- Page 1 ® ® • Intel Xeon E3 / Kabylake-S / Skylake-S Embedded SKUs ® • Intel C236 PCH • 6x GbE Copper w/ 3-pair Bypass + 2x SFP • Exp. NIMs • Single PSU User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
- Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 3: Table Of Contents
ANR-SKB2Nx-ACN Table of Contents 1. Introduction ..............5 1.1. Specifications ......................5 1.2. Packing List ........................ 7 1.3. Layout & Dimension ....................8 1.4. Front Panel ......................... 9 1.5. Rear Panel........................ 10 2. Components Assembly ..........11 2.1. HDD Installation......................11 2.2. NIM Module Insertion ....................14 2.3. - Page 4 4.3.2. Watchdog ...................... 34 4.3.3. LAN Bypass Subsystem ................35 4.3.4. LCD Control Module ..................36 4.3.5. Notes ......................39 5. FAQ ................40 Q 1. Where can I find the serial number of this product? ..........40 Acrosser Technology Co., Ltd.
-
Page 5: Introduction
ANR-SKB2Nx-ACN Introduction ANR-SKB2Nx-ACN series support 6 copper GbE and 2 SFP (by sku) ports for network application and PCIe x8 slot for the expansion cards. 1.1. Specifications System Model Name • ANR-SKB2N1-ACN (Support 1x NIM) • ANR-SKB2N2-ACN (Support 2x NIMs) Thermal Solution •... - Page 6 Power Supply Unit • 1x Single PSU Power Requirements • ATX circuit as AT mode EMC & Safety Certifications • CE, FCC Class A, RoHS 2 Vibration Test • IEC 60068-2-64, 5~500Hz, 3GRMS Drop Test • ISTA-2A 2006 Acrosser Technology Co., Ltd.
-
Page 7: Packing List
ANR-SKB2Nx-ACN 1.2. Packing List Check if the following items are included in the package. Item Q’ty ANR-SKB2Nx-ACN � SATA Cable � CD Utility � Console Cable (RJ45) � Power Cord � Rack Bracket � Box Packing � Screw Pack � www.acrosser.com... -
Page 8: Layout & Dimension
ANR-SKB2Nx-ACN 1.3. Layout & Dimension Acrosser Technology Co., Ltd. -
Page 9: Front Panel
ANR-SKB2Nx-ACN 1.4. Front Panel COM1_USB3_1 Standard USB 3.0 & Yost RJ45 Console Port Pin # Signal Pin # Signal HDMI1 Standard HDMI Connector LAN1 ~ LAN4 Standard IEEE802.3 & RJ45 connector LAN5, LAN6 1000 Link Green Green Green Left Active Blinking Blinking Blinking... -
Page 10: Rear Panel
ANR-SKB2Nx-ACN 1.5. Rear Panel Power Switch AC Inlet • AC Inlet Redundant AC power inlet. • Power Switch Power on/off switch. Acrosser Technology Co., Ltd. -
Page 11: Components Assembly
ANR-SKB2Nx-ACN Components Assembly Please follow the instruction to install the inner modules. 2.1. HDD Installation To install your HDD into the system: Step 1: Remove the chassis top cover. The HDD bracket location is easy to be located. Step 2: Remove the four screws that fasten the HDD bracket from the chassis bottom cover. - Page 12 Prepare the screw pack. There should be 8 screws in the pack. Mount the anti-vibration rubber ring as shown. Push the rubber ring sideward. Do not leave the rubber ring inward. Step 3: Assemble your SSD as shown here. Acrosser Technology Co., Ltd.
- Page 13 ANR-SKB2Nx-ACN Step 4: Install the SSD that had been assembled with bracket to the chassis. Connect the SATA signal and SATA power cable. Close the top cover. www.acrosser.com...
-
Page 14: Nim Module Insertion
ANR-SKB2Nx-ACN 2.2. NIM Module Insertion To install the NIM module into the system: Step 1: Remove the screw that lock the dummy cover on Module A slot. Step 2: Open the dummy cover. Acrosser Technology Co., Ltd. - Page 15 ANR-SKB2Nx-ACN Step 3: Insert your NIM module into the Module A slot. Firmly push it all the way Step 4: Push the latch left. This will lock the module. www.acrosser.com...
- Page 16 ANR-SKB2Nx-ACN Step 5: Use your fingers to lock back the screw. Or you may use a screw driver to lock back the screw. Acrosser Technology Co., Ltd.
-
Page 17: Pcie Card Installation
ANR-SKB2Nx-ACN 2.3. PCIe Card Installation Step 1: Remove the screw that lock the cover shield. Step 2: Take out the cover shield. www.acrosser.com... - Page 18 ANR-SKB2Nx-ACN Step 3: Install your PCIe card. Pay attention to its orientation. Step 4: Secure the PCIe card by #1 head screw driver. Acrosser Technology Co., Ltd.
-
Page 19: Rack Installation
ANR-SKB2Nx-ACN 2.4. Rack Installation Step 1: Pull out each inner bracket from the slide-rail kits until it locks in the extended position. Push the slide-rail lock to release the inner bracket from the mounting bracket. Do the same to the other bracket. Slide-rail Lock Mounting Bracket Pull... - Page 20 Loosely attach the rear bracket to the rear right rack-post with two screws. Step 7: Attach the second slide-rail to the left rack-post in a similar manner. Again, do not tighten the screws. Acrosser Technology Co., Ltd.
- Page 21 ANR-SKB2Nx-ACN Step 8: Fully extend the front and rear brackets to where it reaches the rack-post. Now tighten the screws to lock the ends of the rails in place with your Phillips screwdriver. Step 9: Tighten the four screws that fasten each of the front and rear brackets with your 6-point hex wrench.
-
Page 22: Bios Settings
Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc. Note: Listed at the bottom of the menu are the control keys. If you need any help with the item fields, you can press <F1> key, and it will display the relevant information. Acrosser Technology Co., Ltd. -
Page 23: Advanced Setup
ANR-SKB2Nx-ACN • System Date Set the system date. Note that the ‘Day’ automatically changes when you set the date. • System Time Set the system time. 3.2. Advanced Setup Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Security... -
Page 24: Sata Configuration
Port 0, Port 1 Enable or disable SATA port. • Hot Plug Designates this port as Hot Pluggable. • SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard Disk Drive. Acrosser Technology Co., Ltd. -
Page 25: Trusted Computing
ANR-SKB2Nx-ACN 3.2.2. Trusted Computing Set trusted computing settings Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced TPM20 Device Found Enables or Disables BIOS Vendeor : IFX support for security Firmware Version: 5.63 device. O.S. will not show Security Device. Security Device Support [Enabled] TCG EFI protocol and... -
Page 26: W83627Dhg Hw Monitor
This item displays the System 1 Fan speed. • FAN2 Speed This item displays the System 2 Fan speed. • FAN3 Speed This item displays the System 3 Fan speed. • VCORE This item displays the VCORE voltage. Acrosser Technology Co., Ltd. -
Page 27: Serial Port Console Redirection
ANR-SKB2Nx-ACN 3.2.4. Serial Port Console Redirection Set serial port console redirection. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced COM1 The settings specify how the Console Redirection [Enabled] host computer and the remote Console Redirection Settings computer (which the user is using) will exchange data. -
Page 28: Lan Bypass Function
Graphics Device. →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc. Acrosser Technology Co., Ltd. -
Page 29: Security Setup
ANR-SKB2Nx-ACN • DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. 3.4. Security Setup Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Password Description Set Administrator Password If ONLY the Administrator’s password is set,... -
Page 30: Boot Setup
Restore Defaults →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc. Acrosser Technology Co., Ltd. - Page 31 ANR-SKB2Nx-ACN • Save Changes and Exit Press <Enter> on this item and select [Yes]. This saves the changes to the CMOS and exits the BIOS Setup program. Select [No] or press <Esc> to return to the BIOS Setup Main Menu. •...
-
Page 32: Software Installation And Programming Guide
10. Get bypass current action. 4.1.5. LCD Control Module The LCM (short for LCD Control Module) APIs provide interfaces to control the module. By invoking these APIs, programmers can implement the applications which have the functions listed below: Acrosser Technology Co., Ltd. -
Page 33: File Descriptions
ANR-SKB2Nx-ACN 1. Clear LCM screen. 2. Turn on or off the cursor on the screen (text mode only). 3. Move the cursor on the screen (text mode only). 4. Turn on or off the backlight on the screen (LCD panel only). 5. -
Page 34: Api List And Descriptions
Syntax: Int get_wdt_count(void) Description: This function reads the value of the watchdog time counter. Parameters: None. Return Value: This function returns the value of the time counter. Acrosser Technology Co., Ltd. -
Page 35: Lan Bypass Subsystem
ANR-SKB2Nx-ACN Syntax: Void wdt_stop(void) Description: This function sets the watchdog timer stop. Parameters: None. Return Value: None. 4.3.3. LAN Bypass Subsystem Syntax: int get_bypass_firmware_ver(char *ver) Description: This function can get bypass firmware version and data to save in char pointer. Parameters: char pointer, this pointer to 16 character array. -
Page 36: Lcd Control Module
This function can get which pair bypass current action. Parameters: pair: 1-4. Return Value: 0: bybpass, 1: normal, -1: fail. 4.3.4. LCD Control Module Syntax: i32 clrscrLcm(void) Description: Clear the screen of the LCM. Parameters: None. Return Value: 0 after the screen is cleared. Acrosser Technology Co., Ltd. - Page 37 ANR-SKB2Nx-ACN Syntax: i32 cursorLcm(bool mode) Description: According to the argument ‘mode’, show the cursor on the LCM screen or eliminate the cursor on the LCM screen. The position of the cursor is unchanged. mode = true, show the cursor. mode = false, eliminate the cursor. Parameters: None.
- Page 38 ‘length’, the number of the characters to be printed is: 16 – (column number of the current position of the cursor). Parameters: None. Return Value: 0 after the text is printed. Acrosser Technology Co., Ltd.
-
Page 39: Notes
ANR-SKB2Nx-ACN Syntax: i32 getLCMPICVER(unsigned char *ver) Description: This function can get LCM PIC Version. Parameters: lcm pic version will save the unsigned char pointer parameters. Return Value: None. Syntax: int setBacklight(int mode) Description: This function can set LCM backlight, but only support LCD panel, not support OLED panel. -
Page 40: Faq
Q 1. Where can I find the serial number of this product? • The serial number (S/N) is a label printed with alpha-numeric character. You can find the S/N label on the bottom of this product or on its packing box. Acrosser Technology Co., Ltd. - Page 41 ANR-SKB2Nx-ACN Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
- Page 42 Acrosser Headquarters Acrosser Nanjing Office 欣扬通电子有限公司 南京办事处 241新北市三重區光復路一段61巷26號10樓 江苏省南京市江宁区天元东路228号504室 10F., No.26, Ln. 61, Sec. 1, Guangfu Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241, Taiwan Room 504, No. 228, Tian Yuan East Rd., (R.O.C.) Jiang Ning Dist., Nanjing City, Jiangsu Province, TEL: +886-2-29999000 China (Postal: 211100) FAX: +886-2-29992887 / +886-2-29993960...
