAT for ANR-C627N1(U) series Acrosser Technology Co., Ltd.

  • Page 7: Packing List

    ANR-C62xN1 Series Mechanical & Environment Chassis Dimension • 440 (W) x 88.5 (H) x 670 (D) mm Operating Temperature • 0 ~ 40°C (32 ~ 104°F) Storage Temperature • -20 ~ 80°C (-4 ~ 176°F) Relative Humidity • 0 ~ 90% @40°C, non-condensing Power Supply Unit •...

  • Page 8: Layout & Dimension

    ANR-C62xN1 Series 1.4. Layout & Dimension (Illustration model: ANR-C62xN1 with 8x optional LAN modules) 440.00 Acrosser Technology Co., Ltd.

  • Page 9: Front Panel

    ANR-C62xN1 Series 1.5. Front Panel 1.5.1. Module A: Network expansion module connector Available LAN Modules: Note: The model name, type number, or layout design of these options might change due to product revision. 1. ACC-NM1Z1-01C8B: 1G Copper x8 (RJ-45 w/ 4-pair Bypass) 2.
  • Page 10 ANR-C62xN1 Series 3. ACC-NM1Z1-01F8: 1G Fiber x8 (SFP) 4. ACC-NM1Z1-01H8B: 1G Hybrid x8 (SFP + RJ-45 w/ 2-pair Bypass) 5. ACC-NM1Z1-01H8: 1G Hybrid x8 (SFP + RJ-45) 6. ACC-NM1Z1-10F2: 10G Fiber x2 (SFP+) Acrosser Technology Co., Ltd.
  • Page 11 ANR-C62xN1 Series 7. ACC-NM1Z1-10F4: 10G Fiber x4 (SFP+) 8. ACC-NM1Z1-40F1: 40G Fiber x1 (QSFP+) 9. ACC-NM1Z1-40F2: 40G Fiber x2 (QSFP+) 10. ACC-NM1Z1-01C4B: 1G Copper x4 (RJ-45 w/ 2-pair Bypass) www.acrosser.com...
  • Page 12 ANR-C62xN1 Series 11. ACC-NM1Z1-01C4: 1G Copper x4 (RJ-45) 12. ACC-NM1Z1-01F4: 1G Fiber x4 (SFP) Acrosser Technology Co., Ltd.

  • Page 13: Hdd Trays

    ANR-C62xN1 Series 1.5.2. HDD Trays 4x 2.5” SATA3 Hot-swappable HDD trays (for ANR-C62xN1). 2x U.2 NVMe|SATA3 Hot-swappable HDD trays (for or ANR-C62xN1U). 1.5.3. SFP+ 10GbE LAN Ports Light Status Blue On 10Gbps Blue 1Gbps or below If this LAN port funtion fail after connected a 1GbE module, you may try the following steps: Step 1: Remove the 1GbE module from the LAN port.

  • Page 14: Lan / Console / 2X Usb 3.0 / Reset

    Either M.USB or RJ45 console can only be used only one at a time. • Reset System Reset Button • Console (RJ45) Pin # Signal Pin # Signal SOUT • Light Status 10Mbps LED2 Orange 100Mbps Green 1000Mbps Yellow Link/Active LED1 LAN Off Acrosser Technology Co., Ltd.

  • Page 15: Lcm Display / Navigation Joystick / Indicators

    ANR-C62xN1 Series • Standard USB 3.0 Type-A connector 1.5.5. LCM Display / Navigation Joystick / Indicators Navi. Joystick IPMI • LCM Display 128 * 32 Pixels Graphic mode only • Navigation Joystick LCM menu control buttons (Up/Down/Left/Right/Center) • IPMI IPMI indicator (Green) •...

  • Page 16: Rear Panel

    • AC Inlets 1+1 CRPS 2U Redundant ATX PSU • System Fan 4x Hot-swappable Smart Cooling Fans with 2-color LED (Green->Normal, Orange->Warning) • 2x USB 2.0 ports • VGA connector • Power Switch Power on/off switch Acrosser Technology Co., Ltd.

  • Page 17: Installation

    ANR-C62xN1 Series Installation To mount this server into a rack, you will need to do some preparation. 2.1. Package List Check the following items. Item Description Q’ty RJ45-console cable RJ45 <-> DB9 USB-console cable Micro-B <-> Type A Ear Bracket Screw Pack www.acrosser.com...

  • Page 18: Screw List

    Description Q’ty M4x6 (black) For ear bracket M3 Screw For 2.5” HDD with sponge (yellow) 6#32 Screw For 3.5” HDD with sponge (yellow) Sponge (yellow) For 2.5” & 3.5” HDD M3x4 (sliver) For HDD bay (2.5”-7mmx4) Acrosser Technology Co., Ltd.
  • Page 19 ANR-C62xN1 Series #1: Ear brackets #2: 2.5” HDD with sponge www.acrosser.com...
  • Page 20 ANR-C62xN1 Series #3: 3.5” HDD with sponge #5: 7mm-HDD bay with screws Acrosser Technology Co., Ltd.

  • Page 21: Slide-Rail Assembly

    ANR-C62xN1 Series 2.2. Slide-rail Assembly 1. Slide-rail & Screw: 2. Screw List: www.acrosser.com...
  • Page 22 Step 2: Fasten both inner brackets by M4x4 screws to each of the server’s left and right side. Step 3: Fasten both ear brackets by M4x6 (black) screws to each of the server’s left and right side. Acrosser Technology Co., Ltd.
  • Page 23 ANR-C62xN1 Series Step 4: Install the slide-rail with M5x15 screws on both sides of the rack. The length can be adjusted with the 7mm-nut. www.acrosser.com...
  • Page 24 ANR-C62xN1 Series Step 5: Slide the server in. Note: The slide-rail will stop and lock in center position. Poke to push it in or pull out. Acrosser Technology Co., Ltd.

  • Page 25: Pcie Card Installation

    ANR-C62xN1 Series 2.3. PCIe Card Installation Step 1: Open the top cover. The red-line frame is marked as the position to insert the add-on PCIe card. Remove the 2 screws shown in the red circle to remove the bracket. Remove the 7 screws shown in the red circle of the next three figures, Step 2: and then remove the bracket.
  • Page 26 ANR-C62xN1 Series Acrosser Technology Co., Ltd.
  • Page 27 ANR-C62xN1 Series Remove the 2 screws shown in the figure below, and remove the 2 Step 3: bracket plates. Step 4: Insert the add-on PCIe card into position. www.acrosser.com...
  • Page 28 ANR-C62xN1 Series Step 5: Lock all the screws back. Acrosser Technology Co., Ltd.
  • Page 29 ANR-C62xN1 Series Step 6: Adjust the bracket position according to the length of add-on card to clamp the card firmly. Lock the screws. www.acrosser.com...

  • Page 30: Bios Settings

    Use the arrow keys to highlight the item and then use the <Pg Up> <Pg Dn> keys to select the value you want in each item. 3.1. Main Setup This setup menu displays Bios version and PCH stepping Information. Acrosser Technology Co., Ltd.

  • Page 31: Advanced Setup

    ANR-C62xN1 Series 3.2. Advanced Setup • Trusted Computing This option configures the Trusted Computing Settings. • OnBoard Bypass Controller This option configures the OnBoard Bypass controller. W83627DHG Super IO Configuration • This option configures the Super IO setting. • W83627DHG HW Monitor This option configures checks the status of Harwdare Monitor Value.

  • Page 32: Trusted Computing

    Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. • SHA-1 PCR Bank Enables or Disables SHA-1 PCR Bank. • SHA256 PCR Bank Enables or Disables SHA256 PCR Bank. 3.2.2. OnBoard Bypass Controller Acrosser Technology Co., Ltd.

  • Page 33: W83627Dhg Super Io Configuration

    ANR-C62xN1 Series Chassis open function • When Enabled, if the chassis had been opened continuously for 4 seconds, the system will be shut down. 3.2.3. W83627DHG Super IO Configuration • Serial Port Select Enabled to enable the onboard serial port. •...

  • Page 34: W83627Dhg Hw Monitor

    If CPU temp ishigherer than target temp+tolerance, the fan will run at full fan speed. [Manual Mode] : You can set fixed fan speed. • FAN Target Temperature Input a target temperature between 0 ~ 127°C. • FAN Tolerance Input a target temperature tolerance. Acrosser Technology Co., Ltd.

  • Page 35: Serial Port Console Redirection

    ANR-C62xN1 Series 3.2.5. Serial Port Console Redirection Set serial port console redirection. • Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, you can select a COM Port to be used for Console Redirection. •...

  • Page 36: Usb Configuration

    Use this item to enable or disable Recorder Mode to capture terminal data and send it as text messages. • Resolution 100x31 Use this item to enable or disable extended terminal resolution support. • Putty KeyPad Use this item to select Function Key and Keypad on Putty. 3.2.6. USB Configuration Acrosser Technology Co., Ltd.

  • Page 37: Network Stack Configuration

    ANR-C62xN1 Series • Legacy USB Support Select Enabled to support onboard legacy USB devices. Select Auto to disable legacy support if there are no legacy USB devices present. Select Disable to have all USB devices available for EFI applications only. XHCI Hand-off •...

  • Page 38: Csm Configuration

    (OpROM). Options are: [UEFI], [Legacy], [Do not Launch]. • Network Set The Network boot Mode: UEFI/Legacy. • Storage Set The Vbios Mode: UEFI/Legacy. • Video Set The Boot Mode, Legacy Boot or Uefi Boot. Acrosser Technology Co., Ltd.

  • Page 39: Intelrcsetup

    ANR-C62xN1 Series 3.3. IntelRCSetup 3.3.1. PCH SATA Configuration • Port 1~4 Enable/Disable Port 1/2/3/4 device • Hot Plug Enable/Disable HDD Hot-Plug function. • SATA Device Type Select SATA Device Type HDD/SSD. www.acrosser.com...

  • Page 40: Processor Setup

    The Hyper Threading Technology allows a single processor to execute two or more separate threads concurrently. When hyper-threading is enabled, multi-threaded software applications can execute their threads, thereby improving performance. • Enable/Disable the Vanderpool Technology. This will take effect after rebooting the system. Acrosser Technology Co., Ltd.

  • Page 41: Intel Vt For Directed I/O (Vt-D)

    ANR-C62xN1 Series 3.4.2. Intel VT for Directed I/O (VT-d) Intel VT for Directed I/O • Enable/Disable the Intel VT for Directed I/O (VT-d) support function by reporting the I/O device assignment to VMM through DMAR ACPI Tables. • Interrupt Remapping Enable/Disable the interrupt remapping support function.

  • Page 42: Security Setup

    Use this feature to select the screen display between POST messages or the OEM logo at bootup. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages. Acrosser Technology Co., Ltd.

  • Page 43: Save & Exit Setup

    ANR-C62xN1 Series • Boot Option Priorities This feature allows the user to specify which devices are boot devices and the order of priority from which the systems boots from during startup. 3.7. Save & Exit Setup • Save Changes and Reset When you have completed the system configuration changes, select this option to save all changes made and reset the system.

  • Page 44: Software Installation And Programming Guide

    2. Turn on or off the cursor on the screen. 3. Get the identification of the pressed key of the LCM. 4. Get LCM PIC Version. 5. Get the LCM mode. 6. Graphic write on LCM. Acrosser Technology Co., Ltd.

  • Page 45: Power Supply Unit

    ANR-C62xN1 Series 4.1.5. Power Supply Unit The Power supply APIs provide two protocols, pmbus and i2c, to control the module. By invoking these APIs, programmers can implement the applications which have the functions listed below: Pmbus: 1. Read vout 12v. 2.

  • Page 46: Api List And Descriptions

    Syntax: Int get_wdt_count(void) Description: This function reads the value of the watchdog time counter. Parameters: None. Return Value: This function returns the value of the time counter. Acrosser Technology Co., Ltd.

  • Page 47: Lcd Control Module

    ANR-C62xN1 Series Syntax: Void wdt_stop(void) Description: This function sets the watchdog timer stop. Parameters: None. Return Value: None. 4.3.3. LCD Control Module Syntax: Void clear_lcm_display( void ) Description: Clear the screen of the LCM. Parameters: None. Return Value: None. Syntax: Void graphicwritelcm (unsigned char *data) Description: Graphci Lcm show display function...

  • Page 48: Power Supply Unit (Pmbus)

    This function can get power supply unit Vout 12V. Parameters: None. float Vout 12V Return Value: float pmbus_read_vout_3V3(void) Syntax: Description: This function can get power supply unit Vout 3.3V. Parameters: None. float Vout 3.3V Return Value: Acrosser Technology Co., Ltd.

  • Page 49: Pmbus Command Code Summary

    ANR-C62xN1 Series float pmbus_read_vout_5V(void) Syntax: Description: This function can get power supply unit Vout 5V. Parameters: None. float Vout 5V Return Value: Syntax: int get_pmbus_psu_status(int psu) Description: This function can get which power supply unit status. Parameters: psu: 0-1 Return Value: 0: Good, 1: Fail 4.3.5.
  • Page 50 0x00. Contents in 20h (VOUT_MODE) Command Code: Mode Bits [7:5] Bits [4:0] (Parameter) Five bit two’s complement exponent for the mantissa delivered as Linear 000b the data bytes for an output voltage related command. Acrosser Technology Co., Ltd.
  • Page 51 ANR-C62xN1 Series Note: The Mode bits are set to 000b. The Voltage (ex.+12V_VOUT , 3V3_VOUT , 5V_VOUT), in volts, is calculated from the equation: Voltage = V x 2 Where: Voltage is the parameter of interest in volts; V is a 16 bit unsigned binary integer; and N is a 5 bit two’s complement binary integer.
  • Page 52 PSU1 STATUS FAIL = 1 ; OK = 0 MFR Meaning: Command Code Command Name Meaning MFR_ID ETASIS MFR_MODEL EFRP-S2287HPM MFR_REVSION A0 ~ Z9 MFR_SERIAL Code = 12 (ex. T201XXG00001) MFR_POUT_MAX 280 (W) MFR_TAMBIENT_MAX 40 (°C) Acrosser Technology Co., Ltd.

  • Page 53: Chassis Opened

    ANR-C62xN1 Series C Address Set Table: PDB MCU Device FRU Device (Option) 4.3.6. Chassis Opened Syntax: int get_chassis_open_status(void) Description: This function can get chassis status. Parameters: None. Return Value: 0: Disabled, 1: Enabled. Syntax: void set_chassis_open(int value) Description: This function can set chassis opened. Parameters: 0: Disabled, 1: Enabled.
  • Page 54 Parameters: None. Return Value: None. Syntax: void CloseSerialPort(void) Description: if lcm function not use on your program, please call this function. Parameters: None. Return Value: None. Acrosser Technology Co., Ltd.

  • Page 55: Faq

    ANR-C62xN1 Series Q 1. Where can I find the serial number of this product? • The serial number (S/N) is a label printed with alpha-numeric character. You can find the S/N label on the bottom of this product or on its packing box. www.acrosser.com...
  • Page 56 ANR-C62xN1 Series Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
  • Page 57 Acrosser Nanjing Office Acrosser Headquarters 欣扬通电子有限公司 南京办事处 241新北市三重區光復路一段61巷26號10樓 江苏省南京市江宁区天元东路228号504室 10F., No.26, Ln. 61, Sec. 1, Guangfu Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241, Taiwan Room 504, No. 228, Tian Yuan East Rd., (R.O.C.) Jiang Ning Dist., Nanjing City, Jiangsu Province, TEL: +886-2-29999000 China (Postal: 211100) FAX: +886-2-29992887 / +886-2-29993960...
