Acrosser Technology AND-APL1E Series User Manual

Desktop network appliance, intel celeron processor n3350/e3940 soc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AND-APL1Ex
Desktop Network Appliance
AND-APL1E1
®
Intel
Celeron
AND-APL1E2
®
Intel
Celeron
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com
®
Processor N3350 SoC
®
Processor E3940 SoC
AND-APL1Ex

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AND-APL1E Series and is the answer not in the manual?

Questions and answers

Related Manuals for Acrosser Technology AND-APL1E Series

Summary of Contents for Acrosser Technology AND-APL1E Series

  • Page 1 AND-APL1Ex AND-APL1Ex Desktop Network Appliance AND-APL1E1 ® ® Intel Celeron Processor N3350 SoC AND-APL1E2 ® ® Intel Celeron Processor E3940 SoC User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    AND-APL1Ex Table of Contents 1. Product Specifications ..............5 1.1. Specifications ......................5 1.2. Package Contents ...................... 7 2. Hardware Information ..............8 2.1. Dimensions ......................... 8 2.2. Jumpers and Connectors ..................11 2.3. List of Jumpers ......................13 2.3.1. CMOS Setting Selection (CN2) ..............13 2.4.
  • Page 4 AND-APL1Ex 4. FAQ ....................39 Q 1. Where is the serial number located on my system? ..........39 Acrosser Technology Co., Ltd.

  • Page 5: Product Specifications

    AND-APL1Ex Product Specifications AND-APL1Ex networking appliance product effectively handles Software Defined- WAN (SD-WAN), Virtual Customer Premise Equipment (vCPE) technology, Unified Threat Management (UTM), Virtual Private Networking (VPN), Intrusion Detection and Prevention Systems (IDS, IPS), Firewall technology, and Load Balancing applications. ®...
  • Page 6 • 0.5 Grms/ 5 ~ 500Hz / operation (2.5” HDD) • 1.5 Grms/ 5 ~ 500Hz / non operation Shock • 10 G peak acceleration (11 m sec. duration), operation • 20 G peak acceleration (11 m sec. duration), non operation Acrosser Technology Co., Ltd.

  • Page 7: Package Contents

    AND-APL1Ex Dimension (W X D X H) • 6.5” x 3.62” x 1.57” (165mm x 92mm x 40mm) 1.2. Package Contents Check if the following items are included in the package. Item Q’ty AND-APL1Ex � SATA Cable � SATA Power Cable �...

  • Page 8: Hardware Information

    AND-APL1Ex Hardware Information 2.1. Dimensions (Unit: mm) System: Acrosser Technology Co., Ltd.
  • Page 9 AND-APL1Ex Board Component Side: 85.8 81.75 78.09 80.27 74.08 67.03 71.88 42.32 32.22 27.28 19.79 14.11 10.9 10.23 5.77 5.39 Note: There is no SIM/DDR/mini-PCIE connector on AND-APL1E1. www.acrosser.com...
  • Page 10 AND-APL1Ex Board Solder Side: 54.36 50.4 Acrosser Technology Co., Ltd.

  • Page 11: Jumpers And Connectors

    AND-APL1Ex 2.2. Jumpers and Connectors Component Side: www.acrosser.com...
  • Page 12 AND-APL1Ex Solder Side: Acrosser Technology Co., Ltd.

  • Page 13: List Of Jumpers

    AND-APL1Ex 2.3. List of Jumpers Please refer to the table below for all of the board’s jumpers that you can configure for your application. Label Function CMOS Setting Selection 2.3.1. CMOS Setting Selection (CN2) Normal (Default) Clear CMOS 2.4. List of Connectors Please refer to the table below for all of the board’s connectors that you can configure for your application.

  • Page 14: Digital I/O (Cn9)

    Digital- IN/OUT(Port1 Bit 1) Digital- IN/OUT (Port1 Bit 2) Digital- IN/OUT (Port1 Bit 4) Digital- IN/OUT (Port1 Bit 5) Digital- IN/OUT (Port3 Bit 4) Digital- IN/OUT (Port3 Bit 5) Digital- IN/OUT (Port6 Bit 3) Digital- IN/OUT (Port4 Bit 7) Acrosser Technology Co., Ltd.

  • Page 15: Hard Drive Installation

    AND-APL1Ex 2.5. 2.5” Hard Drive Installation This section details the steps of how to install a 2.5” hard drive. Step 1: Unscrew the front cover. Step 2: Install the anti-vibration pad and 2.5”HDD and then fix the screws. www.acrosser.com...
  • Page 16 AND-APL1Ex Step 3: Install the HDD Bracket & Cable and fix the screws. Acrosser Technology Co., Ltd.
  • Page 17 AND-APL1Ex Step 4: Screw on the front cover. www.acrosser.com...

  • Page 18: Ami Bios Setup

    Advanced – Enable/ Disable boot option for legacy network devices Chipset – For hosting bridge parameters Boot – Enable/ Disable quiet Boot Option Security – The setup administrator password can be set here Save & Exit – Save your changes and exit the program Acrosser Technology Co., Ltd.

  • Page 19: Setup Submenu: Main

    AND-APL1Ex 3.3. Setup Submenu: Main 3.4. Setup Submenu: Advanced www.acrosser.com...

  • Page 20: Advanced: Trusted Computing

    Endorsement Hierarchy Enable or Disable Endorsement Hierarchy. • TPM2.0 UEFI Spec Version Select the TCG2 Spec Version Support. TCG_1_2: the Compatible mode for Win8/Win10, TCG_2: Support new TCG2 protocol and event format for Win10 or later. Acrosser Technology Co., Ltd.

  • Page 21: Advanced: Cpu Configuration

    AND-APL1Ex • Physical Presence Spec Version Select to Tell O.S. to support PPI Spec Version 1.2 or 1.3. Note some HCK tests might not support 1.3. • Device Select TPM 1.2 will restrict support to TPM 1.2 devices, TPM 2.0 will restrict support to TPM 2.0 devices, Auto will support both with the default set to TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated.

  • Page 22: Advanced: Sata Drives

    AND-APL1Ex 3.4.3. Advanced: SATA Drives • Chipset SATA Enables or Disables the Chipset SATA Controller. The Chipset SATA controller supports the 2 black internal SATA ports (up to 3Gb/s supported per port). Acrosser Technology Co., Ltd.

  • Page 23: Advanced: Usb Configuration

    AND-APL1Ex 3.4.4. Advanced: USB Configuration • Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. www.acrosser.com...

  • Page 24: Advanced: Hardware Monitor

    Note: Some fans have the minimum speed even if the PWM value is 0. • Start Control Temperature Temperature Limit Value of FAN Start Control. • Full Speed Temperature Temperature Limit Value of FAN Full Speed. • PWM Slope Slope PWM value/Degree C for FAN Speed Control. Range:[1-15] Acrosser Technology Co., Ltd.

  • Page 25: Advanced: Sio Configuration

    AND-APL1Ex 3.4.6. Advanced: SIO Configuration 3.4.6.1. Serial Port Configuration www.acrosser.com...

  • Page 26: Advanced: Serial Port Console Redirection

    Enable/Disable this Logical Device. • Possible Allow user to change Device’s Resource settings. New settings will be reflected on This Setup Page after System restarts. 3.4.7. Advanced: Serial Port Console Redirection • Console Redirection Console Redirection Enabled or Disabled. Acrosser Technology Co., Ltd.

  • Page 27: Console Redirection Settings

    AND-APL1Ex 3.4.7.1. Console Redirection Settings • Terminal Type Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes. •...
  • Page 28 Redirection After BIOS POST The Setting Specify if BootLoader is selected than Legacy console redirection is disabled before booting to Legacy OS. Default value is Always Enable which means Legacy console Redirection is enabled for Legacy OS. Acrosser Technology Co., Ltd.

  • Page 29: Legacy Console Redirection Settings

    AND-APL1Ex 3.4.7.2. Legacy Console Redirection Settings • Legacy Serial Redirection Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages. (Default only support first COM Port). www.acrosser.com...

  • Page 30: Serial Port For Out-Of-Band Management/Windows Emergency Management Services (Ems)

    0 if the num of 1’s in the data bits is even. Odd: parity bit is 0 if num of 1’s in the data bits is odd. Mark: parity bit is always 1. Space: Parity bit is always 0. Mark and Space Parity do not allow for error detection. Acrosser Technology Co., Ltd.

  • Page 31: Advanced: Lan Bypass Configuration

    AND-APL1Ex • Stop Bits Stop bits indicate the end of a serial data packet. ( A start bit indicates the beginning). The standard setting is 1 stop bit. Communication with slow devices may require more than 1 stop bit. 3.4.8. Advanced: LAN Bypass Configuration •...

  • Page 32: Advanced: Power Management

    Select 0-23 For example enter 3 for 3am and 15 for 3pm. • Wake up minute (Fixed time option) 0-59. • Wake up second (Fixed time option) 0-59. • Wake up minute increase (Dynamic time option) 1-5. Acrosser Technology Co., Ltd.

  • Page 33: Advanced: Digital Io Port Configuration

    AND-APL1Ex 3.4.10. Advanced: Digital IO Port Configuration • DIO Port1~4 Set DIO as Input or Output • Output Level Set output level when DIO pin is output • DIO Port5~8 Set DIO as Input or Output www.acrosser.com...

  • Page 34: Setup Submenu: Chipset

    AND-APL1Ex 3.5. Setup submenu: Chipset 3.5.1. Chipset: North Bridge Acrosser Technology Co., Ltd.

  • Page 35: Chipset: Scc Configuration

    AND-APL1Ex • Primary Display Select which of IGD/PCI Graphics device should be Primary Display. 3.5.2. Chipset: SCC Configuration • SCC eMMC Support (D28:F0) Enable/Disable SCC eMMC Support. • eMMC Max Speed Select the eMMC max Speed allowed. www.acrosser.com...

  • Page 36: Setup Submenu: Security

    Press Enter again to set the password. • Removing the Password Select the password you want to remove and enter the current password. At the next dialog box press Enter to disable password protection. Acrosser Technology Co., Ltd.

  • Page 37: Setup Submenu: Boot

    AND-APL1Ex 3.7. Setup submenu: Boot • Quiet Boot Enable / Disable Quiet Boot option. • CSM Support Enable/Disable CSM Support. • Launch PXE ROM Controls the execution of Legacy PXE OpROM. • Network Stack Enable/Disable UEFI Network Stack. www.acrosser.com...

  • Page 38: Setup Submenu: Exit

    AND-APL1Ex 3.8. Setup submenu: Exit Acrosser Technology Co., Ltd.
  • Page 39 AND-APL1Ex Q 1. Where is the serial number located on my system? • The serial number (S/N) is an alpha-numeric character located on the bottom or side chassis. (for reference only) www.acrosser.com...
  • Page 40 AND-APL1Ex Acrosser Technology Co., Ltd.
  • Page 41 AND-APL1Ex Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
  • Page 42 Acrosser Headquarters Acrosser Nanjing Office 欣扬通电子有限公司 南京办事处 241新北市三重區光復路一段61巷26號10樓 江苏省南京市江宁区天元东路228号504室 10F., No.26, Ln. 61, Sec. 1, Guangfu Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241, Taiwan Room 504, No. 228, Tian Yuan East Rd., (R.O.C.) Jiang Ning Dist., Nanjing City, Jiangsu Province, TEL: +886-2-29999000 China (Postal: 211100) FAX: +886-2-29992887 / +886-2-29993960...
